Media Converter/Signal Repeater
NAME
ms430580mAlmLine2TxBiasLowWng
ms430580mAlmLine2TxBiasHighWng
ms430580mAlmLine2TempLowWng
ms430580mAlmLine2TempHighWng
ms430580mAlmLine2RxPwrLowWng
ms430580mAlmLine2RxPwrHighWng
ms430580mAlmLine2CdrLossofsignal Line 2 CDR Loss of Signal: This OID
ms430580mAlmLine2CdrLossoflock
ms430580mAlmLine2CdrRefAbsent
ms430580mAlmLine2TxPwrLowAla
ms430580mAlmLine2TxPwrHighAla
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
DESCRIPTION
TRSCV 2 Bias Low warning:
Warning indicating that
thetransceiver laser bias current
ofLine 2 is lower than
thethreshold value written in the
transceiver EEPROM
TRSCV 2 Bias High warning:
Warning indicating that the
transceiver laser bias current of
Line 2 is higher than the threshold
value written in the transceiver
EEPROM
TRSCV 2 Temp Low warning:
Warning indicating that the
transceiver temperature of Line
2 is lower than the threshold
value written in the transceiver
EEPROM
TRSCV 2 Temp High warning:
Warning indicating that the
transceiver temperature of Line
2 is higher than the threshold
value written in the transceiver
EEPROM
TRSCV 2 Rx Power Low warning:
Warning indicating that the
transceiver input power
of Line 2 is lower than the
threshold value written in the
transceiver EEPROM
TRSCV 2 Rx Power Highwarning:
Warning indicating that the
transceiver input power
of Line 2 is higher than the
threshold value written in the
transceiver EEPROM
indicates that a Lossof electrical
signal is detectedon the Line 2
CDR
Line 2 CDR Loss of Lock: This
OID indicates that the Line 2
CDR is not locked
Line 2 CDR Reference clock
absent: This OID indicates that
the CDR reference clock is
absent on Line 2
TRSCV 2 Tx Power Low: Alarm
indicating that the transceiver
output power of Line 2 is lower
than the threshold value written
in the transceiver EEPROM
TRSCV 2 Tx Power High: Alarm
indicating that thetransceiver
output power ofLine 2 is higher
than thethreshold value written in
thetransceiver EEPROM
page 12/29
ACTION
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings and
Alarms.
Carry out necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Check client status. Carry out
necessary maintenance
procedures.
Check client status. Carry out
necessary maintenance
procedures.
No action information only.
Correlate all. Carry out necessary
maintenance procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
