Media Converter/Signal Repeater
The following table details the meaning of each bit as well as the default values:
ms430580mCfgportbTrscvCtrl
Bit Default value
Bit 0 0
Bit 7-1 0000000
Bit 15-8 00000000
Client/Line bitrate Configuration
One object is dedicated to the client/line bitrate configuration:
•
ms430580mCfgbitrateSelect
This allows the configuring of the bitrate for the Line 1 and Line 2.
Location: \microsens\modulems430580m\ms430580mConfig\ms430580mCfgStartup\
ms430580mtablelineStartup\
The following table details the meaning of each bit as well as the default values:
ms430580mCfgprotocolSelect
Bit Default
value
Bit 3-0 0000
Bit 7-4 0000
Bit 15-8 00000000
How to modify the Configuration
The following procedure outlines how to modify any configuration. This can be
performed at any time, keeping in mind that the cold reset will affect the traffic.
Note
This is module type dependant. Consu lt the table in the Description section
to determine if it is applicable or not. The following modifications may be
achieved by using control objects in:
...\microsens\modulems430580m\ms430580mcontrolsWrite\
However modifications made in this way are lost following a reset.
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
Bit Name
Line 2 SFP Laser Off
Reserved
Reserved
Bit Name
Line 1 and Line 2 bitrate
Reserved
Reserved
Description
Line 2 SFP Laser state:
0: SFP Laser ON
1: SFP Laser OFF
Set to Default value
Set to Default value
Description
Bitrate selection
0: 2.488 Gb/s (OC-48/STM16)
1: 1.25 Gb/s (GbE)
2: 622.08 Mb/s (OC-12/STM4)
3: 155.52 Mb/s (OC-3/STM1)
4: 2.125 Gb/s (2GFC)
5: 1.0625 Gb/s (1GFC)
7: 125 Mb/s (Fast Ethernet)
8: 2,666 Mb/s (OC-48/STM16-FEC)
9: 666.51 Mb/s (OC-12/STM4-FEC)
10: 166.62 Mb/s (OC-3/STM1-FEC)
Set to Default value
Set to Default value
