Media Converter/Signal Repeater
NAME
ms430580mAlmLine2TxBiasLowAla
ms430580mAlmLine2TxBiasHighAla
ms430580mAlmLine2TempLowAla
ms430580mAlmLine2TempHighAla
ms430580mAlmLine2RxPwrLowAla
ms430580mAlmLine2RxPwrHighAla
ms430580mAlmLine2TrscvAbsent
ms430580mAlmLine2TrscvDdmAbse
nt
ms430580mAlmLine2HwFail
ms430580mAlmLine2TrscvLsd
ms430580mAlmLine2TrscvDdmWarn
ing
ms430580mAlmLine2TrscvDdmAlm
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
DESCRIPTION
TRSCV 2 Bias Low: Alarm
indicating that the transceiver
laser bias current of Line 2 is
lower than the threshold value
written in the transceiver
EEPROM
TRSCV 2 Bias High: Alarm
indicating that the transceiver
laser bias current of Line 2 is
higher than the threshold value
written in the transceiver
EEPROM
TRSCV 2 Temp Low: Alarm
indicating that the transceiver
temperature of Line 2 is lower
than the threshold value written
in the transceiver EEPROM
TRSCV 2 Temp High: Alarm
indicating that the transceiver
temperature of Line 2 is higher
than the threshold value written
in the transceiver EEPROM
TRSCV 2 Rx Power Low: Alarm
indicating that the transceiver
input power of Line 2 is lower
than the threshold value written
in the transceiver EEPROM
TRSCV 2 Rx Power High: Alarm
indicating that the transceiver
input power of Line 2 is higher
than the thresholdvalue written in
the transceiverEEPROM
Line 2 SFP not plugged: This
OID indicates that the
transceiver module 2 is not
present
DDM supported on Line 2 SFP: This
OID indicates that the
transceiver module 2 does not
support Digital Diagnostic
Monitoring Functions
Line 2 HW Failure: This OID
indicates a hardware failure on
the Line 2
Line 2 SFP optical TX ON: This
OID indicates the optical output
power is off on Line 2
Warning DDM on OpticalModule
2: This OID indicates awarning is
present coming outof optical
interface DDM onLine 2
Alarm DDM on Optical Module 2:
This OID indicates an alarm is
present coming out of optical
interface DDM on Line 2
page 13/29
ACTION
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Plug in the Optical Module. If
Alarm
persists change the optical
component.
If SFP supports DDM change the
SFP, else ignore.
Correlate relevant alarms. Carry
out
necessary maintenance
procedures.
No action information only.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all alarms. Carry out
necessary maintenance
procedures.
