Media Converter/Signal Repeater
OID
1.3.6.1.4.1.20044.21.2.3.1.28.8
1.3.6.1.4.1.20044.21.2.3.1.28.15
1.3.6.1.4.1.20044.21.2.3.1.28.16
1.3.6.1.4.1.20044.21.2.3.1.31
1.3.6.1.4.1.20044.21.2.3.1.31.1
1.3.6.1.4.1.20044.21.2.3.1.31.2
1.3.6.1.4.1.20044.21.2.3.1.31.3
1.3.6.1.4.1.20044.21.2.3.2
1.3.6.1.4.1.20044.21.2.3.2.26
1.3.6.1.4.1.20044.21.2.3.2.26.1
1.3.6.1.4.1.20044.21.2.3.2.26.2
1.3.6.1.4.1.20044.21.2.3.2.26.3
1.3.6.1.4.1.20044.21.2.3.2.26.4
1.3.6.1.4.1.20044.21.2.3.2.26.7
1.3.6.1.4.1.20044.21.2.3.2.26.8
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
Name
ms430580mAlmLine2TempHighWng
ms430580mAlmLine2RxPwrLowWng
ms430580mAlmLine2RxPwrHighWng
ms430580mAlmline2CdrAlm
ms430580mAlmLine2CdrLossofsignal
ms430580mAlmLine2CdrLossoflock
ms430580mAlmLine2CdrRefAbsent
ms430580mAlmLineUrg
ms430580mAlmline2TrscvAlmDdm
ms430580mAlmLine2TxPwrLowAla
ms430580mAlmLine2TxPwrHighAla
ms430580mAlmLine2TxBiasLowAla
ms430580mAlmLine2TxBiasHighAla
ms430580mAlmLine2TempLowAla
ms430580mAlmLine2TempHighAla
Access Description
r TRSCV 2 Temp High warning:
Warning indicating that the
transceiver temperature of Line 2 is
higher than the threshold value
written in the transceiver EEPROM
r TRSCV 2 Rx Power Low warning:
Warning indicating that the
transceiver input power of Line 2 is
lower than the threshold value
written in the transceiver EEPROM
r TRSCV 2 Rx Power High warning:
Warning indicating that the
transceiver input power of Line 2 is
higher than the threshold value
written in the transceiver EEPROM
r Line 2 CDR Loss of Signal :This OID
indicates that a Loss of electrical
signal is detected on the Line 2 CDR
r Line 2 CDR Loss of Lock :This OID
indicates that the Line 2 CDR is not
locked
r Line 2 CDR Reference clock absent:
This OID indicates that the CDR
reference clock is absent on Line 2
r TRSCV 2 Tx Power Low: Alarm
indicating that the transceiver
output power of Line 2 is lower than
the threshold value written in the
transceiver EEPROM
r TRSCV 2 Tx Power High: Alarm
indicating that the transceiver
output power of Line 2 is higher
than the threshold value written in
the transceiver EEPROM
r TRSCV 2 Bias Low: Alarm indicating
that the transceiver laser bias current
of Line 2 is lower than the threshold
value written in the transceiver
EEPROM
r TRSCV 2 Bias High: Alarm indicating
that the transceiver laser bias current
of Line 2 is higher than the threshold
value written in the transceiver
EEPROM
r TRSCV 2 Temp Low: Alarm indicating
that the transceiver temperature of
Line 2 is lower than the threshold
value written in the transceiver
EEPROM
r TRSCV 2 Temp High: Alarm
indicating that the transceiver
temperature of Line 2 is higher than
the threshold value written in the
transceiver EEPROM
page 24/29
