Media Converter/Signal Repeater
NAME
ms430580mAlmLine1RxPwrHighWng
ms430580mAlmLine1CdrLossofsignal
ms430580mAlmLine1CdrLossoflock
ms430580mAlmLine1CdrRefAbsent
ms430580mAlmLine1TxPwrLowAla
ms430580mAlmLine1TxPwrHighAla
ms430580mAlmLine1TxBiasLowAla
ms430580mAlmLine1TxBiasHighAla
ms430580mAlmLine1TempLowAla
ms430580mAlmLine1TempHighAla
ms430580mAlmLine1RxPwrLowAla
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
DESCRIPTION
TRSCV 1 Rx Power High
warning: Warning indicating
that the transceiver input power
of Line 1 is higher than the
threshold value written in the
transceiver EEPROM
Line 1 CDR Loss of Signal: This
OID indicates that a Loss
of electrical signal is detected
on the Line 1 CDR
Line 1 CDR Loss of Lock: This
OID indicates that the Line 1
CDR is not locked
Line 1 CDR Reference clock
absent: This OID indicates that
the CDR reference clock is
absent on Line 1
TRSCV 1 Tx Power Low: Alarm
indicating that the transceiver
output power of Line 1 is lower
than the threshold value written
in the transceiver EEPROM
TRSCV 1 Tx Power High: Alarm
indicating that the transceiver
output power of Line 1 is higher
than the threshold value written
in the transceiver EEPROM
TRSCV 1 Bias Low :Alarm
indicating that the transceiver
laser bias current of Line 1 is
lower than the threshold value
written in the transceiver
EEPROM
TRSCV 1 Bias High: Alarm
indicating that the transceiver
laser bias current of Line 1 is
higher than the threshold value
written in the transceiver
EEPROM
TRSCV 1 Temp Low: Alarm
indicating that the transceiver
temperature of Line 1 is lower
than the threshold value written
in the transceiver EEPROM
TRSCV 1 Temp High: Alarm
indicating that the transceiver
temperature of Line 1 is higher
than the threshold value written
in the transceiver EEPROM
TRSCV 1 Rx Power Low: Alarm
indicating that the transceiver
input power of Line 1 is lower
than the threshold value written
in the transceiver EEPROM
page 10/29
ACTION
Correlate all warnings. Carry out
necessary maintenance
procedures.
Check client status. Carry out
necessary maintenance
procedures.
Check client status. Carry out
necessary maintenance
procedures.
No action information only.
Correlate all. Carry out necessary
maintenance procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Correlate all Alarms. Carry out
necessary maintenance
procedures.
