Run Machine; Sweeping Operation - Kärcher KM 100 R B Operating Instructions Manual

Operating instructions
! Side brush switch in its upper
position
Applies only to KM 100/100 R B
! Depress choke lever (applicable
only in cold or wet weather
conditions)
— Push the choke lever back home
when the engine is running
KM 100/100 R B / KM 100/100 R LPG
Applies only to
KM 100/100 R LPG
! Press the remote button (only
when the weather is cold or wet)
— Release the remote button when
the ignition is on
! Turn ignition key beyond
position 1
! When the machine starts, release
ignition key
Note:
Never actuate the starter motor for
more than 10 s.
Wait at least 10 s before actuating
the starter motor again.

Run machine

Prior to start of the machine
! Main brush switch in its upper
position
! Side brush switch in its upper
position
Freewheel lever of axle drive must
be in its bottom position
! Start machine
Drive forwards
! Slowly press the driving pedal
Drive backwards
! Slowly press the driving pedal
Note:
Driving behaviour
— The driving speed can be varied
continuously with the driving
pedals.
— Avoid abrupt actuation of the
pedal because this could damage
the hydraulic system.
— Slightly release drive pedal if
power decrease is registered
uphill.
Braking
! Release the driving pedal; the
machine brakes automatically
and comes to a standstill.
English

Sweeping operation

Warning!
In order to avoid damaging the floor
do not operate the sweeper while it
is stationary.
! Lower main brush
— Sweeping with the main brush
! The coarse-dirt flap must be
briefly raised for sweeping in
largish objects up to a height of
60 mm, e.g. drinks cans.
30
