Media Converter/Signal Repeater
Introduction
Media Converter/Signal Repeater range is a MICROSENS 10G Transport Platform
allowing Media conversation and Retiming, Reshaping and Retransmission of the signal
from 155 Mb/s up to 2.5 Gb/s.
Features
•
Media Converter
•
Signal repeater with 3R functions:
−
Retiming
−
Reshaping
−
Retransmitting
•
Supports the following protocols:
−
OC-3/STM1
−
OC-12/STM4
−
OC-48/STM16
−
GbE
−
1GFC
−
2GFC
−
Fast Ethernet
−
OC-3/STM1-FEC
−
OC-12/STM4-FEC
−
OC-48/STM16-FEC
•
SFP for Line 1 and Line 2 physical interface
•
Digital Diagnostic Monitoring information from SFP

System description

The block diagram for the MS430580M is given in Figure 1. The MS430580M is a bi-
directional device that offers twice the same media convertion/regeneration
functionnality
•
From one interface input signal (Line 1 or Line 2) to one interface output signal
(Line 2 or Line 1).
The MS430580M includes also several sections composed of
•
Controller block, providing interfacing to the MS module series chassis controller
board hosting the SNMP Agent.
•
Power supplies: generates different internal power supplies from the -48V of the
MICROSENS chassis backplane
