Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual, Service Manual
Edition: July 3, 2007
™
Lexmark
X850e, X852e, & X854e Finisher
7500-XXX
• Table of contents
• Start diagnostics
• Safety and notices
• Trademarks
• Index
Lexmark and Lexmark with diamond design are
trademarks of Lexmark International, Inc., registered
in the United States and/or other countries.

Advertisement

Table of Contents
loading

Related Manuals for Lexmark X850e

Summary of Contents for Lexmark X850e

  • Page 1 X850e, X852e, & X854e Finisher 7500-XXX • Table of contents • Start diagnostics • Safety and notices • Trademarks • Index Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
  • Page 2 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company.

  • Page 3: Table Of Contents

    7500-XXX Table of contents Table of contents ............iii Notices and safety information .
  • Page 4 7500-XXX Media sizes that allow stapling ..........1-23 Stapling one sheet .
  • Page 5 7500-XXX 983.00 Sensor (rear tamper HP) late error ......... . . 2-56 983.01 Sensor (rear tamper HP) lag error .
  • Page 6 7500-XXX Serial Number ............. .3-10 Engine Setting 1 to 4 .
  • Page 7 7500-XXX Sensor (punch carriage shift HP) removal ......... . 4-51 Sensor (punch waste box set) removal .
  • Page 8 7500-XXX Booklet unit gear train frame removal ..........4-128 Booklet unit assembly left cover .
  • Page 9 7500-XXX Parts catalog ................How to use this parts catalog .
  • Page 10 7500-XXX MFP Finisher Service Manual...

  • Page 11: Notices And Safety Information

    7500-XXX Notices and safety information The following laser notice labels may be affixed to this printer. Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1.
  • Page 12 7500-XXX Avisos sobre el láser Se certifica que, en los EE.UU., esta impresora cumple los requisitos para los productos láser de Clase I (1) establecidos en el subcapítulo J de la norma CFR 21 del DHHS (Departamento de Sanidad y Servicios) y, en los demás países, reúne todas las condiciones expuestas en la norma IEC 60825-1 para productos láser de Clase I (1).
  • Page 13 7500-XXX Laserilmoitus Tämä tulostin on sertifioitu Yhdysvalloissa DHHS 21 CFR Subchapter J -standardin mukaiseksi luokan I (1) - lasertuotteeksi ja muualla IEC 60825-1 -standardin mukaiseksi luokan I lasertuotteeksi. Luokan I lasertuotteita ei pidetä haitallisina. Tulostimen sisällä on luokan IIIb (3b) laser, joka on nimellisteholtaan 5 mW:n galliumarsenidilaser ja toimii 770 - 795 nanometrin aallonpituuksilla.
  • Page 14 7500-XXX Avís sobre el Làser Segons ha estat certificat als Estats Units, aquesta impressora compleix els requisits de DHHS 21 CFR, apartat J, pels productes làser de classe I (1), i segons ha estat certificat en altres llocs, és un producte làser de classe I que compleix els requisits d’IEC 60825-1.
  • Page 15 7500-XXX Notices and safety information...
  • Page 16 7500-XXX MFP Finisher Service Manual...

  • Page 17: Safety Information

    7500-XXX Safety information • The safety of this product is based on testing and approvals of the original design and specific components. The manufacturer is not responsible for safety in the event of use of unauthorized replacement parts. • The maintenance information for this product has been prepared for use by a professional service person and is not intended to be used by others.
  • Page 18 7500-XXX Sicherheitshinweise • Die Sicherheit dieses Produkts basiert auf Tests und Zulassungen des ursprünglichen Modells und bestimmter Bauteile. Bei Verwendung nicht genehmigter Ersatzteile wird vom Hersteller keine Verantwortung oder Haftung für die Sicherheit übernommen. • Die Wartungsinformationen für dieses Produkt sind ausschließlich für die Verwendung durch einen Wartungsfachmann bestimmt.
  • Page 19 7500-XXX Informació de Seguretat • La seguretat d'aquest producte es basa en l'avaluació i aprovació del disseny original i els components específics. El fabricant no es fa responsable de les qüestions de seguretat si s'utilitzen peces de recanvi no autoritzades. •...

  • Page 20: Preface

    7500-XXX Preface This manual contains maintenance procedures for service personnel. It is divided into the following chapters: General information contains a general description of the printer and the maintenance approach used to repair it. Special tools and test equipment, as well as general environmental and safety instructions, are discussed.

  • Page 21: General Information

    The optional finisher staples, punches, folding and stapling, and stacks media transferred from the Lexmark™ X850e, X852e, and X854e. Output is stacked in the upper media bin or separately collated in the stacker media bin or folded and stapled in the booklet bin.

  • Page 22: Media Path Overview

    7500-XXX Media path overview Media size and weight The following shows media sizes and weights that the finisher can handle, as well as applicable functions for each media size. The printer and the finisher handle different media sizes and weights. For this reason, if the printer has printed media that the finisher cannot handle, the exit 1 diverter gate in the printer is switched to eject the media from Exit 2 onto the bridge unit assembly.

  • Page 23: Media Weight

    7500-XXX a(2) 257 x 364 mm a(2,3,4) 297 x 420 mm a(2,3,4) Ledger 11 x 17 in. Custom size Same width with standard size Custom size Besides above Numbers (2,3,4) mean 2 holes, 3 holes, and 4 holes, respectively. Applicable within the following range: Media width: 203.2—297 mm Media length: 182—431.8 mm Media weight...

  • Page 24: Finisher Theory

    7500-XXX Finisher theory Media transport This section describes the transfer of media from the printer to a specified bin. The following figures illustrate layouts (front view) of sensors, rollers, and main blocks, as well as a layout (rear view) of the main components. Bridge unit assembly paper path To finisher From printer...

  • Page 25: Finisher Roll Assemblies

    7500-XXX Finisher roll assemblies Upper Media Exit Roll Assembly- Upper Media Transport Roll Assembly – driven by motor (exit) driven by drive motor (buffer/transport) Finisher Diverter Gate Finisher Media Entrance Roll Assembly – driven by Sub Paddle – drive motor (entrance paddle) driven by drive motor (entrance/paddle) Eject Clamp –...

  • Page 26: Finisher Media Path Sensors

    7500-XXX Finisher media path sensors Sensor (upper media) Sensor (diverter gate) Sensor (upper media bin full) Sensor Sensor (lower media exit) (media entrance) Sensor (buffer path) Sensor (booklet media entrance) Sensor (lower media exit) Sensor (booklet media exit) Sensor (booklet bin media present) Sensor (booklet compiler media in) MFP Finisher Service Manual...

  • Page 27: Finisher Motors

    7500-XXX Finisher motors Drive motor (exit) Drive motor Media eject clamp motor (buffer/transport) Finisher diverter gate solenoid Media eject motor assembly Buffer diverter solenoid Drive motor (entrance paddle) Stacker bin lift motor assembly Bridge unit assembly When the printer designates the finisher, the media diverter gate in the printer activates, and media is fed from the printer into the bridge unit assembly.

  • Page 28: From Bridge Unit Assembly To Punch

    7500-XXX From bridge unit assembly to punch The media fed from the bridge unit assembly is fed into the finisher by the media entrance roll assembly located on the entrance section of the finisher which is driven by the drive motor (entrance/paddle). The media route inside the finisher is determined by the finisher diverter gate.

  • Page 29: From Punch To Compiler Unit Assembly

    7500-XXX From punch to compiler unit assembly The media is transferred to the compiler unit assembly by the buffer roll assembly (driven by the motor (buffer/ transport)) and by the lower media exit roll assembly (driven by the drive motor (exit)). When the first media reaches the compiler unit assembly, the media eject clamp motor is activated to lower the media eject clamp so that the media eject clamp and the media eject shaft assembly can clamp the media.
  • Page 30 7500-XXX Sensor (lower media exit) Sub paddle—driven by drive motor (entrance/paddle) Eject clamp—driven Buffer roll assembly— by eject clamp motor driven by drive motor (buffer/transport) Media eject shaft assembly— driven by media eject motor asm Buffer diverter Compiler unit assembly Main paddle Lower media exit motor—driven by...

  • Page 31: From Compiler Unit Assembly To Stacker Media Bin

    7500-XXX From compiler unit assembly to stacker media bin Stapled media on the compiler unit assembly (stapling mode) or aligned media (non-stapling mode) are held between the media eject clamp and the media eject shaft assembly. The media eject shaft assembly is driven by the media eject motor assembly to transfer media to the stacker media bin.

  • Page 32: Finisher

    7500-XXX Finisher • Sensor (finisher media entrance) — A photo-reflective sensor detects whether media is fed from the bridge unit assembly to the finisher — It turns high (+5 V dc) while media is present within the sensing area. — When the level turns high due to the first media of the second set during multi-set printing, this sensor activates the buffer diverter solenoid to switch the buffer diverter gate so that the media goes in the buffer roll assembly’s circumferential direction.

  • Page 33: Punch Unit

    7500-XXX Punch unit This section describes the media punching operation of the punch. Two types of punch are provided: the 2/3-hole type and the 2/4-hole type. The following explains the 2/3-hole type (2-hole/3-hole auto-switching). Every type has the same construction, except for the sensor (punch hole select) that is provided for the 2-hole type and 3-hole type only.

  • Page 34: Punching

    7500-XXX Punching After punching positions are determined, the punch unit motor is activated to move the cam plate. With the movement of the cam plate, the pins descend along the guide holes to punch the media. This operation is performed for each sheet of media. The cam plate can lower the pins even while it is moving to the front or rear side.

  • Page 35: Detecting Punch Waste Full

    7500-XXX Detecting punch waste full Punch waste is stored in the punch waste box. A sensor is provided to detect punch waste full. When punch waste full is detected, it is notified to the operator only once. Even if punch waste is not removed, the finisher can still punch media. However, it can spread punch waste inside the machine.

  • Page 36: Compiler Unit Assembly

    7500-XXX • Sensor (punch waste box set) — A photo-interrupter sensor that detects whether the waste box is properly set — When the punch waste box is properly set, the actuator of the box blocks the light transmission of the sensor, which turns the sensor to high (+5 V dc).

  • Page 37: Capacity Of Compiler Unit Assembly

    7500-XXX Capacity of compiler unit assembly Media volume that can be stacked on the compiler unit assembly is limited as shown in the table below. The number of sheets depends on whether media is stapled or not, as well as on media size. If the number of sheets of one set to be stapled exceeds the limit, the exceeding sheets are not stacked on the compiler unit assembly, and are forcibly ejected to the stacker media bin without being stapled.

  • Page 38: Front Tamping

    7500-XXX Front tamping Front tamping is used in the following cases. • In the non-staple mode • When executing front stapling (corner) The tamper positions during front tamping are shown below. Sensor (rear tamper HP) Sensor (front tamper HP) Rear Front Front tamper motor Rear tamper...

  • Page 39: Rear Tamping

    7500-XXX Rear tamping Rear tamping is used in the following cases. • When executing rear stapling (corner) • When executing dual stapling The tamper positions during rear tamping are shown below. Sensor (rear tamper HP) Sensor (front tamper HP) Rear Front Front tamper motor Front tamper...

  • Page 40: Center Tamping

    7500-XXX Center tamping Center tamping is used when executing rear stapling (straight). The tamper positions during center tamping are shown below. Sensor (front tamper HP) Sensor (rear tamper HP) Front Rear Front tamper motor Front tamper Rear tamper Rear tamper motor Position Description Front tamper home position–sensor (front tamper HP)

  • Page 41: Offsetting

    7500-XXX Offsetting Offsetting is an operation to shift the position of media to be ejected to the stacker media bin so that boundaries between media units (sets of media, job units, etc.) can be easily recognized. Offsetting is executed for staple positions: •...

  • Page 42: Stapler

    7500-XXX • Rear tamper motor — A stepping motor that moves the rear tamper for tamping — Clockwise rotation of this motor moves the rear tamper to the front side. Counterclockwise rotation of this motor moves the tamper to the rear side. Rear tamper Front tamper Sensor (rear...

  • Page 43: Media Sizes That Allow Stapling

    7500-XXX • Rear Staple (Straight) [rear straight] Rear This type of stapling is applied for media with a width of less than 216 mm. The Stapler staples a set of media in parallel with the media edge after the front tamper aligns the media to the rear side.

  • Page 44: Stapling Multiple Size Media

    7500-XXX Stapling multiple size media When sheets with different sizes and the same width (example: A4L and A3S) are present on the compiler unit assembly, all the sheets are stapled and then ejected to the stacker media bin. When sheets with different widths are present on the compiler unit assembly, stapling is stopped when a different width is detected.

  • Page 45: Stapler Unit Assembly

    7500-XXX Stapler unit assembly The stapling operation is executed by closing the stapler unit assembly. The stapler unit assembly, containing the staple motor, the sensor (staple home), the sensor (self priming), and the sensor (low staple), is activated by the staple motor. Forward (clockwise) rotation of the motor drives the stapler to staple a set of sheets, and returns the stapling unit to the home position.

  • Page 46: Booklet Operation

    7500-XXX • Stapler unit motor (in the stapler unit assembly) — A DC motor to activate the stapler unit assembly for stapling — Clockwise rotation of this motor enables stapling, while counterclockwise rotation returns the stapler unit assembly. Stapler carriage motor asm Stapler rack gear Sensor (stapler carriage HP)

  • Page 47: Functions Of Booklet Sensors And Motors

    7500-XXX Functions of booklet sensors and motors • Sensor (booklet media entrance) — This photo sensor detects the media delivery to the booklet unit. • Sensor (booklet media exit) — This photo sensor detects paper delivery to booklet media bin. •...
  • Page 48 7500-XXX • Booklet knife solenoid — This solenoid transfers the booklet folding/exit drive motor assembly to the knife through the gear. Booklet media Sensor (booklet entrance roll media entrance) assembly Booklet media entrance drive motor Booklet folding roll assembly Booklet media exit roll assembly Sensor (booklet media exit roll assembly)

  • Page 49: Booklet Media Bin

    7500-XXX • Sensor (booklet drawer interlock) — This photo sensor detects when the booklet unit is set. • Sensor (booklet bin media present) — This photo sensor detects paper availability on the booklet media bin. If 15 sets of printouts are detected in the booklet media bin, it will be considered as Full Stack.

  • Page 50: Stacker Media Bin

    7500-XXX Stacker media bin The stacker media bin goes up and down to an appropriate position according to the volume of media fed from the compiler unit assembly so as to properly stack media to a full stack. Operation The stacker media bin moves to an appropriate position according to the volume of media fed from the compiler unit assembly.
  • Page 51 7500-XXX The stacker media bin lowers according to the volume of media it contains. If any obstacle under the tray hinders the tray from lowering, the stacker lower safety warning is detected, and the stacker media bin is stopped. Eject clamp motor Sensor (stacker bin level 1) Sensor (media eject clamp HP)

  • Page 52: Full Stack Detection

    7500-XXX Full stack detection A full stack is detected when media in the stacker media bin becomes full to prevent media jam or falling of media to the floor. The stacker media bin can stack up to approximately 3000 sheets. The media volume in the stacker media bin is detected at every 10% (approximately 300 sheets) and notified to the Controller.
  • Page 53 7500-XXX — A photo-interrupter sensor that detects that the stacker media bin is at the highest position; it also detects no media. — When the actuator attached to the carriage assembly right enters the sensing area, the emitted light is blocked, which turns the sensor to high (+5 V).

  • Page 54: Booklet Tray

    7500-XXX Booklet tray Paper is folded into two by the booklet folding roll driven by the booklet Fold Roll Motor and booklet Eject Roll, and delivered to the booklet tray. Booklet tray is at a position lower than the paper delivery exit. Paper delivery belt will move at fixed interval for every set of output.
  • Page 55 7500-XXX • Switch (eject cover interlock)–Turns off when the cover eject on the right side opens, shutting off the Interlock +24 V dc line in the finisher. Switch (eject cover interlock) Switch (finisher front door interlock) Finisher controller card asm Sensor +5 V dc Switch...

  • Page 56: Tools Required For Service

    7500-XXX Tools required for service Flat-blade screwdriver #1 Phillips screwdriver, magnetic #2 Phillips screwdriver, magnetic #2 Phillips screwdriver, magnetic short-blade Needle nose pliers Diagonal side cutters Spring hook 5.5 mm hex driver, magnetic Analog or digital multi-meter Parallel wrap plug 1319128 Twinax/serial debug cable 1381963 Coax/serial debug cable 1381964 Acronyms...
  • Page 57 7500-XXX Power-on Reset POST Power-on Self Test Pages Per Minute Parallel Synchronous Communications Position Sensing Device Pulse Width Modulation RFID Radio Frequency Identification Raster Imaging Processor Read only Memory Revolutions Per Minute SDRAM Synchronous Dual Random Access Memory Short Edge Feed SIMM Single Inline Memory Module Start of scan...
  • Page 58 7500-XXX 1-38 MFP Finisher Service Manual...

  • Page 59: Diagnostic Information

    7500-XXX 2. Diagnostic information Start CAUTION: Unplug the power cord from the electrical outlet before you connect or disconnect any cable electronic board or assembly. CAUTION If the printer is kept on, never touch the conductive parts if not specifically required. The power switch and inlet of the low voltage power supply card (LVPS card) assembly is live even while the power supply is cut off.

  • Page 60: Por (Power-On Reset) Sequence

    7500-XXX POR (Power-On Reset) sequence The following is an example of the events that occur during the POR sequence for the base machine with no paper handling options installed. 1. Turn the machine on. 2. +5V LED (Power ON) on the system board comes on. 3.

  • Page 61: Error Code Messages - Finisher

    7500-XXX Error code messages - finisher Error code or Error contents Description/action message 280.00 Sensor (bridge unit media The media is late reaching the sensor (bridge unit media entrance) late jam entrance) within the specified time after reaching the Paper jam sensor (fuser exit).
  • Page 62 7500-XXX Error code or Error contents Description/action message 285.00 Sensor (compiler media in) lag The media reached the sensor (lower media exit) but did not clear it within the specified time. Paper jam Go to “285.00 Sensor (media compiler in) lag jam” on page 2-27.
  • Page 63 7500-XXX Error code or Error contents Description/action message 289.04 sensor (booklet unit media exit) The media is late reaching the sensor (booklet unit late jam media exit) within the specified time after the booklet Paper jam knife solenoid is turned on. Go to “289.04 Sensor (booklet unit media exit) late jam”...
  • Page 64 7500-XXX Error code or Error contents Description/action message 983.01 Sensor (rear tamper HP) lag The sensing area of the sensor (rear tamper HP) error remains interrupted within the specified time after the Service finisher rear tamper starts moving from the home position. error Go to “983.01 Sensor (rear tamper HP) lag error”...
  • Page 65 7500-XXX Error code or Error contents Description/action message 989.00 Stapler unit error The sensing area of the sensor (stapler unit motor HP) inside the stapler unit assembly is not interrupted within Service finisher the specified timer after the stapler unit motor starts error moving to the home position.
  • Page 66 7500-XXX Error code or Error contents Description/action message 991.07 Sensor (booklet compiler no The sensing area of the sensor (booklet compiler no media) no media detected media) did not detect any media when the booklet Service finisher stapler motor was activated. error Go to “991.07 Sensor (booklet compiler no media) no...
  • Page 67 7500-XXX Error code or Error contents Description/action message Remove paper Finisher upper media bin full. Stacker set over count from bin 1 The upper media bin has reached maximum capacity. Go to “Finisher upper media bin full” on page 2-93. Remove paper Stacker media bin full (no mix) The stacker media bin has reached maximum capacity...

  • Page 68: Service Checks - Finisher

    7500-XXX Service checks - finisher 280.00 Sensor (bridge unit media entrance) late Jam Step Check Check the bridge unit media transport rolls. Go to step 2. Clean or replace the bridge unit Are the bridge unit media transport rolls free of excess assembly.

  • Page 69: Sensor (Bridge Unit Media Entrance) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. bridge unit Does the error remain? interface card assembly. Go to “Bridge unit interface card assembly removal” on page 4-115. Go to step 7. Perform a print test. Replace the Problem solved.

  • Page 70: Sensor (Bridge Unit Media Exit) Late Jam

    7500-XXX Step Check Check the bridge unit drive motor for proper operation. Go to step 5. Go to step 4. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 71 7500-XXX Step Check Check the sensor (bridge unit media exit) for proper Go to step 4. Go to step 3. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 1. 5. Touch Bridge unit media exit. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 72: Sensor (Bridge Unit Media Exit) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 281.03 Sensor (bridge unit media exit) static jam Step Check Check the sensor (bridge unit media exit) for proper Go to step 4.

  • Page 73: Sensor (Finisher Media Entrance) Late Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. bridge unit Does the error remain? interface card assembly. Go to “Bridge unit interface card assembly removal” on page 4-115. Go to step 6. Perform a print test. Replace the Problem solved.
  • Page 74 7500-XXX Step Check Check the sensor (finisher media entrance) for proper Go to step 6. Go to step 5. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 1. 5. Touch Finisher media entrance. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 75: Sensor (Finisher Media Entrance) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 282.01 Sensor (finisher media entrance) static jam Step Check Check the sensor (finisher media entrance) for proper Go to step 3.

  • Page 76: Sensor (Buffer Path) Late Jam

    7500-XXX Step Check Check the drive motor (entrance/paddle) for proper Replace the drive Replace the connection. motor (entrance/ connection. paddle). Is the above component properly connected? Go to “Drive motor (entrance/ paddle) and belt (entrance/ paddle) removal” on page 4-99. Perform a print test.
  • Page 77 7500-XXX Step Check Check the sensor (diverter gate) for proper connection. Replace the Replace the sensor (diverter connection. Is the above component properly connected? gate). Go to “Sensor (diverter gate) removal” on page 4-108. Check the buffer diverter gate solenoid for proper Go to step 7.
  • Page 78 7500-XXX Step Check Check the drive motor (buffer/transport) for proper Go to step 11. Go to step 10. operation. 1. Enter the Diagnostics Menu. 2. Touch MOTOR TESTS. 3. Touch Finisher Motor Tests. 4. Touch Motor (buffer/transport). Does the above component operate properly? Check the drive motor (buffer/transport) for proper Replace the drive Problem solved.

  • Page 79: Sensor (Buffer Path) Static Jam

    7500-XXX 283.03 Sensor (buffer path) static jam Step Check Check the sensor (buffer path) for proper operation. Go to step 3. Go to step 2. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1.

  • Page 80: Sensor (Lower Media Exit) Late Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 284.00 Sensor (lower media exit) late jam Step Check Check the finisher buffer roll assembly. Go to step 2.
  • Page 81 7500-XXX Step Check Check the drive motor (buffer/transport) for proper Replace the drive Replace the connection. motor (buffer/ connection. transport). Is the above component properly connected? Go to “Drive motor (buffer/ transport) and belt (buffer/ transport) removal” on page 4-113. Check the sensor (diverter gate) for proper operation.

  • Page 82: Sensor (Lower Media Exit) Lag Jam

    7500-XXX 284.03 Sensor (lower media exit) lag jam Step Check Check the lower media exit roll assembly. Go to step 2. Clean or replace the lower media Is the above component free of excess wear and exit roll assembly. contamination? “Lower Go to media exit roll...

  • Page 83: Sensor (Lower Media Exit) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 284.05 Sensor (lower media exit) static jam Step Check Check the sensor (lower media exit) for proper Go to step 3.
  • Page 84 7500-XXX Step Check Check the buffer diverter gate solenoid for proper Replace the Problem solved. connection. buffer diverter gate solenoid. Is the above component properly connected? Go to “Buffer diverter gate solenoid removal” on page 4-102. Check the drive motor (exit) for proper operation. Go to step 7.

  • Page 85: Sensor (Media Compiler In) Lag Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 285.00 Sensor (media compiler in) lag jam Step Check Check the media eject clamp motor for proper Go to step 3.

  • Page 86: Sensor (Compiler Media In) Static Jam

    7500-XXX Step Check Check the sensor (compiler media in) for proper Go to step 6. Go to step 5. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 1. 5. Touch Compiler media in. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?
  • Page 87 7500-XXX Step Check Check the sensor (compiler media in) for proper Go to step 5. Go to step 4. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 1. 5. Touch Compiler media in. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 88: Sensor (Upper Media Exit) Late Jam

    7500-XXX 287.00 Sensor (upper media exit) late jam Step Check Check the two upper media transport roll assemblies. Go to step 2. Clean or replace the two upper Are the two upper media transport roll assemblies free media transport of excess wear and contamination? roll assemblies.

  • Page 89: Sensor (Upper Media Exit) Lag Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 287.01 Sensor (upper media exit) lag jam Step Check Check the two upper media transport roll assemblies. Go to step 2.
  • Page 90 7500-XXX Step Check Check the drive motor (buffer/transport) for proper Go to step 6. Go to step 5. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2. Touch MOTOR TESTS. 3.

  • Page 91: Sensor (Upper Media Exit) Static Jam

    7500-XXX 287.05 Sensor (upper media exit) static jam Step Check Check the sensor (upper media exit) for proper Go to step 3. Go to step 2. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 92: Sensor (Diverter Gate) Late Jam

    7500-XXX 288.00 Sensor (diverter gate) late jam Step Check Check the finisher media entrance roll assembly. Go to step 2. Clean or replace the finisher Is the finisher media entrance roll assembly free of media entrance excess wear and contamination? roll assembly.
  • Page 93 7500-XXX Step Check Check the sensor (diverter gate) for proper operation. Go to step 8. Go to step 7. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 2. 5. Touch Diverter gate. Does the operator panel display change every time the actuator of the sensor (bridge unit media exit) is operated?

  • Page 94: Sensor (Diverter Gate) Static Jam A (To Top Bin)

    7500-XXX 288.01 Sensor (diverter gate) static jam A (to top bin) Step Check Check the sensor (diverter gate) for proper operation. Go to step 3. Go to step 2. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 95: Sensor (Diverter Gate) Static Jam B (To Stacker Bin)

    7500-XXX 288.04 Sensor (diverter gate) static jam B (to stacker bin) Step Check Check the sensor (diverter gate) for proper operation. Go to step 3. Go to step 2. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 96: Sensor (Booklet Unit Media Entrance) Late Jam

    7500-XXX 289.00 sensor (booklet unit media entrance) late jam Step Check Check the booklet unit interface connector assembly. Go to step 2. Replace the booklet unit Is the above component free of damage? interface connector assembly. Check the main connector on the booklet unit sensor Go to step 3.

  • Page 97: Sensor (Booklet Unit Media Entrance) Lag Jam

    7500-XXX Step Check Check the motor (entrance/paddle) for proper operation. Go to step 10. Go to step 9. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2. Touch MOTOR TESTS. 3.
  • Page 98 7500-XXX Step Check Check the main connector on the booklet unit motor Go to step 4. Replace the interface cable assembly. booklet unit motor interface cable Is the above component free of damage? assembly. Check the sensor (booklet unit media entrance) for proper Go to step 6.

  • Page 99: Sensor (Booklet Unit Media Entrance) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 289.02 sensor (booklet unit media entrance) static jam Step Check Check the booklet unit interface connector assembly. Go to step 2.

  • Page 100: Sensor (Booklet Compiler Media In) Static Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 289.03 sensor (booklet compiler media in) static jam Step Check Check the booklet unit interface connector assembly. Go to step 2.

  • Page 101: Sensor (Booklet Unit Media Exit) Late Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 289.04 Sensor (booklet unit media exit) late jam Step Check Check the booklet unit interface connector assembly. Go to step 2.
  • Page 102 7500-XXX Step Check Check the booklet knife solenoid for proper operation. Go to step 8. Go to step 7. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2. Touch MOTOR TESTS. 3.

  • Page 103: Sensor (Booklet Unit Media Exit) Lag Jam

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error remain? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 289.05 Sensor (booklet unit media exit) lag jam Step Check Check the booklet unit interface connector assembly. Go to step 2.

  • Page 104: Sensor (Booklet Unit Media Exit) Static Jam

    7500-XXX Step Check Check the booklet folding/exit drive motor for proper Go to step 8. Go to step 7. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.

  • Page 105: Finisher Communication Failure

    7500-XXX Step Check Check the sensor (booklet unit media exit) for proper Go to step 5. Go to step 4. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Booklet path 5. Touch Booklet unit media exit Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 106: Sensor (Stacker Bin Level 1) Late Error

    7500-XXX Step Check Check the finisher controller card assembly Replace the Replace the connection. finisher controller connection. card assembly. Are the connections of the finisher controller card assembly properly connected? Go to “Finisher controller card assembly removal” on page 4-116. Go to step 4.

  • Page 107: Stacker Bin Upper Limit Error

    7500-XXX Step Check Is the sensor (stacker bin level 2) connected properly. Replace the Replace the sensor (stacker connection. Is the above component properly connected? bin level 2). Go to “Sensor (stacker bin level 2) removal” on page 4-34. Check the stacker bin lift motor assembly for proper Go to step 8.
  • Page 108 7500-XXX Step Check Check the sensor (stacker bin level 1) for proper Replace the Replace the connection. sensor (stacker connection. bin level 1). Is the above component properly connected? Go to “Sensor (stacker bin level 1) removal” on page 4-34. Check the sensor (stacker bin level 2) for proper operation.

  • Page 109: Stacker Bin Lower Limit Error

    7500-XXX Step Check Check the stacker bin lift motor assembly for proper Go to step 10. Go to step 9. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 110 7500-XXX Step Check Check the sensor (stacker bin level 1) for proper operation. Go to step 6. Go to step 5. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Bin Level. 5. Touch Stacker bin level1. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 111: Sensor (Front Tamper Hp) Late Error

    7500-XXX Step Check Check the stacker bin lift motor assembly for proper Go to step 12. Go to step 11. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.

  • Page 112: Sensor (Front Tamper Hp) Lag Error

    7500-XXX Step Check Is the sensor (front tamper HP) properly connected? Replace the Replace the sensor (front connection. Is the above component properly connected? tamper HP). Go to “Sensor (front tamper HP) and sensor (rear tamper HP) removals” on page 4-71.
  • Page 113 7500-XXX Step Check Check the sensor (front tamper HP) for proper operation. Go to step 4. Go to step 3. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Media Path 2. 5. Touch Front tamper HP. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 114: Sensor (Rear Tamper Hp) Late Error

    7500-XXX 983.00 Sensor (rear tamper HP) late error Step Check Check the tamper mechanism by moving it manually. Go to step 2. Replace the media compiler unit Does the above component slide back and forth properly? assembly. Go to “Media compiler unit assembly removal”...

  • Page 115: Sensor (Rear Tamper Hp) Lag Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. finisher controller Does the error continue when the power is turned off/on? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 983.01 Sensor (rear tamper HP) lag error Step Check Check the tamper mechanism by moving it manually.

  • Page 116: Sensor (Punch Unit Hp) Late Error

    7500-XXX Step Check Check the compiler unit cable assembly for proper Replace the media Replace the connection. compiler unit connection. assembly. Is the above component properly connected? Go to “Media compiler unit assembly removal” on page 4-69. Perform a POR. Replace the Problem solved.

  • Page 117: Sensor (Punch Unit Hp) Lag Error

    7500-XXX Step Check Is the punch unit motor properly connected? Replace the punch Replace the unit motor connection. Is the above component properly connected? assembly. Go to “Punch unit motor assembly removal” on page 4-47. Perform a POR. Replace the Problem solved.

  • Page 118: Sensor (Punch Carriage Shift Hp) Late Error

    7500-XXX Step Check Is the punch unit motor properly connected? Replace the Replace the punch unit motor connection. Is the above component properly connected? assembly. Go to “Punch unit motor assembly removal” on page 4-47. Perform a POR. Replace the Problem solved.

  • Page 119: Sensor (Punch Carriage Shift Hp) Lag Error

    7500-XXX Step Check Check the punch carriage shift motor assembly for Go to step 6. Go to step 9. proper operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 120 7500-XXX Step Check Check the sensor (punch carriage shift HP) for proper Replace the Replace the connection. sensor (punch connection. carriage shift Is the above component properly connected? HP). Go to “Sensor (punch carriage shift HP) removal” on page 4-51. Check the punch carriage shift motor assembly for Go to step 6.

  • Page 121: Sensor (Media Eject Clamp Hp) Late Error

    7500-XXX 986.00 Sensor (media eject clamp HP) late error Step Check Check the sensor (media eject clamp HP) for proper Go to step 3. Go to step 2. operation. 1. Enter the Diagnostic Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 122: Sensor (Media Eject Clamp Hp) Lag Error

    7500-XXX 986.01 Sensor (media eject clamp HP) lag error Step Check Check the sensor (media eject clamp HP) for proper Go to step 3. Go to step 2. operation. 1. Enter the Diagnostic Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 123: Sensor (Media Eject Shaft Hp) Late Error

    7500-XXX 987.00 Sensor (media eject shaft HP) late error Step Check Check the sensor (media eject shaft HP) for proper Go to step 3. Go to step 2. operation. 1. Enter the Diagnostic Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4.

  • Page 124: Sensor (Media Eject Shaft Hp) Lag Error

    7500-XXX Step Check Check the media eject clutch assembly for proper Go to step 7. Go to step 6. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 125 7500-XXX Step Check Check the sensor (media eject shaft HP) for proper Replace the Replace the connection. sensor (media connection. eject shaft HP). Is the above component properly connected? Go to “Sensor (media eject shaft HP) removal” on page 4-79. Check the media eject motor assembly for proper Go to step 5.

  • Page 126: Sensor (Punch Unit Side Reg1) Or (Sensor (Punch Unit Side Reg2) Lag Failure

    7500-XXX Step Check Perform a POR. Replace the Problem solved. finisher controller Does the error continue when the power is turned off/ card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 988.01 Sensor (punch unit side reg1) or (sensor (punch unit side reg2) lag failure Note: This procedure pertains to sensor punch unit reg1 and reg2.
  • Page 127 7500-XXX Step Check Check the appropriate sensor (punch unit side reg pair) Replace the Replace the connection. appropriate connection. sensor (punch Is the above component properly connected? unit side reg pair). Go to “Sensor (punch unit side registration pair) with bracket removal”...

  • Page 128: Stapler Unit Failure

    7500-XXX 989.00 Stapler unit failure Step Check Check the stapler unit assembly for proper operation. Check for staples Go to step 2. and staple jams. Caution: When performing motor tests, Problem ensure that all cover and door interlock resolved. switches are overridden. Warning: Ensure there are no loose staples in the stapler unit after performing this test.

  • Page 129: Sensor (Stapler Carriage Hp) Lag Error

    7500-XXX Step Check Is the sensor (stapler carriage HP) properly Replace the Replace the connected? sensor (stapler connection. carriage HP). Is the above component properly connected? Go to “Sensor (stapler carriage HP) removal” on page 4-58. Check the stapler carriage motor assembly for proper Go to step 6.
  • Page 130 7500-XXX Step Check Check the sensor (stapler carriage HP) for proper Go to step 4. Go to step 3. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Punch and Staple. 5. Touch Stapler carriage shift HP. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 131: Sensor (Booklet Front Temper Hp) Late Error

    7500-XXX 991.00 Sensor (booklet front temper HP) late error Step Check Check the booklet unit interface connector assembly. Go to step 2. Replace the booklet unit Is the above component free of damage? interface connector assembly. Check the main connector on the booklet unit sensor Go to step 3.

  • Page 132: Sensor (Booklet Front Tamper Hp) Lag Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. booklet controller Does the error continue when the power is turned off/on? card assembly. Go to “Booklet controller card assembly removal ??” on page 4-121. Perform a POR. Replace the Problem solved.

  • Page 133: Sensor (Booklet Rear Tamper Hp) Late Error

    7500-XXX Step Check Check the booklet front tamper motor for proper operation. Go to step 6. Go to step 5. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 134 7500-XXX Step Check Check the booklet rear tamper by moving it manually. Go to step 5. Remove obstructions. Does the above component slide back and forth properly? Check the sensor (booklet rear tamper HP) for proper Go to step 7. Go to step 6.

  • Page 135: Sensor (Booklet Rear Tamper Hp) Lag Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. finisher controller Does the error continue when the power is turned off/on? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 991.03 Sensor (booklet rear tamper HP) lag error Step Check Check the booklet unit interface connector assembly.

  • Page 136: Sensor (Booklet End Guide Hp) Late Error

    7500-XXX Step Check Check the booklet rear tamper motor for proper operation. Go to step 6. Go to step 5. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.
  • Page 137 7500-XXX Step Check Check the booklet end guide by moving it manually. Go to step 5. Remove obstructions. Does the above component slide up and down properly? Check the sensor (booklet end guide HP) for proper Go to step 7. Go to step 6.

  • Page 138: Sensor (Booklet End Guide Hp) Lag Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. finisher controller Does the error continue when the power is turned off/on? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 991.05 Sensor (booklet end guide HP) lag error Step Check Check the booklet unit interface connector assembly.

  • Page 139: Sensor (Booklet Unit Interlock) Error

    7500-XXX Step Check Check the booklet end guide drive motor for proper Go to step 9. Go to step 8. operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.

  • Page 140: Sensor (Booklet Compiler No Media) No Media Detected

    7500-XXX Step Check Check the booklet unit assembly by opening it and closing Go to step 5. Remove obstructions. Does the above component slide open and close properly? Check the sensor (booklet unit interlock) for proper Go to step 7. Go to step 6.

  • Page 141: Sensor (Booklet Knife Hp) Late Error

    7500-XXX Step Check Check the sensor (booklet compiler media in) for proper Go to step 6. Go to step 5. operation. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Booklet Path 5. Touch Booklet compiler media in. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?
  • Page 142 7500-XXX Step Check Check the sensor (booklet knife HP) for proper operation. Go to step 6. Go to step 5. 1. Enter the Diagnostics Menu. 2. Touch FINISHER TESTS. 3. Touch Sensor Test. 4. Touch Booklet Path. 5. Touch Booklet knife HP. Does the display on the operator panel change every time the sensing area of the above sensor is interrupted or blocked?

  • Page 143: Sensor (Booklet Knife Hp) Lag Error

    7500-XXX Step Check Is the booklet folding/exit drive motor assembly properly Replace the Replace the connected? booklet folding/exit connection. drive motor Is the above component properly connected? assembly. Go to “Booklet folding/exit drive motor assembly removal” on page 4-122. Perform a POR. Replace the Problem solved.
  • Page 144 7500-XXX Step Check Is the sensor (booklet knife HP) properly connected? Replace the Replace the sensor (booklet connection. Is the above component properly connected? knife HP). Go to “Sensor (booklet knife HP) removal” on page 4-136. Check the booklet knife solenoid for proper operation. Go to step 8.

  • Page 145: Sensor (Booklet Knife Folding) Late Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. booklet controller Does the error continue when the power is turned off/on? card assembly. Go to “Booklet controller card assembly removal ??” on page 4-121. Perform a POR. Replace the Problem solved.

  • Page 146: Booklet Stapler Error

    7500-XXX Step Check Check the booklet folding/exit drive motor assembly for Go to step 8. Go to step 7. proper operation. Caution: When performing motor tests, ensure that all cover and door interlock switches are overridden. 1. Enter the Diagnostics Menu. 2.

  • Page 147: Communication Error With Booklet Controller Card Assembly

    7500-XXX Step Check Check the main connector on the booklet unit sensor Go to step 4. Replace the interface cable assembly. booklet unit sensor interface cable Is the above component free of damage? assembly. Check the main connector on the booklet unit motor Go to step 5.

  • Page 148: Booklet Unit Maker Error

    7500-XXX Step Check Perform a POR. Replace the Problem solved. finisher controller Does the error continue when the power is turned off/on? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. 991.13 Booklet unit maker error Step Check Perform a POR.
  • Page 149 7500-XXX Step Check Check the bridge unit top cover assembly on the bridge Reshape the Go to step 3. unit assembly for shape and operation. actuator so it fits into the cover Is the actuator of the bridge unit top cover assembly sensor.

  • Page 150: Finisher Front Door Open

    7500-XXX Finisher front door open Step Check Open and close the finisher front door assembly. Go to step 2. Check the finisher front door Does it open or close smoothly? assembly for installation, correct deformations, or replace it. Go to “Finisher front door assembly...

  • Page 151: Finisher Eject Cover Open

    7500-XXX Finisher eject cover open Step Check Check the switch (eject cover interlock) installation. Go to step 2. Reinstall the switch (media Is the switch (eject cover interlock) installed properly? eject cover). Check the operation of the switch (eject cover Go to step 4.

  • Page 152: No Punch Waste Box

    7500-XXX Step Check Is the sensor (upper media bin full) connected Replace the Replace the properly? sensor (upper connection. media bin full). Go to “Sensor (upper media bin full) removal” on page 4-106. Perform a print test. Replace the Problem solved. finisher controller Does the error still occur? card assembly.

  • Page 153: Punch Waste Box Full

    7500-XXX Step Check Perform a print test. Replace the Problem solved. bridge unit Does the error still occur? interface card assembly. Go to “Bridge unit interface card assembly removal” on page 4-115. Go to step 5. Perform a print test. Replace the Problem solved.

  • Page 154: Stacker Media Bin Full (Mix Size)

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error still occur? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. Stacker media bin full (mix size) Step Check Check the stacker bin for obstructions. Remove the Go to step 2.
  • Page 155 7500-XXX Step Check Is the sensor (stacker bin level 2) connected properly? Replace the Replace the sensor (stacker connection. bin level 2). Go to “Sensor (stacker bin level 2) removal” on page 4-34. Check the encoder of the sensor (stacker bin level Go to step 7.

  • Page 156: Stacker Media Bin Full (No Mix)

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error still occur? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. Stacker media bin full (no mix) Step Check Check the stacker bin for obstructions. Remove the Go to step 2.
  • Page 157 7500-XXX Step Check Is the sensor (stacker bin level 2) connected properly? Replace the Replace the sensor (stacker connection. bin level 2). Go to “Sensor (stacker bin level 2) removal” on page 4-34. Check the encoder of the sensor (stacker bin level Go to step 7.

  • Page 158: Stacker Lower Safety Failure

    7500-XXX Step Check Perform a print test. Replace the Problem solved. finisher controller Does the error still occur? card assembly. Go to “Finisher controller card assembly removal” on page 4-116. Stacker lower safety failure Step Check Check the vertical transport mechanism of the stacker Remove Go to step 2.

  • Page 159: Stacker Set Over Count Failure

    7500-XXX Step Check Check the sensor (stacker bin level 2) connection. Replace the Replace the sensor (stacker connection. Are the connections of the main sensor cable bin level 2). assembly properly connected? Go to “Sensor (stacker bin level 2) removal” on page 4-34.

  • Page 160: Staple Cartridge Empty

    7500-XXX Staple cartridge empty Step Check Check the staple cartridge for new and unused staples. Go to step 2. Refill the cartridge with Does the staple cartridge have a sufficient amount of new and unused new and unused staples? staples. Check the staple cartridge for correct installation.

  • Page 161: Diagnostic Aids

    7500-XXX 3. Diagnostic aids This chapter explains the tests and procedures to identify printer failures and to verify that repairs have corrected the problem. Accessing service menus Access the following menus to identify problems with the printer and run diagnostic tests. Diagnostics Menu 1.

  • Page 162: Diagnostics Menus

    7500-XXX Diagnostics Menus Entering Diagnostics Menus 1. Turn off the printer. 2. Press and hold the 3 and 6 buttons simultaneously. 3. Turn on the printer. 4. Release the buttons after 10 seconds. Available tests Tests appear on the LCD in the order shown: MOTOR TESTS “MOTOR TESTS”...
  • Page 163 7500-XXX OUTPUT BIN TESTS Feed to All Bins “Feed Tests (output bins)” on page 3-4. Feed Tests “Feed To All Bins” on page 3-5. FINISHER TESTS Staple Test “Staple Test” on page 3-5. Hole Punch Test “Hole Punch Test” on page 3-6.

  • Page 164: Motor Tests

    7500-XXX MOTOR TESTS The tests in this group allow you to test specific motors, and on some motors run them forward or reverse. To run the MOTOR TESTS: 1. Touch MOTOR TESTS from the Diagnostics Menu. 2. Touch the test to run. The following Finisher Motor Tests are available: •...

  • Page 165: Feed To All Bins

    7500-XXX Feed To All Bins This test can be used to verify that the printer can feed media to the standard bin or any installed output options. No information will be printed on the test pages, as the printhead is not engaged during the feed test. The media feeds from the default paper source.

  • Page 166: Hole Punch Test

    7500-XXX Hole Punch Test This test is used to verify that media can be fed to a finisher output bin and then hole punched. No information is printed on the feed test pages. To run the Hole Punch Test: 1. Touch FINISHER TESTS from the Diagnostics Menu. 2.
  • Page 167 7500-XXX Available Bin Level Sensors Sensor Name Fin upper bin full Stacker bin level1 Stacker bin level2 Stacker bin upper limit Stacker bin no media Stacker bin level encod Available Media Path 1 Sensors Sensor Name Bridge media ent Bridge media exit Fin media enter Buffer path Upper media exit...
  • Page 168 7500-XXX Available Booklet Path Sensors Sensor Name Booklet end guide HP Booklet knife HP Booklet knife folding Booklet front tamper HP Booklet rear tamper HP Booklet unit media entrance Booklet unit media exit Booklet bin media present Booklet compiler media in Booklet unit interlock Booklet front low staple Booklet rear low staple...

  • Page 169: Printer Setup

    7500-XXX PRINTER SETUP To enter the PRINTER SETUP screen, touch PRINTER SETUP from the Diagnostics Menu. The following graphic appears on the LCD: PRINTER SETUP U.S. Defaults Printed Page Count Perm Page Count Serial Number NV26T470 Medium Envelope Entrance Engine Setting 1 Back Submit Defaults...

  • Page 170: Printed Mono Page Count

    7500-XXX Printed Mono Page Count The value of this setting enables you to gauge the amount of usage on a device. The Printed Page Count cannot be reset by the servicer. Permanent Page Count The value of this setting indicates the total number of pages that have been printed by the printer. The Permanent Page Count cannot be reset.

  • Page 171: Event Log

    7500-XXX The Configuration ID setting allows you to set both Configuration IDs simultaneously. To set one or both Configuration IDs: 1. From the PRINTER SETUP menu, touch the icon to the right of the Configuration ID menu item. The screen displays the value of both Configuration IDs. By default, the cursor appears on the Configuration ID 1 line.

  • Page 172: Display The Event Log

    7500-XXX • Maintenance Count Resets • NV Resets and various types of JFFS@ partition formats Touch EVENT LOG from the Diagnostics Menu, and the following options are displayed: Display Log Print Log Clear Log Display the Event Log Note: The displayed version of the Event Log shows only a subset of the information contained in the Diagnostics version of the printed Event Log.

  • Page 173: Print The Event Log

    7500-XXX Print the Event Log Each page of the printed Event Log report has the title Event Log at the top of each page followed by the model name and serial number. The following is a sample of a printed Event Log: Model and Serial number XXX-XXXX...

  • Page 174: Finisher Config

    7500-XXX Booklet 2-sheet Booklet 2-sheet values appear on the LCD. If required reset the values and submit. Booklet 15-sheet Booklet 15-sheet values appear on the LCD. If required reset the values and submit. Booklet Fold Pos Fine Adj Booklet Staple Fold Fine Adjust values appear on the LCD.

  • Page 175: Exiting Diagnostics Menu

    7500-XXX Exiting Diagnostics Menu From the Diagnostics Menu, touch Back until a graphic appears with Exit Diag Menu in the lower right corner. Touch Exit Diag Menu to perform a POR, and the following graphic appears on the LCD: Copy E-Mail Menus Ready.
  • Page 176 7500-XXX 3-16 MFP Finisher Service Manual...
  • Page 177 7500-XXX 3-17 Diagnostic aids...
  • Page 178 7500-XXX 3-18 MFP Finisher Service Manual...
  • Page 179 7500-XXX 3-19 Diagnostic aids...
  • Page 180 7500-XXX 3-20 MFP Finisher Service Manual...
  • Page 181 7500-XXX 3-21 Diagnostic aids...
  • Page 182 7500-XXX 3-22 MFP Finisher Service Manual...
  • Page 183 7500-XXX 3-23 Diagnostic aids...
  • Page 184 7500-XXX 3-24 MFP Finisher Service Manual...
  • Page 185 7500-XXX 3-25 Diagnostic aids...
  • Page 186 7500-XXX 3-26 MFP Finisher Service Manual...
  • Page 187 7500-XXX 3-27 Diagnostic aids...
  • Page 188 7500-XXX 3-28 MFP Finisher Service Manual...

  • Page 189: Repair Information

    7500-XXX 4. Repair information Warning: Read the following before handling electronic parts. Handling ESD-sensitive parts Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power before removing logic boards: •...

  • Page 190: Removal Procedures

    7500-XXX Removal procedures CAUTION Remove the power cord from the electrical outlet before you connect or disconnect any cable or electronic board or assembly for personal safety and to prevent damage. Disconnect any connections between the printer and PCs/peripherals. Note: Some removal procedures require removing cable ties. You must replace cable ties during reassembly to avoid pinching wires, obstructing the paper path, or restricting mechanical movement.

  • Page 191: Finisher Removal

    7500-XXX Finisher removal 1. Disconnect the finisher power cord and the finisher connection cable from the rear of the printer. 2. Release the hook securing the bridge unit hookup cover (A) to the finisher. Hook Right Rear 3. Remove the bridge unit hookup cover (A). 4.
  • Page 192 7500-XXX 5. Open the finisher front door assembly (B) on the front of the finisher. 6. Pull the finisher docking latch assembly (C) outward in the direction of the arrow, and pull the finisher away from the printer. 7. Close the finisher front door assembly. MFP Finisher Service Manual...

  • Page 193: Bridge Unit Assembly Removal

    7500-XXX 8. Remove the two screws securing the finisher docking bracket (D) to the printer. 9. Remove the finisher docking bracket (D). Replacement note: When docking the finisher to the printer, make sure the boss on the finisher docking bracket (D) is inserted into the hole on the finisher docking latch assembly (C). The finisher should be firmly locked into position.

  • Page 194: Bridge Unit Rear Cover Removal

    7500-XXX 5. Remove the bridge unit assembly (B) from the printer. Bridge unit rear cover removal 1. Remove the bridge unit assembly. See “Bridge unit assembly removal” on page 4-5. 2. Remove the two screws securing the bridge unit rear cover (A) to the bridge unit assembly (B). 3.

  • Page 195: Bridge Unit Top Cover Assembly Removal

    7500-XXX Bridge unit top cover assembly removal 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Open the bridge unit top cover assembly (A). 3. Remove the six screws securing the bridge unit top cover assembly (A) to the bridge unit assembly (B). 4.

  • Page 196: Bridge Unit Drive Belt And Bridge Unit Drive Pulley Removal

    7500-XXX Bridge unit drive belt and bridge unit drive pulley removal 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Use a prying tool to remove the e-clip securing the bridge unit drive pulley (A) to the bridge unit assembly (B).

  • Page 197: Bridge Unit Right Shaft Assembly Removal

    7500-XXX Bridge unit right shaft assembly removal 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Remove the bridge unit transport belt and bridge unit drive pulley. See “Bridge unit drive belt and bridge unit drive pulley removal”...

  • Page 198: Bridge Unit Left Shaft Assembly Removal

    7500-XXX Bridge unit left shaft assembly removal 1. Open the bridge unit top cover assembly. 2. Use a prying tool to remove the front e-clip securing the 4 mm ball bearing (A) to the bridge unit left shaft (B). Front 3.

  • Page 199: Bridge Unit Idler Rolls Removal

    7500-XXX Bridge unit idler rolls removal 1. Open the bridge unit top cover assembly. 2. Remove the bridge unit left shaft assembly. See “Bridge unit left shaft assembly removal” on page 4-10. 3. Move the two transport belts (A) away from the two bridge unit idler rolls (B). 4.

  • Page 200: Bridge Unit Transport Belt Removals

    7500-XXX Bridge unit transport belt removals 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Open the bridge unit top cover assembly. 3. Remove the bridge unit right shaft assembly. See “Bridge unit right shaft assembly removal” on page 4-9.

  • Page 201: Bridge Unit Drive Motor Assembly Removal

    7500-XXX Bridge unit drive motor assembly removal 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Remove the bridge unit drive belt. See “Bridge unit drive belt and bridge unit drive pulley removal” on page 4-8.

  • Page 202: Bridge Unit Entrance Guide Removal

    7500-XXX Bridge unit entrance guide removal 1. Remove the bridge unit rear cover. See “Bridge unit rear cover removal” on page 4-6. 2. Open the bridge unit top cover assembly. 3. Remove the two screws securing the bridge unit entrance guide (A) to the bridge unit assembly (B). 4.

  • Page 203: Sensor (Bridge Unit Top Cover Interlock) Removal

    7500-XXX Sensor (bridge unit top cover interlock) removal 1. Remove the bridge unit assembly. See “Bridge unit assembly removal” on page 4-5. 2. Place the bridge unit assembly upside down. 3. Remove the screw securing the bracket (A) to the bridge unit assembly (B). 4.

  • Page 204: Sensor (Bridge Unit Media Entrance) Removal

    7500-XXX Sensor (bridge unit media entrance) removal 1. Remove the bridge unit assembly. See “Bridge unit assembly removal” on page 4-5. 2. Place the bridge unit assembly upside down. 3. Remove the screw securing the bracket (A) to the bridge unit assembly (B). 4.

  • Page 205: Sensor (Bridge Unit Media Exit) Removal

    7500-XXX Sensor (bridge unit media exit) removal 1. Remove the bridge unit assembly. See “Bridge unit assembly removal” on page 4-5. 2. Place the bridge unit upside down. 3. Remove the screw securing the bracket (A) to the bridge unit (B). Connector 4.

  • Page 206: Bridge Unit Pinch Roller Removal

    7500-XXX Bridge unit pinch roller removal 1. Open the bridge unit top cover assembly (A). 2. Remove the six bridge unit pinch rollers (B) by gently pulling them out of the bridge unit top cover assembly. 3. Remove the six springs (C). 4-18 MFP Finisher Service Manual...

  • Page 207: Top Cover Removal

    7500-XXX Top cover removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 208: Upper Media Bin Assembly Removal

    7500-XXX Upper media bin assembly removal 1. Loosen the two screws securing the upper media bin assembly (A) to the finisher. Right 2. Lift the upper media bin assembly (A) upward in the direction of the arrow. 3. Remove the upper media bin assembly (A). 4-20 MFP Finisher Service Manual...

  • Page 209: Right Eject Cover Removal

    7500-XXX Right eject cover removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the two screws securing the right eject cover (A) to the finisher. Right 4.

  • Page 210: Stacker Media Bin Assembly Removal

    7500-XXX Stacker media bin assembly removal 1. Release the two hooks securing the stacker media bin assembly (A) to the finisher. 2. Lift the stacker media bin assembly (A) upward. 3. Remove the stacker media bin assembly. (A). Right lower low voltage power supply (LVPS) cover removal 1.

  • Page 211: Rear Lower Cover Removal

    7500-XXX Rear lower cover removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the four screws securing the rear lower cover (A) to the finisher. 3. Remove the rear lower cover (A). 4-23 Repair information...

  • Page 212: Rear Upper Cover Removal

    7500-XXX Rear upper cover removal 1. Release the hook of the bridge unit hookup cover (A) to the finisher. 2. Disconnect the bridge unit harness from the finisher. 3. Remove the four screws securing the rear upper cover (B) to the finisher. Hook 4.

  • Page 213: Upper Media Bin Front Cover Removal

    7500-XXX Upper media bin front cover removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 3. Remove the two screws securing the upper media bin front cover (A). 4.

  • Page 214: Switch (Finisher Front Door Interlock) Removal

    7500-XXX Switch (finisher front door interlock) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the punch waste box (A). 4. Remove the three screws in the front securing the punch waste chute (B). 5.

  • Page 215: Finisher Front Door Assembly Removal

    7500-XXX Finisher front door assembly removal 1. Open the finisher front door assembly (A). 2. Remove the three screws securing the finisher front door assembly. 3. Remove the finisher front door assembly. Replacement note: Make sure the actuator molded in the finisher front door assembly properly engages the switch (finisher front door interlock) (B).

  • Page 216: Left Lower Cover Removal

    7500-XXX Left lower cover removal 1. Open the finisher front door assembly. 2. Remove the two screws securing the left lower cover (A). 3. Remove the left lower cover (A). 4-28 MFP Finisher Service Manual...

  • Page 217: Left Upper Cover Removal

    7500-XXX Left upper cover removal 1. Open the finisher front door assembly. 2. Remove the two screws securing the left upper cover (A). 3. Remove the left upper cover (A). 4-29 Repair information...

  • Page 218: Carriage Lift Belt Left Removal

    7500-XXX Carriage lift belt left removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 3. Move the slip clutch gear 24T (A) toward the rear to disengage the stacker bin (B). 4.
  • Page 219 7500-XXX 5. Remove the two screws securing the bin bracket (C) to the left carriage bracket (D). 6. Remove the spring (E) from the left carriage lift assembly. 7. Remove the screw securing the upper belt clamp (F) to the left carriage bracket (D). 8.

  • Page 220: Carriage Lift Belt Right Removal

    7500-XXX Carriage lift belt right removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 3. Move the slip clutch gear 24T (A) toward the rear to disengage the stacker bin (B). 4.
  • Page 221 7500-XXX 5. Remove the two screws securing the bin bracket (C) to the right carriage bracket (D). 6. Remove the spring (E) from the right carriage bracket (D). 7. Remove the screw securing the upper belt clamp (F) to the right carriage bracket (D). 8.

  • Page 222: Sensor (Stacker Bin Level 1) Removal

    7500-XXX Sensor (stacker bin level 1) removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Disconnect the connector from the sensor (stacker bin level 1) (A). Front Connector 4.

  • Page 223: Sensor (Stacker Bin Level Encoder) Removal

    7500-XXX Sensor (stacker bin level encoder) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Disconnect the connector from the sensor (stacker bin level encoder) (A). 3. Release the harness from the clamp. 4.

  • Page 224: Sensor (Stacker Bin Upper Limit) Or Sensor (Stacker Bin No Media) Removal

    7500-XXX Sensor (stacker bin upper limit) or sensor (stacker bin no media) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the rear lower cover. See “Rear lower cover removal” on page 4-23.
  • Page 225 7500-XXX Replacement note: Make sure that the yellow connector is plugged into the sensor (stacker bin no media) (C). Rear White connector Yellow connector 4-37 Repair information...

  • Page 226: Stacker Bin Lift Motor Assembly Removal

    7500-XXX Stacker bin lift motor assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the rear lower cover. See “Rear lower cover removal” on page 4-23. 3. Loosen the four screws securing the plate (A). 4.
  • Page 227 7500-XXX 6. Move the slip clutch gear 24T (B) toward the rear to disengage the stacker bin (C). 7. Move the stacker bin (C) to the lowest position. Note: Make sure the stacker bin (C) is at the lowest position before continuing. 8.
  • Page 228 7500-XXX 11. Remove the screw securing the bracket (F) to the stacker bin lift motor assembly (G). 12. Remove the bracket (F). Connector Clamp 13. Release the hook securing the encoder (H) to the stacker bin lift motor assembly (G). 14.

  • Page 229: Punch Carriage Assembly Removal

    7500-XXX Punch carriage assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.
  • Page 230 7500-XXX 12. Remove the two screws on the front securing the punch carriage assembly (B) to the finisher. Front 13. While moving the belt (buffer/transport) (E) to the left as shown, pull the punch carriage assembly (B) gently out of the rear of the finisher. Warning: Do not force the punch carriage assembly (B) out of the finisher.

  • Page 231: Punch Carriage Shift Motor Assembly Removal

    7500-XXX Punch carriage shift motor assembly removal 1. Open the finisher front door assembly. 2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 3. Remove the top cover. See “Top cover removal” on page 4-19.

  • Page 232: Sensor (Punch Unit Side Registration Pair) With Bracket Removal

    7500-XXX Sensor (punch unit side registration pair) with bracket removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 233: Punch Unit Assembly Removal

    7500-XXX Punch unit assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 234: Punch Media Stop Assembly Removal

    7500-XXX Punch media stop assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 235: Punch Unit Motor Assembly Removal

    7500-XXX Punch unit motor assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 236: Sensor (Punch Unit Motor Encoder) Removal

    7500-XXX Sensor (punch unit motor encoder) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 237: Sensor (Punch Hole Select), Sensor (Punch Cam Front), And Sensor (Punch Unit Hp) Removal

    7500-XXX Sensor (punch hole select), sensor (punch cam front), and sensor (punch unit HP) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the punch carriage assembly. See “Punch carriage assembly removal”...
  • Page 238 7500-XXX Replacement note: Make sure the color coded-connectors are connected to the proper sensors, as shown. Connector Blue Black Connector White 4-50 MFP Finisher Service Manual...

  • Page 239: Sensor (Punch Carriage Shift Hp) Removal

    7500-XXX Sensor (punch carriage shift HP) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the punch carriage assembly. See “Punch carriage assembly removal” on page 4-41.

  • Page 240: Sensor (Punch Waste Box Set) Removal

    7500-XXX Sensor (punch waste box set) removal 1. Open the finisher front door assembly. 2. Pull the punch waste box. 3. Disconnect the connector from the sensor (punch waste box set) (A). 4. Release the hooks securing the sensor (punch waste box set) (A) to the finisher. Connector 5.

  • Page 241: Sensor (Punch Waste Box Full) Removal

    7500-XXX Sensor (punch waste box full) removal 1. Open the finisher front door assembly. 2. Remove the punch waste box (A) from the finisher. 3. Disconnect the connector from the sensor (punch waste box full) (B). 4. Release the hooks securing the sensor (punch waste box full) (B) to the finisher. Connector 5.

  • Page 242: Stapler Unit Frame Removal

    7500-XXX Stapler unit frame removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the staple cartridge. 3. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 4.
  • Page 243 7500-XXX 8. Disconnect the connector P8308 from the finisher controller card assembly (B). 9. Remove the screw securing the ground wire (C) to the finisher. 10. Release the harness from the clamp. Clamp P8308 Rear 11. Remove the media stacker bin lift motor assembly. See “Stacker media bin assembly removal”...

  • Page 244: Stapler Unit Assembly Removal

    7500-XXX Stapler unit assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the staple cartridge. 3. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 4.
  • Page 245 7500-XXX 11. Remove the screw securing the stapler cover (E) to the stapler unit assembly (F). 12. Remove the stapler cover (E). 13. Disconnect the two connectors from the stapler unit assembly (F). 14. Disconnect the connector from the sensor (stapler carriage HP) (G). 15.

  • Page 246: Sensor (Stapler Carriage Hp) Removal

    7500-XXX Sensor (stapler carriage HP) removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the staple cartridge. 3. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24.

  • Page 247: Media Eject Unit Assembly Removal

    7500-XXX Media eject unit assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal”...
  • Page 248 7500-XXX 8. Remove the screw securing the eject clamp lever assembly (C) from the shaft (D) on the rear of the finisher. 9. Remove the eject clamp lever assembly (C). 10. Remove the e-clip securing the shaft (D) to the rear of the finisher. 11.
  • Page 249 7500-XXX 12. Remove the e-clip securing the shaft (F) to the front of the finisher. 13. Remove the 8 mm bushing (E) on the front side. E-clip Front 14. Gently move the left side of the media eject unit assembly (G) out of the finisher followed by the right side. Note: Do not force the media eject unit assembly out of the finisher.
  • Page 250 7500-XXX Replacement notes: • Do not force the media eject unit assembly into the finisher. Insert the right side before the left side. • Make sure the media eject unit assembly properly actuates the switch (eject cover interlock) (H) without binding.

  • Page 251: Sub Paddle Removal

    7500-XXX Sub paddle removal 1. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 2. Gently remove the two sub paddles (A) from the two shafts (B). Replacement note: Make sure the sub paddles are properly installed as shown in the figure. The paddles must not come in contact with the media eject unit assembly (C).

  • Page 252: Sub Paddle Drive Shaft Assembly Removal

    7500-XXX Sub paddle drive shaft assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the media eject unit assembly. See “Media eject unit assembly removal” on page 4-59.
  • Page 253 7500-XXX 8. Loosen the two screws securing the belt tensioner bracket (D) to the rear of the finisher. 9. Release the hook of the sub paddle drive gear 23T (E) from the sub paddle drive shaft assembly (B). 10. Remove the sub paddle drive gear 23T (E). 11.

  • Page 254: Media Eject Clamp Motor Assembly Removal

    7500-XXX Media eject clamp motor assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 3. Remove the two media eject unit springs (A) attached to the media eject unit assembly (B) by pushing them downward.

  • Page 255: Sensor (Media Eject Clamp Hp) Removal

    7500-XXX Sensor (media eject clamp HP) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 3. Remove the two media eject unit springs attached to the media eject unit assembly by pushing them downward.

  • Page 256: Switch (Eject Cover Interlock) Removal

    7500-XXX Switch (eject cover interlock) removal 1. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 2. Disconnect the connector from the switch (eject cover interlock) (A). 3. Release the harness from the two clamps. 4.

  • Page 257: Media Compiler Unit Assembly Removal

    7500-XXX Media compiler unit assembly removal 1. Remove the finisher front door assembly. See“Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the rear lower cover. See “Rear lower cover removal”...
  • Page 258 7500-XXX 13. Disconnect the connector P8309 from the finisher controller card assembly (B). 14. Release the harness from the clamps. Clamp P8309 Rear 15. Remove the screw securing the media compiler unit assembly (C) to the finisher. This screw is found inside the finisher.

  • Page 259: Sensor (Front Tamper Hp) And Sensor (Rear Tamper Hp) Removals

    7500-XXX 16. Release the media compiler assembly (C) by pushing the front lock and the rear lock inward to release the front boss and the rear boss from the finisher. Right Rear view Front view Lock Lock 17. Remove the harness from any additional parts. 18.

  • Page 260: Sensor (Compiler Media In) Removal

    7500-XXX 13. Remove the sensor(s). Note: The sensors are identical. Connector Sensor (compiler media in) removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24.
  • Page 261 7500-XXX 13. Move the compiler media present actuator (C) downward as shown. Connector 14. Remove the sensor (compiler media present) (A). 4-73 Repair information...

  • Page 262: Media Eject Shaft Assembly Removal

    7500-XXX Media eject shaft assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Move the slip clutch gear 24T (A) toward the rear as shown to disengage the stacker bin (B). 4.
  • Page 263 7500-XXX 15. Move the media eject shaft assembly toward the rear and outward as shown. E-clips E-clip Front Rear 16. Remove the media eject shaft assembly (E). Rear 4-75 Repair information...

  • Page 264: Clamp Paddle Removal

    7500-XXX Clamp paddle removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the media eject shaft assembly. See “Media eject shaft assembly removal”...

  • Page 265: Media Eject Clutch Assembly Removal

    7500-XXX Media eject clutch assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Disconnect the connector from the sensor (media eject shaft HP) (A). 3. Release the harness from the clamp. 4. Disconnect the connector from the media eject clutch (B). 5.

  • Page 266: Media Eject Motor Assembly Removal

    7500-XXX Media eject motor assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the media eject clutch. See “Media eject clutch assembly removal” on page 4-77. 3. Disconnect the connector from the media eject motor assembly (A). 4.

  • Page 267: Sensor (Media Eject Shaft Hp) Removal

    7500-XXX Sensor (media eject shaft HP) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Disconnect the connector from the sensor (media eject shaft HP) (A). 3. Rotate the media eject clutch actuator (B) by hand so it clears the sensor (media eject shaft HP) (A). 4.

  • Page 268: Sensor (Lower Media Exit) Removal

    7500-XXX Sensor (lower media exit) removal 1. Open the finisher front door assembly. 2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20. 3. Disconnect the connector from the sensor (lower media exit) (A). 4.

  • Page 269: Lower Media Exit Roll Assembly Removal

    7500-XXX Lower media exit roll assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal”...
  • Page 270 7500-XXX Front view Rear view 19. Release the hook of the lower exit roll drive pulley 20T (C) from the lower media exit roll assembly (F). 20. Remove the lower exit roll drive pulley 20T (C). 4-82 MFP Finisher Service Manual...
  • Page 271 7500-XXX 21. Remove the 6 mm ball bearing (G). 22. Use a prying tool to remove the e-clip on the front of the finisher securing the lower media exit roll assembly (F) to the finisher. 4-83 Repair information...
  • Page 272 7500-XXX 23. Remove the 6 mm bushing (H). E-clip Front 24. Move the lower media exit roll assembly (F) towards the rear and outward, as shown. Rear 25. Remove the lower media exit roll assembly (F). 4-84 MFP Finisher Service Manual...

  • Page 273: Paddle And Roll Exit Assembly Removal

    7500-XXX Paddle and roll exit assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the rear lower cover. See “Rear lower cover removal”...
  • Page 274 7500-XXX 14. Loosen the two screws securing the belt tensioner bracket (D) to the finisher and move it upward, as shown. Replacement note: When replacing the belt tensioner bracket (D), tighten the screws in the order shown. 15. Remove the belt (paddle/entrance) (E) from the main paddle drive pulley/gear 44/20T (F). 16.
  • Page 275 7500-XXX 25. Remove the main paddle shaft assembly. Rear 4-87 Repair information...
  • Page 276 7500-XXX Replacement notes: • The tension of the belt (exit) (A) and the belt (paddle/entrance) (E) is automatically adjusted by the force of the spring attached to the belt tensioner bracket (A and D). • Tighten the screws in the order shown. First Right Second...

  • Page 277: Lower Pinch Guide Assembly Removal

    7500-XXX Lower pinch guide assembly removal 1. Open the finisher front door assembly. 2. Open the lower pinch guide assembly (A) by lifting it upward. 3. Remove the screw securing the lower pinch guide assembly (A) to the finisher. 4. Move the lower pinch guide assembly (A) upward and outward. Front 5.

  • Page 278: Finisher Diverter Gate Removal

    7500-XXX Finisher diverter gate removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Open the lower pinch guide assembly (A) to the right. 4. Open the upper pinch guide assembly (B) to the right. 5.

  • Page 279: Buffer Diverter Gate Removal

    7500-XXX Buffer diverter gate removal 1. Open the finisher front door assembly. 2. Move the lower pinch guide assembly (A) to the right. 3. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 4. Remove the buffer diverter gate solenoid. See “Buffer diverter gate solenoid removal”...

  • Page 280: Sensor (Buffer Path) Removal

    7500-XXX Sensor (buffer path) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 281: Finisher Buffer Roll Assembly Removal

    7500-XXX Finisher buffer roll assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Open the finisher front door assembly. 3. Remove the stapler unit cartridge. 4. Move the stapler unit assembly by hand as far to the rear as it will go. 5.
  • Page 282 7500-XXX 11. Loosen the two screws securing the belt tensioner bracket (E) to the finisher and move it downward, as shown. 12. Remove the belt (buffer/transport) (F) from the buffer roll drive gear 46T (G). E-clip Second First 13. Use a prying tool to remove the e-clip securing the buffer roll drive gear 23/53T (G). 14.

  • Page 283: Buffer Pinch Guide Assembly Removal

    7500-XXX Buffer pinch guide assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the rear lower cover. See “Rear lower cover removal”...

  • Page 284: Media Entrance Pinch Guide Assembly Removal

    7500-XXX Media entrance pinch guide assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the left lower cover. See “Left lower cover removal” on page 4-28.

  • Page 285: Sensor (Finisher Media Entrance) Removal

    7500-XXX Sensor (finisher media entrance) removal 1. Open the front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 286: Finisher Media Entrance Roll Assembly Removal

    7500-XXX Finisher media entrance roll assembly removal 1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-27. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the left upper cover. See “Left upper cover removal”...

  • Page 287: Drive Motor (Entrance/Paddle) And Belt (Entrance/Paddle) Removal

    7500-XXX 16. Move the media entrance roll assembly (H) toward the rear, downward, and then forward. 17. Remove the media entrance roll assembly (H) through the inside of the finisher. Note: When removing the media entrance roll assembly (H), do not touch the rubber surface. Replacement notes: •...
  • Page 288 7500-XXX 5. Remove the two screws securing the bracket (D) to the finisher. Connector 6. Remove the bracket (D). 7. Remove the two screws securing the bracket (D) to the drive motor (entrance/paddle) (C). 8. Remove the drive motor (entrance/paddle) (C). 9.

  • Page 289: Finisher Diverter Gate Solenoid Removal

    7500-XXX Finisher diverter gate solenoid removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Disconnect the connector from the finisher diverter gate solenoid (A). 4. Release the harness from the clamp. 5.

  • Page 290: Buffer Diverter Gate Solenoid Removal

    7500-XXX Buffer diverter gate solenoid removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Disconnect the connector from the buffer diverter gate solenoid (A). 4. Release the harness from the clamp. 5.

  • Page 291: Sensor (Upper Media Exit) Removal

    7500-XXX Sensor (upper media exit) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 292: Upper Media Exit Roll Assembly Removal

    7500-XXX Upper media exit roll assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.
  • Page 293 7500-XXX 11. Remove the bracket (C). 12. Release the hook from the upper media exit roll drive gear 20T(D). 13. Remove the upper media exit roll drive gear 20T. 14. Remove the 6 mm bushing. 15. Use a prying tool to remove the e-clip securing the upper media exit roll assembly (F) to the front of the finisher.

  • Page 294: Sensor (Upper Media Bin Full) Removal

    7500-XXX Sensor (upper media bin full) removal 1. Open the finisher front door assembly. 2. Remove the screw securing the bracket (A) to the upper media bin vertical cover (B). 3. Move the bracket frontward and downward to gain access to the harness and connector. 4.

  • Page 295: Upper Pinch Guide Assembly Removal

    7500-XXX Upper pinch guide assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the drive motor (buffer/transport). See “Drive motor (buffer/transport) and belt (buffer/ transport) removal”...

  • Page 296: Sensor (Diverter Gate) Removal

    7500-XXX Sensor (diverter gate) removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-20.

  • Page 297: Upper Media Transport Roll Assembly Removal

    7500-XXX Upper media transport roll assembly removal 1. Open the finisher front door assembly. 2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 3. Remove the top cover. See “Top cover removal” on page 4-19. 4.
  • Page 298 7500-XXX 10. Remove the two screws securing the bracket (D). Note: It is not necessary to remove the bracket from the finisher; it should only be slightly moved to provide better access to the two upper media transport roll drive pulleys 20T(E). 11.

  • Page 299: Drive Motor (Exit) Assembly And Belt (Exit) Removal

    7500-XXX Drive motor (exit) assembly and belt (exit) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Loosen the two screws securing the belt tensioner bracket (A) to the finisher, and move it down as shown. 3.
  • Page 300 7500-XXX 5. Remove the two screws securing the bracket (D) to the finisher. 6. Remove the bracket (D). 7. Remove the two screws securing the drive motor (exit) assembly to the bracket (D). Connector 8. Remove the drive motor (exit) assembly (C). Replacement notes: •...

  • Page 301: Drive Motor (Buffer/Transport) And Belt (Buffer/Transport) Removal

    7500-XXX Drive motor (buffer/transport) and belt (buffer/transport) removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the two screws securing the bracket (A) on the rear of the finisher. 3. Move the bracket slightly. Note: It is not necessary to remove the bracket from the finisher.
  • Page 302 7500-XXX 6. Disconnect the connector from the drive motor (buffer/transport). 7. Remove the two screws securing the bracket (E) to the finisher. 8. Remove the bracket. 9. Remove the two screws securing the drive motor (buffer/transport) to the bracket. 10. Remove the drive motor (buffer/transport). 11.

  • Page 303: Bridge Unit Interface Card Assembly Removal

    7500-XXX Bridge unit interface card assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Disconnect all the connectors from the bridge unit interface card assembly (A). 3. Remove the two screws securing the bridge unit interface card assembly (A) to the finisher. Connector Connectors Rear...

  • Page 304: Finisher Controller Card Assembly Removal

    7500-XXX Finisher controller card assembly removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the rear lower cover. See “Rear lower cover removal” on page 4-23. 3. Loosen the four screws securing the plate (A) to the finisher. 4.

  • Page 305: Finisher Low Voltage Power Supply (Lvps) Removal

    7500-XXX Finisher low voltage power supply (LVPS) removal 1. Remove the right lower cover. See “Rear lower cover removal” on page 4-23. 2. Disconnect all the connectors from the finisher LVPS (A). 3. Remove the two screws securing the finisher LVPS (A) to the finisher. Rear 4.

  • Page 306: Booklet Bin Hookup Cable Assembly Removal

    7500-XXX Booklet bin hookup cable assembly removal 1. Disconnect booklet hookup cable assembly from the booklet bin assembly. 2. Remove rear lower cover. See “Rear lower cover removal” on page 4-23. 3. Disconnect the booklet bin hookup cable assembly from the rear of the finisher. 4.

  • Page 307: Booklet Bin Assembly Removal

    7500-XXX Booklet bin assembly removal 1. Disconnect booklet hookup cable assembly from the booklet bin assembly. 2. Remove the screw securing the booklet bin assembly (A) to the finisher. 3. Remove booklet bin assembly (A). 4-119 Repair information...

  • Page 308: Sensor (Booklet Unit Interlock) Removal

    7500-XXX Sensor (booklet unit interlock) removal 1. Open the finisher front door assembly. 2. Pull the booklet unit assembly out of the finisher. 3. Remove rear lower cover. See “Rear lower cover removal” on page 4-23. 4. Disconnect the connector from the sensor (booklet unit interlock). 5.

  • Page 309: Booklet Controller Card Assembly Removal

    7500-XXX Booklet controller card assembly removal ?? Warning: When replacing the booklet controller card assembly, the existing booklet maker adjustments must be restored to the original settings, or booklet folding and stapling will be out of alignment. The existing booklet maker adjustments can be found on the settings sheet located in the tray 1 settings sheet compartment.

  • Page 310: Booklet Unit Assembly Removal

    7500-XXX Booklet unit assembly removal 1. Open the finisher front door assembly. 2. Slide the booklet unit out. 3. Release the two latches securing the booklet unit (A) from the guides. 4. Remove booklet unit (A). Booklet folding/exit drive motor assembly removal 1.

  • Page 311: Booklet Diverter Gate Solenoid Removal

    7500-XXX Booklet diverter gate solenoid removal 1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-24. 2. Remove the two screws securing the booklet diverter gate solenoid (A) to the machine. 3. Remove the booklet diverter gate solenoid (A). 4.

  • Page 312: Booklet Knife Solenoid Frame Removal

    7500-XXX 6. Remove the booklet stapler unit assembly (B). Booklet knife solenoid frame removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit motor assembly. See “Booklet folding/exit drive motor assembly removal” on page 4-122.

  • Page 313: Booklet Knife Solenoid Removal

    7500-XXX 8. Remove the folding solenoid frame (A). Rear Booklet knife solenoid removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit motor assembly. See “Booklet folding/exit drive motor assembly removal” on page 4-122.

  • Page 314: Booklet Knife Sector Drive Gear 42T

    7500-XXX 5. Remove the booklet knife solenoid (A). Booklet knife sector drive gear 42T 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit motor assembly. See “Booklet folding/exit drive motor assembly removal” on page 4-122.

  • Page 315: Booklet Media Entrance Drive Motor Removal

    7500-XXX 5. Remove the booklet knife sector drive gear 42T (A). Rear Booklet media entrance drive motor removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the screws securing the booklet media entrance drive motor cover from the booklet unit. 3.

  • Page 316: Booklet Unit Gear Train Frame Removal

    7500-XXX 6. Remove the booklet media entrance drive motor (A). Connector Rear Booklet unit gear train frame removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit motor assembly. See “Booklet folding/exit drive motor assembly removal”...

  • Page 317: Booklet Unit Assembly Left Cover

    7500-XXX 8. Remove the booklet unit gear train frame (A). Booklet unit assembly left cover 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the top screws securing the left cover to the booklet unit assembly. 3.

  • Page 318: Booklet Rear Tamper Assembly Removal

    7500-XXX 4. Remove the booklet unit assembly left cover (A). Booklet rear tamper assembly removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit motor assembly. See “Booklet folding/exit drive motor assembly removal” on page 4-122.

  • Page 319: Booklet Front Tamper Guide Removal

    7500-XXX 13. Remove the rear tamper assembly (A). Right Booklet front tamper guide removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 320: Sensor (Booklet Front Tamper Hp) Removal

    7500-XXX 4. Remove the front tamper guide (A). Right Left Sensor (booklet front tamper HP) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 321: Sensor (Booklet Rear Tamper Hp) Removal

    7500-XXX 5. Remove sensor (booklet front tamper HP) (A). Left Connector Sensor (booklet rear tamper HP) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover”...

  • Page 322: Booklet Front Tamper Motor Removal

    7500-XXX 5. Remove sensor (booklet rear tamper HP) (A). Left Connector Booklet front tamper motor removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 323: Booklet Rear Tamper Motor Removal

    7500-XXX 5. Remove the booklet front tamper motor (A). Connector Left Booklet rear tamper motor removal “Booklet unit assembly removal” on page 4-122. 1. Remove the booklet unit assembly. See 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 324: Sensor (Booklet Knife Hp) Removal

    7500-XXX 5. Remove the booklet rear tamper motor (A). Connector Left Sensor (booklet knife HP) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 325: Sensor (Booklet Knife Folding) Removal

    7500-XXX 6. Remove sensor (booklet knife HP) (A). Connector Left Sensor (booklet knife folding) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 1. Remove the Complete booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.

  • Page 326: Booklet Unit Front Door Assembly Removal

    7500-XXX 5. Remove sensor (booklet knife folding) (A). Connector Left Booklet unit front door assembly removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the e-clip securing the shaft X from the booklet unit. 3.

  • Page 327: Sensor (Booklet Media Compiler In) Removal

    7500-XXX 5. Remove Sensor (booklet unit media entrance) (A). Right Connector Sensor (booklet media compiler in) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover”...

  • Page 328: Sensor (Booklet End Guide Hp) Removal

    7500-XXX 6. Remove Sensor (booklet unit media exit) (A). Connector Right Sensor (booklet end guide HP) removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. “Booklet unit assembly left cover” on page 4-129. 2. Remove the booklet unit assembly left cover. See 3.

  • Page 329: Booklet Media Pinch Roll Assembly Removal

    7500-XXX 5. Remove sensor (booklet end guide HP) (A). Left Connector Booklet media pinch roll assembly removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the Sensor (booklet unit media entrance). See “Sensor (booklet unit media entrance) removal”...

  • Page 330: Booklet Paddle Motor Removal

    7500-XXX 7. Remove the booklet media pinch roll assembly (A). Booklet paddle motor removal 1. Remove the booklet unit assembly. See “Booklet unit assembly removal” on page 4-122. 2. Remove the booklet unit assembly left cover. See “Booklet unit assembly left cover” on page 4-129.
  • Page 331 7500-XXX 5. Remove the booklet end guide drive motor (A). Connector 4-143 Repair information...

  • Page 332: Booklet Maker Setup & Adjustment

    7500-XXX Booklet maker setup & adjustment Folding precision skew adjustment Step Check Print a 2 sheet booklet using the booklet maker. Go to step 2. The folding precision skew Does the booklet appear skewed as shown in the graphic adjustment is in below? spec.

  • Page 333: Sheet Fold & Staple Position Fine Adjustment

    7500-XXX 2 sheet fold & staple position fine adjustment Step Check Print a 2 sheet booklet using the booklet maker. Go to step 2. The 2 sheet fold position fine Does the booklet sheet edges appear overlapped as shown adjustment is in in the graphic below? spec.
  • Page 334 7500-XXX Step Check Adjust the 2 sheet position fine adjustment value based on Repeat step 2 until Problem solved. the graphic below: the 2 sheet fold position fine adjustment is in spec. Go to step 3. 1. Enter the diagnostic mode. 2.
  • Page 335 7500-XXX Step Check Print a 2 sheet stapled booklet using the booklet maker. Go to step 4. The 2 sheet staple position fine Does the staple position fine adjustment appear to be offset adjustment is in from the fold as shown in the graphic below? spec.
  • Page 336 7500-XXX Step Check Adjust the 2 sheet staple position fine adjustment value as Repeat step 2 until Problem solved. shown in the graphic below: the 2 sheet staple position fine adjustment is in spec. 1. Enter the diagnostic mode. 2. Touch ENGINE ADJUST. 3.

  • Page 337: Sheet Staple Position Fine Adjustment

    7500-XXX 15 sheet staple position fine adjustment Step Check Print a 15 sheet stapled booklet using the booklet maker. Go to step 2. The 15 sheet staple position fine Does the staple position fine adjustment appear to be offset adjustment is in from the fold as shown in the graphic below? spec.
  • Page 338 7500-XXX Step Check Adjust the 15 sheet staple position fine adjustment value as Repeat step 2 until Problem solved. shown in the graphic below: the 15 sheet staple position fine adjustment is in spec. 1. Enter the diagnostic mode. 2. Touch ENGINE ADJUST. 3.

  • Page 339: Booklet Fold Position Fine Adjustment (3-15 Sheets)

    7500-XXX Booklet fold position fine adjustment (3-15 sheets) Step Check Note: The booklet fold position fine adjustment is different Go to step 2. The booklet fold depending on the amount of sheets that compose the position fine booklet and the size of the media. adjustment is in spec.
  • Page 340 7500-XXX Step Check Adjust the fold position fine adjustment value based on the Repeat step 2 until Problem solved. graphic below: the Booklet fold position fine adjustment is in spec. 1. Enter the diagnostic mode. 2. Touch ENGINE ADJUST. 3. Touch Booklet fold adjust. 4.

  • Page 341: Booklet Staple Position Fine Adjustment (3-14 Sheets)

    7500-XXX Booklet staple position fine adjustment (3-14 sheets) Step Check Note: The booklet staple position fine adjustment is Go to step 2. The booklet staple different depending on the amount of sheets that compose position fine the booklet. adjustment is in spec.
  • Page 342 7500-XXX Step Check Adjust the booklet staple position fine adjustment value as Repeat step 2 until Problem solved. shown in the graphic below: the Booklet staple position fine adjustment is in spec. 1. Enter the diagnostic mode. 2. Touch ENGINE ADJUST. 3.

  • Page 343: Connector Locations

    7500-XXX 5. Connector locations Finisher components Bridge unit assembly Bridge unit drive motor Sensor (bridge unit media entrance) Sensor (bridge unit media exit) Sensor (bridge unit top cover interlock) Connector locations...

  • Page 344: Stacker Lift And Stapler

    7500-XXX Stacker lift and stapler Sensor (stacker bin upper limit) Sensor (stacker bin level 2) Sensor (stacker bin no media) Sensor (stacker bin level 1) Switch (finisher front door interlock) Stapler carriage motor assembly Sensor (stapler carriage HP) Bottom view MFP Finisher Service Manual...

  • Page 345: Punch Unit

    7500-XXX Punch unit Punch carriage shift motor assembly Sensor (punch carriage shift HP) Sensor (punch unit HP) Sensor (punch hole select) Sensor (punch unit side registration 2) Sensor (punch Sensor (punch unit side cam front) registration 1) Punch unit motor assembly Sensor (punch waste box set) Sensor (punch...

  • Page 346: Diverter And Media Eject

    7500-XXX Diverter and media eject Sensor (media eject clamp HP) Media eject clamp motor Buffer diverter solenoid Media diverter solenoid Switch (eject cover interlock) Sensor (lower media exit) Media eject and media compiler Media eject motor asm Sensor ( front tamper HP) Front tamper motor...

  • Page 347: Buffer, Upper Exit, Lower Exit, And Drive Motors

    7500-XXX Buffer, upper exit, lower exit, and drive motors Sensor (upper media exit) Sensor (upper media bin full) Drive motor (exit) Drive motor (buffer/transport) Sensor (diverter gate) Sensor (finisher media entrance) Sensor (buffer path) Drive motor (entrance/paddle) Motor (exit) Motor (buffer/transport) Motor (entrance/paddle) Lower media exit roll assembly...
  • Page 348 7500-XXX Upper media exit roll assembly Upper media transport roll assembly Finisher controller card assembly Finisher controller Bridge unit interface card assembly card assembly P8304 P8308 P8389 P8306 P8307 P8309 P8300 P8305 P8301 P8376 P8310 P8302 P8316 P8311 P8314 P8317 P8315 P8313 Finisher low...

  • Page 349: Booklet Media Bin

    7500-XXX Booklet media bin Booklet bin assembly Sensor (booklet bin full) Front Booklet bin drive motor Connector locations...

  • Page 350: Booklet Maker

    7500-XXX Booklet maker Booklet rear Sensor (booklet tamper motor rear tamper HP) Booklet front tamper motor Booklet folding/exit drive motor assembly Sensor (booklet Sensor front tamper HP) (booklet folding) Sensor (booklet knife HP) Booklet paddle drive motor assembly Booklet end guide drive motor assembly MFP Finisher Service Manual...
  • Page 351 7500-XXX Sensor (booklet media entrance) Sensor (booklet media exit) Booklet media entrance drive motor assembly Booklet folding/exit drive motor assembly Booklet stapler drive motor Rear Connector locations...
  • Page 352 7500-XXX Booklet controller card assembly 5-10 MFP Finisher Service Manual...

  • Page 353: Cabling

    7500-XXX Cabling Finisher media entrance sensor cable assembly Upper media exit sensor cable assembly Upper media bin full cable assembly Lower media exit sensor cable sssembly Compiler unit cable assembly Buffer path sensor cable assembly Main sensor cable assembly LVPS cable assembly AC power cord assembly...
  • Page 354 7500-XXX Diverter gate sensor upper cable assembly Punch main drive cable assembly Diverter gate sensor lower cable assembly Punch waste box set cable assembly Interlock switch cable assembly 5-12 MFP Finisher Service Manual...
  • Page 355 7500-XXX Main drive cable assembly Punch waste box full cable assembly Bridge unit connect cable assembly Stapler unit cable assembly Bridge unit interface card cable assembly Finisher interface cable assembly 5-13 Connector locations...
  • Page 356 7500-XXX 5-14 MFP Finisher Service Manual...

  • Page 357: Preventive Maintenance

    Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover • Possible safety exposure from any non-Lexmark attachments Lubrication specifications Lubricate only when parts are replaced or as needed, not on a scheduled basis. Use of lubricants other than those specified can cause premature failure.
  • Page 358 7500-XXX MFP Finisher Service Manual...

  • Page 359: Parts Catalog

    7500-XXX 7. Parts catalog How to use this parts catalog The following legend is used in the parts catalog: Asm- Part Units/ Units/ Description Index number option • Asm-index: Identifies the assembly and the item in the diagram. For example 3-1 indicates Assembly 3 and item number 1 in the table.

  • Page 360: Assembly 1: Finisher-Bridge Unit

    7500-XXX Assembly 1: Finisher–bridge unit Asm- Part Units/ Units/ Description Index number option 40X0811 Bridge unit assembly 40X0810 Bridge unit assembly docking screw (2 each) MFP Finisher Service Manual...

  • Page 361: Assembly 2: Finisher-Bridge Unit Top Cover Assembly

    7500-XXX Assembly 2: Finisher–bridge unit top cover assembly Asm- Part Units/ Units/ Description Index number option 40X0813 Bridge unit top cover assembly 40X0812 Bridge unit pinch roll kit includes: • Bridge unit pinch roll (6 each) • Spring (6 each) Parts catalog...

  • Page 362: Assembly 3: Finisher-Bridge Unit Lower Assembly

    7500-XXX Assembly 3: Finisher–bridge unit lower assembly MFP Finisher Service Manual...
  • Page 363 7500-XXX Assembly 3: Finisher–bridge unit lower assembly Asm- Part Units/ Units/ Description Index number option 40X0814 Bridge unit rear cover 40X0822 Bridge unit right shaft kit includes: • 6 mm bushing - front • Bridge unit right shaft assembly • 6 mm bushing - rear 40X0820 Transport belts (2 each) 40X0821...

  • Page 364: Assembly 4: Finisher-Covers

    7500-XXX Assembly 4: Finisher–covers MFP Finisher Service Manual...
  • Page 365 7500-XXX Assembly 4: Finisher–covers Asm- Part Units/ Units/ Description Index number option 40X0829 Top cover 40X0831 Upper media bin assembly 40X0830 Upper media bin vertical cover 40X0832 Right eject cover 40X0833 Stacker media bin 40X0834 Right lower LVPS cover 40X0835 Caster 40X0836 Rear lower cover...

  • Page 366: Assembly 5: Finisher-Covers

    7500-XXX Assembly 5: Finisher–covers MFP Finisher Service Manual...
  • Page 367 7500-XXX Assembly 5: Finisher–covers Asm- Part Units/ Units/ Description Index number option 40X0829 Top cover 40X0831 Upper media bin assembly 40X0830 Upper media bin vertical cover 40X0832 Right eject cover 40X0833 Stacker media bin 40X0834 Right lower LVPS cover 40X0835 Caster 40X0836 Rear lower cover...

  • Page 368: Assembly 6: Finisher-Covers And Front Door

    7500-XXX Assembly 6: Finisher–covers and front door 7-10 MFP Finisher Service Manual...
  • Page 369 7500-XXX Assembly 6: Finisher–covers and front door Asm- Part Units/ Units/ Description Index number option 40X0839 Upper media bin front cover 40X0841 Finisher front door assembly (this comes assembled) 40X0840 Switch (finisher front door interlock) 40X0842 Finisher docking latch kit includes: •...

  • Page 370: Assembly 7: Finisher-Stacker Bin Lift

    7500-XXX Assembly 7: Finisher–stacker bin lift 7-12 MFP Finisher Service Manual...
  • Page 371 7500-XXX Assembly 7: Finisher–stacker bin lift Asm- Part Units/ Units/ Description Index number option 40X0846 Carriage lift belt kit includes: • Carriage lift belt • Belt clamp (2 each) • Spring • Roll (2 each) 40X0847 Sensor (stacker bin level) 40X0849 Stacker slip clutch pulley kit includes: •...

  • Page 372: Assembly 8: Finisher-Punch

    7500-XXX Assembly 8: Finisher–punch 7-14 MFP Finisher Service Manual...
  • Page 373 7500-XXX Assembly 8: Finisher–punch Asm- Part Units/ Units/ Description Index number option 40X0854 Punch carriage shift motor assembly 40X0855 Punch carriage assembly 40X0856 Sensor (punch unit side reg) assembly • Sensor (punch unit side reg1) • Sensor (punch unit side reg2) •...

  • Page 374: Assembly 9: Stapler

    7500-XXX Assembly 9: stapler 7-16 MFP Finisher Service Manual...
  • Page 375 7500-XXX Assembly 9: Finisher–stapler Asm- Part Units/ Units/ Description Index number option 40X0870 Stapler unit cable assembly 40X0869 Stapler carriage kit includes: • Stapler carriage wire guide • Stapler carriage assembly 40X0871 Stapler carriage motor assembly 40X0872 Stapler carriage rack gear 40X0868 Stapler unit cover 40X0850...

  • Page 376: Assembly 10: Finisher-Media Eject

    7500-XXX Assembly 10: Finisher–media eject 7-18 MFP Finisher Service Manual...
  • Page 377 7500-XXX Assembly 10: Finisher–media eject Asm- Part Units/ Units/ Description Index number option 40X0873 Media eject unit assembly (this comes assembled) 40X0874 Sub paddle 40X0875 Sub paddle drive shaft kit includes: • Sub paddle drive shaft assembly • Knob 40X0882 Switch (eject cover interlock) 40X1388 Bushing 8 mm...

  • Page 378: Assembly 11: Finisher-Eject And Compiler Unit

    7500-XXX Assembly 11: Finisher–eject and compiler unit 7-20 MFP Finisher Service Manual...
  • Page 379 7500-XXX Assembly 11: Finisher–eject and compiler unit Asm- Part Units/ Units/ Description Index number option 40X0883 Media compiler unit assembly (this comes assembled) 40X0850 Sensor (rear tamper HP) 40X0850 Sensor (front tamper HP) 40X0825 Sensor (compiler media in) 40X0886 Media eject shaft assembly 40X0887 Clamp paddle 40X0888...

  • Page 380: Assembly 12: Finisher-Lower Exit Drive

    7500-XXX Assembly 12: Finisher–lower exit drive 7-22 MFP Finisher Service Manual...
  • Page 381 7500-XXX Assembly 12: Finisher–lower drive Asm- Part Units/ Units/ Description Index number option 40X0892 Sensor (lower media exit) with bracket 40X0893 Sensor (lower media exit) 40X0894 Static eliminator brush 40X0895 Lower media exit roll assembly 40X0896 Main paddle shaft kit includes: (this comes assembled) •...

  • Page 382: Assembly 13: Finisher-Buffer And Entrance Drive

    7500-XXX Assembly 13: Finisher–buffer and entrance drive 7-24 MFP Finisher Service Manual...
  • Page 383 7500-XXX Assembly 13: Finisher–buffer and entrance drive Asm- Part Units/ Units/ Description Index number option 40X0901 Lower pinch guide assembly (this comes assembled) 40X0902 Finisher diverter gate 40X0903 Buffer diverter gate 40X0824 Magnetic catch 40X0888 Bushing 6 mm 40X0904 Buffer upper guide assembly 40X0893 Sensor (buffer path) 40X0905...

  • Page 384: Assembly 14: Finisher-Buffer, Transport, And Upper Drive

    7500-XXX Assembly 14: Finisher–buffer, transport, and upper drive 7-26 MFP Finisher Service Manual...
  • Page 385 7500-XXX Assembly 14: Finisher–transport and upper drive Asm- Part Units/ Units/ Description Index number option 40X0918 Upper media exit pinch roll assembly 40X0893 Sensor (upper media exit) 40X0919 Upper media exit roll assembly 40X0908 Sensor (upper media bin full) 40X0824 Magnetic catch 40X0888 Bushing 6 mm...

  • Page 386: Assembly 15: Booklet Maker 1

    7500-XXX Assembly 15: Booklet maker 1 7-28 MFP Finisher Service Manual...
  • Page 387 7500-XXX Assembly 15: Booklet maker 1 Asm- Part Units/ Units/ Description Index number option 40X3981 Booklet bin assembly 40X3979 Booklet unit right glide assembly 40X3986 Booklet unit assembly (this comes assembled) 40X3980 Booklet unit left glide assembly 40X3984 Booklet unit cable assembly 40X3983 Booklet bin/diverter cable assembly 40X3982...

  • Page 388: Assembly 16: Booklet Maker

    7500-XXX Assembly 16: Booklet maker 2 Asm- Part Units/ Units/ Description Index number option 40X3961 Booklet diverter gate 40X4118 Booklet path media transport roll assembly 40X3958 Booklet pinch guide assembly 40X4128 Belt idler pulley 40X0899 Booklet media transport roll drive gear 23T 40X3962 Booklet media transport roll torque limiter 40X0880...

  • Page 389: Assembly 17: Booklet Maker

    7500-XXX Assembly 17: Booklet maker 3 Asm- Part Units/ Units/ Description Index number option 40X3991 Booklet stapler unit assembly 40X3990 Booklet manual feed knob 40X3989 Booklet manual feed drive gear 31T 40X3988 Booklet unit catch 7-31 Parts catalog...

  • Page 390: Assembly 18: Booklet Maker

    7500-XXX Assembly 18: Booklet maker 4 Asm- Part Units/ Units/ Description Index number option 40X0825 Sensor (booklet end guide HP) 40X3992 Booklet media entrance drive motor 40X3993 Gear pulley 40/20T 40X3994 Booklet end guide drive belt 40X3996 Booklet paddle drive motor assembly 40X3995 Booklet paddle idler gear 14T 40X3997...

  • Page 391: Assembly 19: Booklet Maker

    7500-XXX Assembly 19: Booklet maker 5 Asm- Part Units/ Units/ Description Index number option 40X3999 Booklet knife sector drive gear 42T 40X0825 Sensor (booklet knife HP) 40X0825 Sensor (booklet knife folding) 40X3998 Booklet knife HP sensor cable assembly 7-33 Parts catalog...

  • Page 392: Assembly 20: Booklet Maker

    7500-XXX Assembly 20: Booklet maker 6 Asm- Part Units/ Units/ Description Index number option 40X4001 Booklet front tamper 40X0825 Sensor (booklet front tamper HP) 40X4002 Booklet front tamper motor 40X4002 Booklet rear tamper motor 40X0825 Sensor (booklet rear tamper HP) 7-34 MFP Finisher Service Manual...

  • Page 393: Assembly 21: Booklet Maker

    7500-XXX Assembly 21: Booklet maker 7 Asm- Part Units/ Units/ Description Index number option 40X4008 Booklet roll drive gear 18T 40X4006 Booklet roll drive gear 16T 40X4007 Booklet idler gear 38/18T 40X4009 Booklet drive gear 16T 40X4010 Folding drive gear 38T 40X4005 Exit roll drive belt 40X4004...

  • Page 394: Assembly 22: Booklet Maker

    7500-XXX Assembly 22: Booklet maker 8 Asm- Part Units/ Units/ Description Index number option 40X4012 Manual feed drive gear 28T 40X4014 Media exit sensor cable assembly 40X4013 Manual feed drive gear 17T 40X4011 Booklet media pinch roll assembly 40X0921 Sensor (booklet unit media exit) 7-36 MFP Finisher Service Manual...

  • Page 395: Assembly 23: Booklet Maker

    7500-XXX Assembly 23: Booklet maker 9 Asm- Part Units/ Units/ Description Index number option 40X4016 Booklet gear 43/14T 40X4024 Booklet gear 39/18T 40X4015 Booklet gear 45T 40X4017 Booklet gear 44/16T 40X4019 Booklet gear 27/34T 40X4023 Booklet sensor interface cable assembly 40X4022 Booklet motor interface cable assembly 40X4021...

  • Page 396: Assembly 24: Finisher-Electronics

    7500-XXX Assembly 24: Finisher–electronics 7-38 MFP Finisher Service Manual...
  • Page 397 7500-XXX Assembly 24: Finisher–electronics Asm- Part Units/ Units/ Description Index number option 40X0931 Bridge unit interface card assembly 40X0932 Bridge unit connect cable assembly 40X0933 Bridge unit interface card cable assembly 40X0934 Finisher controller card assembly 40X0935 AC power cord assembly 40X0936 Finisher LVPS card assembly 7-39...

  • Page 398: Assembly 25: Finisher-Cables 1

    7500-XXX Assembly 25: Finisher–cables 1 7-40 MFP Finisher Service Manual...

  • Page 399: Index

    7500-XXX Assembly 25: Finisher–cables 1 Asm- Part Units/ Units/ Description Index number option 40X0942 Upper media exit sensor cable assembly 40X0940 Finisher media entrance sensor cable assembly 40X0941 Buffer path sensor cable assembly 40X0937 Main sensor cable assembly 40X0946 Finisher LVPS cable assembly 40X0892 Sensor (lower media exit) assembly •...
  • Page 400 7500-XXX Assembly 26: Finisher–cables 2 Asm- Part Units/ Units/ Description Index number option 40X0922 Diverter gate sensor upper cable assembly 40X0944 Punch main drive cable assembly 40X0950 Diverter gate sensor lower cable assembly 40X0865 Punch waste box set cable assembly 40X0947 Interlock switch cable assembly 40X0945...
  • Page 401 7500-XXX Assembly 27: Finisher–cables 3 Asm- Part Units/ Units/ Description Index number option 40X0938 Main drive cable assembly 40X0930 Punch waste box full cable assembly 40X0932 Bridge unit connect cable assembly 40X0931 Bridge unit interface card assembly 40X0939 Finisher interface cable assembly 40X0870 Stapler unit cable assembly 7-43...
  • Page 402 7500-XXX 7-44 MFP Finisher Service Manual...
  • Page 403 7500-XXX Index error code messages - finisher 2-10 service checks - finisher accessing service menus Diagnostic Menus 1-36 acronyms entering diagnostic menus Diagnostics Menus available tests belts 3-11 4-113 EVENT LOG buffer/transport 3-13 Clear the Event Log 4-99 entrance/paddle 3-12 Display the Event Log 4-111 exit...
  • Page 404 7500-XXX 2-25 4-81 284.05 sensor (lower media exit) static jam lower media exit roll assembly 2-28 4-89 286.00 sensor (compiler media present) static jam lower pinch guide assembly 2-30 287.00 sensor (upper media exit) on jam A lubrication specifications 2-31 287.01 sensor (upper media exit) off jam A 2-33 287.05 sensor (upper media exit) static jam A...
  • Page 405 7500-XXX 4-43 4-24 punch carriage shift motor assembly rear upper cover 4-46 4-21 punch media stop assembly right eject cover 4-45 4-22 punch unit assembly right lower low voltage power supply (LVPS) cover 4-47 4-16 punch unit motor assembly sensor (bridge unit media entrance) 4-17 sensor (bridge unit media exit) 4-92...
  • Page 406 7500-XXX 4-67 media eject clamp HP 4-79 media eject shaft HP 4-49 punch cam front 4-51 punch carriage shift HP 4-49 punch hole select 4-49 punch unit HP 4-48 punch unit motor encoder punch unit side reg 1 punch unit side reg 2 4-44 punch unit side registration pair with bracket 4-53...

  • Page 407: Part Number Index

    7500-XXX Part number index Description Page 40X0810 Bridge unit assembly docking screw - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40X0811 Bridge unit assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40X0812...
  • Page 408 7500-XXX 7-13 40X0850 Sensor (stacker bin level encoder) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40X0850 Sensor (stacker bin no media) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-13...
  • Page 409 7500-XXX 7-25 40X0909 Media entrance roll assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40X0910 Drive motor (buffer/transport) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-27...
  • Page 410 7500-XXX 7-29 40X3981 Booklet bin assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 40X3982 Booklet controller card power cable assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-29...
  • Page 411 Finisher Buffer Diverter BUFFER DIV SOLENOID(PULL)+24VDC Front Tamper Solenoid BUFFER DIV SOLENOID(PUSH)+24VDC Motor Stacker Bin Eject Clamp I/L+24VDC Lift Motor Motor EJECT CLAMP MOTOR CCW ON(H)+24VDC TRANSPORT GATE SOLENOID(PULL)(L)+24VDC EJECT CLAMP MOTOR ON(H)+24VDC TRANSPORT GATE SOLENOID(PUSH)(L)+24VDC ENT/PAD MOT/B Finisher Diverter Solenoid I/L +24VDC Rear...

This manual is also suitable for:

X852eX854eX860deX862deX864de

Table of Contents
