Media Converter/Signal Repeater
NAME
ms430580mAlmLine1RxPwrHighAla
ms430580mAlmLine1TrscvAbsent
ms430580mAlmLine1TrscvDdmAbsent
ms430580mAlmLine1HwFail
ms430580mAlmLine1TrscvLsd
ms430580mAlmLine1TrscvDdmWarning
ms430580mAlmLine1TrscvDdmAlm
ms430580mAlmLine1Fail
ms430580mAlmLine1LasFail
ms430580mAlmLine1Los
ms430580mAlmLine2TxPwLowWng
ms430580mAlmLine2TxPwrHighWng
MICROSENS GmbH & Co. KG - Küferstraße 16 - 59067 Hamm - Tel. +49 2381/9452 0 - Fax 9452 100 - www.microsens.com
DESCRIPTION
TRSCV 1 Rx Power High: Alarm
indicating that the transceiver
input power of Line 1 is higher
than the threshold value written
in the transceiver EEPROM
Line 1 SFP not plugged: This
OID indicates that the
transceiver module 2 is not
present.
DDM supported on Line 1 SFP:
This OID indicates that the
transceiver module 1 does not
support Digital Diagnostic
Monitoring Functions
Line 1 HW Failure: This OID
indicates a hardware failure on
the Line 1
Line 1 SFP optical TX ON: This
OID indicates the optical output
power is off on Line 1
Warning DDM on Optical
Module 1: This OID indicates a
warning is present coming out
of optical interface DDM on
Line 1
Alarm DDM on Optical Module
1: This OID indicates an alarm is
present coming out of optical
interface DDM on Line 1
Line 1 Failure: This OID
indicates a failure on the Line 1
Line 1 SFP Tx Failed: This OID
indicates that the transmitter
fails for the transceiver plugged
into the Line 1 (this alarm
reports the transmitter failure
alarm generated by the
transceivers)
Loss of Optical signal on Line 1:
This OID indicates that no signal
is present on thetransceiver 1
TRSCV 2 Tx Power Low warning:
Warning indicating that the
transceiver output power of
Line 2 is lower than the
threshold value written in the
transceiver EEPROM
TRSCV 2 Tx Power High
warning :Warning indicating
that the transceiver output
power of Line 2 is higher than
the threshold value written in
the transceiver EEPROM
page 11/29
ACTION
Correlate all Alarms. Carry out
necessary maintenance
procedures.
Plug in the Optical Module. If
Alarm
persists change the optical
component.
If SFP supports DDM change the
SFP, else ignore.
Correlate relevant alarms. Carry
out
necessary maintenance
procedures.
No action information only.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all alarms. Carry out
necessary maintenance
procedures.
Correlate relevant alarms. Carry
out necessary maintenance
procedures.
Correlate relevant alarms. If
Alarm
persists replace the Client SFP.
Check client status. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
Correlate all warnings. Carry out
necessary maintenance
procedures.
