TECHNICAL DATA 3-WAY ECO-i MULTI SYSTEM 5 series Outdoor Unit Class Model Name SPW-C0705DZH8 SPW-C0905DZH8 SPW-C1155DZH8 SPW-C1305DZH8 SPW-C1405DZH8 Indoor Unit Class SPW- SPW- SPW- SPW- SPW- SPW- SPW- SPW- SPW- 4-Way Air Discharge XDR74GXH56(A/B) XDR94GXH56(A/B) XDR124GXH56(A/B) XDR164GXH56(A/B) XDR184GXH56(A/B) XDR254GXH56(A/B) XDR364GXH56(A/B) XDR484GXH56(A/B) XDR604GXH56(A/B) Semi-Concealed X075XH X095XH...
Page 4 Contents Section 1: OUTLINE OF 3-WAY ECO-i SYSTEM ..............1-1 Line-up ......................1-2 Features of 3-WAY ECO-i SYSTEM ..............1-4 Section 2: DESIGN OF 3-WAY ECO-i SYSTEM ..............2-1 Model Selecting and Capacity Calculator ............2-2 System Design ....................2-18 Electrical Wiring .....................2-24 Installation Instructions ..................2-30 Section 3: Control of 3-WAY ECO-i SYSTEM ................3-1 Main Operating Functions ................3-3 Wireless Remote Controller ................3-5...
Page 5 Outline of 3-WAY ECO-i SYSTEM Contents 1. OUTLINE OF 3-WAY ECO-i SYSTEM 1. Line-up ..........................1-2 2. Features of 3-WAY ECO-i SYSTEM..................1-4 2-1. Outline of 3-WAY ECO-i SYSTEM ................1-4...
Page 6: Line-Up
Outline of 3-WAY ECO-i SYSTEM 1. Line-up Indoor units Type Capacity: kW 2.8 (9,600) 3.6 (12,000) 4.5 (15,000) 5.6 (19,000) 7.3 (25,000) 9.0 (30,000) 10.6 (36,000) 14.0 (47,800) 16.0 (54,600) 2.2 (7,500) (BTU/h) Cooling 2.5 (8,500) 3.2 (11,000) 4.2 (14,000) 5.0 (17,000) 6.3 (21,000) 8.0 (27,000)
Page 7: Outdoor Unit
Outline of 3-WAY ECO-i SYSTEM 1. Line-up Outdoor units DC inverter unit Type Capacity: kW (BTU/h) 22.4 (76,400) 28.0 (95,500) 33.5 (114,300) / 25.0 (85,300) Cooling / Heating / 31.5 (107,500) / 37.5 (128,000) Air direction Outdoor Unit Space for creating on-site holes (Maximum hole size ø48) C0705DZH8 C0905DZH8...
Page 8: Features Of 3-Way Eco-I System
Inverter unit Since all pipings are concentrated CONCENTRATION into one pipe shaft, you can minimize piping space and construction labor * SANYO makes it possible to link outdoor unit CONNECTION together for a large capacity (48HP). Solenoid valve kit Indoor unit...
Page 9 Outline of 3-WAY ECO-i SYSTEM 2. Features of 3-WAY ECO-i SYSTEM Dimensions 8, 10, 12, 14, 16 HP SPW-C0705DZH8 10HP SPW-C0905DZH8 12HP SPW-C1155DZH8 14HP SPW-C1305DZH8 16HP SPW-C1405DZH8 Installation hole (Installation hole pitch) ( × 4 corners) Unit: mm (Top plate dimensions)
Page 10 Outline of 3-WAY ECO-i SYSTEM 2. Features of 3-WAY ECO-i SYSTEM Capacity control The compressor combination (DC inverter compressor + constant-speed compressor) allows smooth capacity control from 0.8 HP to 48 HP. Realization of smooth capacity control from In case of 16 HP system 0.8 HP to 48 HP Capacity For the outdoor units of 8, 10, 12, 14 and 16 HP, a DC...
Page 11: Indoor Unit
Design of 3-WAY ECO-i SYSTEM Contents 2. DESIGN OF 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator ............... 2-2 1-1. Operating Range ......................2-2 1-2. Procedure for Selecting Models and Calculating Capacity .......... 2-3 1-3. Design of Tubing Length ....................2-4 1-4.
Page 12: Model Selecting And Capacity Calculator
Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-1. Operating Range Heating and Cooling Operating range –5 –10 –15 –20 Indoor air intake temp. °C (DB) Heating Cooling Operating Operating range range –5 –10 –15 –20 Indoor air intake temp. °C (DB) –5 –10 Indoor air intake temp.
Page 13: Model Selecting And Capacity Calculator
Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-2. Procedure for Selecting Models and Calculating Capacity Model Selection Procedure Select the model and calculate the capacity for each refrigerant system according to the procedure shown below. Calculation of the indoor air-conditioning load Calculate the maximum air-conditioning load for each room or zone.
Page 14 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-3. Design of Tubing Length Select the installation location so that the length and size of refrigerant tubing are within the allowable range shown in the figure below. > Main tubing length LM = LA + LB …...
Page 15 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator NOTE The outdoor connection main tubing (LO portion) is determined by the total capacity of the outdoor units that are connected to the tube ends. If the longest tubing length (L1) exceeds 90 m (equivalent length), increase the sizes of the main tubes (LM) by 1 rank for the discharge tubes, suction tubes, and narrow tubes. (field supplied) If the longest main tube length (LM) exceeds 50 m, increase the main tube size at the portion before 50 m by 1 rank for the suction tubes and discharge tubes. (field supplied) (For the portion that exceeds 50 m, set based on the main tube sizes (LA) listed in the table on the following page.) Refrigerant Charge Amount at Shipment (for outdoor unit) SPW-C0705DZH8 SPW-C0905DZH8 SPW-C1155DZH8 (kg) 11.8 11.8 11.8 SPW-C1305DZH8 SPW-C1405DZH8 (kg) 11.8 11.8 Additional Refrigerant Charge Additional refrigerant charge amount is calculated from the liquid tubing total length as follows.
Page 16: Tubing Size
Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Tubing size Main Tubing Size (LA) Unit: mm 22.4 33.5 40.0 45.0 50.4 56.0 61.5 68.0 73.0 78.5 85.0 90.0 96.0 28.0 Total system horsepower Combined outdoor units ø28.58 ø28.58 ø19.05 ø22.22 ø25.4 Suction tubing (mm) ø31.75...
Page 17 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Outdoor Unit Tubing Connection Size Narrow tubing size Amount of refrigerant charge/m (g/m) ø6.35 ø9.52 ø12.7 ø15.88 ø19.05 ø22.22 Indoor Unit Tubing Connection Unit: mm Indoor unit type Distribution ø19.05 Suction tubing (mm) ø15.88...
Page 18 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Installation standards Relationship between A/C units and the refrigerant tubing 4-tube layout 3-tube layout Solenoid 2-tube layout Outdoor unit Outdoor unit Indoor unit valve kit Suction tube Suction tube Wide tube (gas) Discharge tube Discharge tube...
Page 19 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Straight equivalent length of joints Design the tubing system by referring to the following table for the straight equivalent length of joints. Straight Equivalent Length of Joints Wide tubing size (mm) 12.7 15.88 19.05...
Page 20 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-4. Check of Limit Density Check of limit density Always check the gas den- WARNING sity limit for the room in which the unit is installed. When installing an air conditioner in a room, it is neces- Minimum indoor volume and floor area as against the sary to ensure that even if the refrigerant gas accident- amount of refrigerant is roughly as given in the follow-...
Page 21 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-5. Calculation of Actual Capacity of Indoor Unit Calculating the actual capacity of each indoor unit Because the capacity of a multi air-conditioner changes according to the temperature conditions, tubing length, elevation difference and other factors, select the correct model after taking into account the various correction val- ues.
Page 22 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator <Heating> Outdoor unit corrected heating capacity (5) = Outdoor unit rated heating capacity × Correction coefficient for model ((1) Page 2-13) × Correction coefficient for outdoor temper- ature conditions ((2) Page 2-13) × Correction coefficient for tubing length and elevation difference ((3) Page 2-14) ×...
Page 23 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Refer to the graph below for the correction coefficients for Ruc and Ruh. Indoor unit capacity correction coefficient for Ruc (cooling) Indoor unit capacity correction coefficient for Ruh (heating) 0.8 0.9 1.1 1.2 1.8 1.9...
Page 24 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Graph of indoor unit capacity characteristics (2 – (2)) Indoor unit cooling capacity characteristics Indoor unit heating capacity characteristics indicates the rating point. indicates the rating point. 15 16 17 18 19 20 21 22 23 24 25 26 27 14 15 16 17 18 19 20 21 22 23 24 25 Indoor air intake temp.
Page 25 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator 1-6. Capacity Correction Graph According to Temperature Condition Capacity characteristics (The corrected capacity for specific temperature conditions can be found from the graphs below.) <Heating> <Cooling> 50Hz: 8HP 50Hz: 10HP * Broken line indicates 14, 16 HP DC inverter unit WB = 22°C Indoor air intake temp.
Page 26 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator Rated performance values <50Hz models> Cooling Heating Item Cooling Power Heating Power capacity consumption capacity consumption Type Type (kW) (kW) (kW) (kW) 22.4 5.93 25.0 6.11 28.0 8.12 31.5 7.97 33.5 9.82...
Page 27 Design of 3-WAY ECO-i SYSTEM 1. Model Selecting and Capacity Calculator If the maximum tubing length (L1) exceeds 90 m (equivalent length), increase the tubing size of the main liquid, suction and discharge tubes (LM) by one rank. However, the upper limit for the suction and discharge tube size is ø41.28. Increasing the tubing size of the suction and discharge tubes can reduce the loss of capacity caused by longer tubing lengths.
Page 28: System Design
Design of 3-WAY ECO-i SYSTEM 2. System Design 2-1. System Example (1) Below are the tables created using the “Sanyo PAC/GHP System Diagram Software.” Details of the calculations are shown in (2). Outdoor Outdoor unit 1 unit 2 50 m...
Page 29 Design of 3-WAY ECO-i SYSTEM 2. System Design Indoor unit changes The indoor unit in room 4, where the corrected indoor unit capacity is less than the maximum load, is increased by one rank. Room 1 Room 2 Room 3 Room 4 Outdoor unit (indoor unit 1) (indoor unit 2) (indoor unit 3) (indoor unit 4)
Page 30 Design of 3-WAY ECO-i SYSTEM 2. System Design (3) Increasing the size of the refrigerant tubing Increasing the tubing size of the suction and discharge tubes can reduce the loss of capacity caused by longer tubing lengths. (Only the main suction and discharge tubes with the largest tube diameter (main tube LA and main tubes after the distribution point that are the same size as LA) can be changed.) In this case, it is necessary to recalculate the actual indoor unit capacities.
Page 31 Design of 3-WAY ECO-i SYSTEM 2. System Design Additional refrigerant charge before extension Liquid tube Tubing length (m) Additional refrigerant charge (A) × (B) kg diameter per 1 m (kg/m) (B) ø12.7 0.128 0.256 ø12.7 0.128 0.128 ø9.52 0.056 0.056 ø15.88 0.185 3.700...
Page 32 Design of 3-WAY ECO-i SYSTEM 2. System Design Checking of limit density The limit density judgment is made based on the room with the indoor unit having the smallest capacity in the system after extension. The volume of the room where a type 96 indoor unit is used (connected to tubing L11) is calculated as follows: floor area 15 m × Ceiling height 2.7 m = 40. 5 m From the graph below, the minimum room volume for 52.05 kg of refrigerant is 168 m (floor area 62 m Therefore an opening for ventilation is required. <Judgment by calculation> ( Total refrigerant charge amount : kg ) ( Minimum Indoor volume where indoor unit is installed : m 52.05 (kg) = 1.29 (kg/m ) >...
Page 33 1 unit, a trap or ball valve must be added to that distribution joint. (When adding the ball valve, locate it within 40 cm of the distribution joint.) Types of vertical trap specifications (Consult with SANYO separately concerning the (When using ball valve) ball valve.) Main tubing...
Page 34: Electrical Wiring
Time delay fuse or Time delay fuse or circuit capacity circuit capacity Wire size Max. length Wire size Max. length 6 mm 92 m 35 A SPW-C0705DZH8 6 mm 92 m 30 A 6 mm 70 m 35 A SPW-C0905DZH8 6 mm...
Page 35 Design of 3-WAY ECO-i SYSTEM 3. Electrical Wiring 3-3. Wiring System Diagrams Indoor unit (No. 1) Power supply Outdoor unit 220-240V 50/60Hz INV unit Power supply Ground Remote 380-415V-3N 50Hz controller Ground Ground Ground Ground Ground Indoor unit (No. 2) Inter-outdoor-unit control wiring Power supply Ground...
Page 36 Design of 3-WAY ECO-i SYSTEM 3. Electrical Wiring CAUTION When linking outdoor units in a network (S-net link system), disconnect the terminal extended from the short plug (CN003, 2P Black, location: right bottom on the outdoor main control PCB) from all outdoor units except any one of the outdoor units.
Page 37 Design of 3-WAY ECO-i SYSTEM 3. Electrical Wiring Use shielded wires for inter-unit control wiring (c) and ground the shield on both sides, otherwise misoperation from noise may occur. Connect wiring as shown in Section 3-3.“Wiring System Diagrams.” Loose wiring may cause the terminal to overheat or result in unit malfunction.
Page 38 Design of 3-WAY ECO-i SYSTEM 3. Electrical Wiring Necessity of setting changes by combination of each method Type of combination: Necessity of setting Method 1 only: Setting is unnecessary. Method 2 included: Setting up in common use of a solenoid valve kit from “Remote Control” is necessary. * * Method 2 only is set. * Method 3 excluded Method 3 included: Setting up in common use of a solenoid valve kit from “Remote Control” is necessary. * * Setting all connected indoor units *1: Refer to “Test Run” for setting instructions. Please note the following system example is prohibited and avoid the following connection. Solenoid Solenoid valve kit valve kit Indoor unit...
Page 39 Design of 3-WAY ECO-i SYSTEM 3. Electrical Wiring How to connect wiring to the terminal Stranded wire For stranded wiring Cut the wire end with cutting pliers, then strip the Ring pressure insulation to expose the stranded wiring about 10 terminal mm and tightly twist the wire ends. Using a Phillips head screwdriver, remove the ter- minal screw(s) on the terminal plate. Using a ring connector fastener or pliers, securely Special clamp each stripped wire end with a ring pressure Screw washer terminal. Ring pressure Screw and Place the ring pressure terminal, and replace and terminal Special washer tighten the removed terminal screw using a screw- Terminal plate Wire driver.
Page 40: Installation Instructions
Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions Ceiling-Mounted Type 4-1. Indoor Unit Ceiling AVOID: Areas where leakage of flammable gas may be expected. Places where large amounts of oil mist exist. Wall Direct sunlight. Locations near heat sources which may affect the per- Min. n. 25 cm Min. n. 25 cm formance of the unit. Front view Locations where external air may enter the room directly. NOTE This may cause “sweating” on the air discharge ports, The rear of the indoor unit can be installed flush against the causing them to spray or drip. wall. Locations where the remote controller will be splashed with water or affected by dampness or humidity. discharge Installing the remote controller behind curtains or furniture. Locations where high-frequency emissions are generated. Air intake Min.
Page 41 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions Total Heat Exchanger with DX coil The distance between the indoor unit and any obstruc- NOTE tions should be as shown in the ﬁ gure below. There is a packaging bracket located on each of the four If installing in a highly humid location, give consideration product corners.
Page 42 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-3. Shield for Horizontal Exhaust Discharge It is necessary to install an air-discharge chamber (field supply) to direct exhaust from the fan horizontal- ly if it is difficult to provide a minimum space of 2 m between the air-discharge outlet and a nearby obsta- cle. In regions with heavy snow- fall, the outdoor unit should CAUTION be provided with a solid, raised platform and snow- proof vents. 4-4.
Page 43: Unit Installation
Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-6. Dimensions of Wind Ducting Reference diagram for air-discharge chamber (field supply) - 1 Unit: mm Ceiling panel Ceiling panel Air direction: Front direction Air direction: Right direction 890 (Ceiling panel dimensions) 1106 1106 (Maximum bracket dimensions)
Page 44 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-7. Dimensions of Snow Ducting Reference diagram for snow-proof vents (field supply) Air direction: Right direction example Air direction: Front direction example Ceiling panel Ceiling panel (Air intake duct) Unit: mm 1710 (Air outlet duct) (Ceiling panel (Ceiling panel...
Page 45 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-8. Optional Distribution Joint Kits See the installation instructions packaged with the distribution joint kit for the installation procedure. Model name Capacity after distribution joint Remarks 1. APR-CHRZP680BGB 68.0 kW or less For outdoor unit greater than 68.0 kW and no more than 135.0 kW 2.
Page 46 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 3. APR-RZP224BGB Use: For indoor unit (Capacity after distribution joint is 22.4 kW or less.) Example: (F below indicates inner diameter . below indicates outer diameter.) Discharge pipe Suction pipe Liquid pipe Insulator Insulator Insulator...
Page 47 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-9. Optional Solenoid Valve Kit ATK-RZP56BGWB Cool with damp cloth or other means when Part brazing the joint with a torch. Otherwise, the Types and specifications of tubing connections number solenoid valve will be damaged. Gas tube Gas tube: ø12.7 Liquid tube: ø6.35...
Page 48 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions ATK-RZP160BGWB Cool with damp cloth or other means when Part brazing the joint with a torch. Otherwise, the Types and specifications of tubing connections number solenoid valve will be damaged. Gas tube Gas tube: ø15.88 Liquid tube: ø9.52 Suspension hook...
Page 49 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-10. Transporting (2) Be sure the rubber vibration insulator and platform ex- When transporting the unit, have it delivered as close tend to the inside of the legs. In addition, the washers to the installation site as possible without unpacking.
Page 50 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 4-12. Routing the Tubing The tubing can be routed out either from the front or When cutting the tubing, use a tube cutter, and be from the bottom. (Fig. 4-15) sure to remove any burrs. (The same applies to distribution tubing (optional).) The connecting valve is contained inside the unit.
Page 51 Design of 3-WAY ECO-i SYSTEM 4. Installation Instructions 115 type (12 horsepower) Refrigerant tube port: Use caulking, putty, or a similar material to fill any gaps at the refrigerant tube port ( ) in order to prevent rainwater, dust or foreign substances from entering the unit. * Perform this work even if the tubing is routed out in a downward direction. Base plate Tubing cover Connection Use supplied Refrigerant tubing method connector tube? Suction tube Brazed connection Yes (ø19.05 ø25.4) Tubing routed out forward Tubing routed out downward Discharge tube Brazed connection Yes (ø15.88 ø19.05) Valve cap Liquid tube Brazed connection Yes (ø9.52 ø12.7) Balance tube Flared connection...
Page 52 – MEMO – 2-42...
Page 53: Table Of Contents
Control of 3-WAY ECO-i SYSTEM Contents 3. Control of W-2WAY ECO-i SYSTEM 3. Control of 3-WA Y ECO-i SYSTEM 1. Main Operating Functions ....................3-3 1. Main Operating Functions ....................3-3 1-1. Room Temperature Control ...................3-3 1-1. Room Temperature Control ...................3-3 1-2. Automatic Control for Heating and Cooling ..............3-4 1-2.
Page 54 Control of 3-WAY ECO-i SYSTEM Contents 5. Schedule Timer .........................3-70 Schedule Timer / SHA-TM64AGB ..................3-70 Operation Buttons ......................3-70 Display ..........................3-71 Using the Schedule Timer ....................3-71 Setting the Present Time ....................3-72 Setting Today's Day of the Week ..................3-73 Setting Up Programmed Operations ................3-74 Setting Errors ........................3-76 How to Check Program Times ..................3-77 How to Copy Program Times ..................3-78 How to Copy Group Programs ..................3-80 How to Set Holidays in a Scheduled Week of Operation ..........3-82 How to Clear Programs ....................3-84 Schedule Timer and Air Conditioner Operation ..............3-85 Power Outages .......................3-86 Troubleshooting .......................3-87 Accessories for Schedule Timer ..................3-88 Installing the Schedule Timer .
Page 55: Main Operating Functions
Control of 3-WAY ECO-i SYSTEM 1. Main Operating Functions 1-1. Room Temperature Control The thermostat is turned ON/OFF according to T as shown below. T = Room temperature - Set temperature When remote controller sensor Room temperature = Temperature detected by the remote controller sensor is used When body sensor is used Room temperature = Temperature detected by the body sensor - Intake shift temperature*...
Page 56 Control of 3-WAY ECO-i SYSTEM 1. Main Operating Functions 1-2. Automatic Control for Heating and Cooling Automatic Heating/Cooling Control (1) When operation starts, heating or cooling is selected according to the set temperature and the room temperature. Room temperature Set temperature + 1 Cooling Set temperature –...
Page 57: Wireless Remote Controller
Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1. Optional Controller (Remote Controller) Wireless Remote Controller / RCS-SH80BG.WL / RCS-TRP80BG.WL / RCS-SS80BG.WL / RCS-BH80BG.WL / RCS-XM18BG.WL One remote control can control a group of up to eight indoor units. 1-1.
Page 58 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RECEIVER RCS-SH80BG.WL RCS-TRP80BG.WL 1. Receiver Receives the signal sent from the remote control. 2. Emergency Display lamps When an error occurs, one of the operation button lamps flashes. When a display lamp is blinking, refer to "...
Page 59 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1-2. Installing Batteries 1. Remove the cover. 2. Insert two AAA alkaline batteries. Put the batteries in with the polarity [+/–] as shown in the figure. 3. Gently insert one end of an unfolded paper clip (or a similar object that can fit) into the Reset hole and press the Reset button inside the hole and then put the cover back on.
Page 60 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1-5. Timer Operation When setting the timer, make sure the current time on the remote control is accurate. The timer’s clock can only be set when the display of the remote control is ON. After setting the timer, put the remote control in a place where its signal will reach the receiver of the indoor unit.
Page 61 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1-7. Operating Multiple In/Outdoor Units Simultaneously (Group Control) Indoor Unit Group control works well for providing air conditioning to one, large room with more than one air conditioning units. Receiver Indoor Unit One remote control can operate up to eight indoor units.
Page 62 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller Address Display on the Remote Control RCS-SH80BG.WL For 1, 2 and 3, set the switch on the left and for 4, Position of The position of the 5 and 6, to the right. receiver’s receiver’s address (inside indoor...
Page 63 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1-11. Emergency Operation Use [Emergency Operation] in the following situations when there is an urgent need. When the remote control’s batteries have failed. When the remote control is broken. When the remote control is lost. Figures: RCS-SH80BG.WL and RCS-TRP80BG.WL are of receivers (inside indoor unit), RCS-SS80BG.WL is of the operation panel (inside indoor unit) and Indoor Unit (K type) is of its front panel.
Page 64 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 1-12. Miscellaneous Settings A variety of changes can be made to settings, depending on the indoor unit being used. Wind Direction (flap) indicator, operation mode indicator, time display (24 hour, AM/PM), Heat Max Temp For information about the flap function, refer to the users’...
Page 65: How To Install The Wireless Remote Controller Receiver
Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2. How to Install the Wireless Remote Controller Receiver Common to All Models 2-1. Warning about Installation of Receivers The wireless remote uses a very weak infrared light for its signal, which can result in the signal not being received because of the following influences, so take care in where the unit is installed.
Page 66 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RCS-SH80BG.WL 2-4. Accessories Accessories Quantity Accessories Quantity Receiver AAA alkaline batteries Users Manual Truss Self-Tapping Screw s 4 X 16 Remote Controller Cable clamp Remote Control Holder Clamp fixing screw 4 X 12 2-5.
Page 67 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2-6. Wiring the Receiver Unit Wiring Diagram Indoor Unit Receiver PCB CN001 Terminal Strip for White Wiring Remote Black Controls Connections Connect the wires from the receiver to the remote control terminal strip on the indoor unit. (Polarity does not matter.) 2-7.
Page 68 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RCS-TRP80BG.WL 2-9. Accessories Accessories Quantity Accessories Quantity Receiver AAA alkaline batteries Users Manual Remote controller Truss self-tapping screws 4 X 16 Remote control holder Cable tie 2-10. Installing the Receiver Unit Ceiling Suspended Model (1) Open the air inlet grille on the side panel, remove the 1 screw and then move it toward the front (direction of the arrow) and remove it.
Page 69 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller Unidirectional cassette model for high ceilings/Unidirectional ceiling cassette model 1 While spreading the tabs of the cover, pull it out from the panel to the front. (Fig. 3-10) 2 Pass the lead wire through the panel and install the receiver in the hole in the panel. (The projecting parts of the receiver hold it in the hole in the panel) 3 Press the lead wire from the receiver in along the rib on the back of the panel.
Page 70 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2-12. Test Operation Implementing a Test Run S003 Bit 1: OFF 1. Turn the #1 DIP switch [S003] on the receiver’s PCB from OFF to ON and operate the wireless remote control with its Start/Stop button. 2.
Page 71 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RCS-SS80BG.WL 2-14. Accessories No . Accessories Quantity No . Accessories Quantity Operation panel AAA alkaline batteries Users Manual Display Truss self-tapping screws 4 X 16 Remote control Pan head self-tapping screws 4 X 10 Remote control holder Plastic clamp L150...
Page 72 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller Metal Panel Installing the Operation Panel 1 Remove the 2 screws and remove cover A from the back of the panel. (Fig. 3-19) 2 Fasten the operation panel to the location in the diagram below with the 2 enclosed screws (4 X10). (Fig. 3-20) 3 Pass the wiring for the display (W2, 6P white connector) through the back of the panel.
Page 73 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2-17. Test Operation DIP Switch Bit 1 Implementing a Test Run 1. Turn the #1 DIP switch of the operation panel from OFF to ON (Down Up) and operate the wireless remote control with its Start/Stop button. 2.
Page 74 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RCS-BH80BG.WL 2-19. Accessories Accessories Quantity Accessories Quantity Receiver Users Manual (Enclosed 200 mm wiring) Truss self-tapping screws 4 X 16 Remote controller Machine screws Remote controller's holder Wood screws AAA alkaline batteries Cable tie 2-20.
Page 75 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller When using a receiver that has been installed separately into the ceiling, use the enclosed fittings for installing to a ceiling. (1) Remove the metal plate of the receiver by slipping a flat head screwdriver or the like into the cut- out on the bottom.
Page 76 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2-22. Setting Address Switches When more than one receiver and remote control are installed in the same room, setting up addresses allows them to avoid interfering with each other. Refer to the Users Manual for information on how to change the addresses of the remote controls. Changing the address of a receiver can be done after removing the screw to the receiver’s PCB cover.
Page 77 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller RCS-XM18BG.WL 2-24. Accessories Accessories Quantity Accessories Quantity Receiver Remote Control Holder AAA alkaline batteries Tapping screw 4x16 Remote Controller Clamper 2-25. Installing the Receiver Unit As the receiver can only be installed in the corner where the panel wire comes out, as shown in Fig. 3-32, consideration should be given to orientation when fitting the panel to the indoor unit.
Page 78 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller Pass the wire from the wireless receiver through the grille. (Fig. 3-34) Fit the panel to the indoor unit and connect the wire from the receiver to the connector (CN130/WL/WHT/10P) on the indoor control board. (Fig. 3-35) After fixing the panel in place, fit the receiver to the panel taking care not to trap the wire from the receiver.
Page 79: Common To All Models
Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller Common to All Models 2-26. The Self-Diagnosis Function Display and What is Detected Alarm Display in the table below indicates the content of alarms that are displayed when a wired remote control is connected.
Page 80 Control of 3-WAY ECO-i SYSTEM 2. Wireless Remote Controller 2-28. Setting Up Remote Control Functions The functions of the wireless remote can be set on site. (These settings are saved in nonvolatile memory in the remote control, so even when its batteries are changed, the settings do not revert to the defaults.) NOTE The operation of the air conditioner can be impacted, depending on the settings made, so only service personnel...
Page 81: Timer Remote Controller
Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Timer Remote Controller/RCS-TM80BG How to Use the Timer Remote Controller Operating buttons Display 15 14 29 26 3-29...
Page 82 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Names and Operations Operation Section (Refer to the previous page) (Start/Stop) button (Ventilation) button Pushing this button starts, and pushing again stops the Use this button when you installed a fan available in the market.
Page 83 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Display Section (Refer to the page 3-29) (Operation mode change control) indication (Setting) indication Displays when an operation mode is entered by the re- Appears when the timer program is being set. mote control unit, while another operation mode has been (Unit) indication already selected.
Page 84 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Setting the Present Time Press and hold for more than 2 seconds to enter in the present day and time setting mode. Once you enter in the setting mode, , “ ”(day) and “time” ﬂ ash. Set “...
Page 85 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Weekly Program Function Checking Weekly Timer Set the weekly program assigning a given timer to each day of the week. Maximum of 6 programs a day and 42 programs a week can be set. Select the day and the TIMER number you want to program.
Page 86 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Changing the Program Timer To set the weekly program, follow the steps below. Select the program you want to set in the program conﬁ rmation mode, and press . The enters the setting mode of the program currently displayed.
Page 87 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Weekly Program Function (Continued) Pattern 1 4. Set the program pattern. (program step 3) There are 4 program patterns. Pressing repeats the following display patterns. Pattern 2 Pattern 1 The indoor unit starts operation at the programmed time.
Page 88 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Deleting the Program Timer To delete the program timer setting, follow the steps below. Press to enter the program conﬁ rmation mode. Press to select the day of the program you want to de- lete.
Page 89 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Weekly Program Function (Continued) Duplicating the Program Timer You can duplicate the preset program by day. Select the copy source. is pressed in program checking mode , it enters the copy mode (Selecting the copy source ) of the pro- gram timer.
Page 90: Outing Function
Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Outing Function Outing function is a function that prevents the room temperature from increasing too much (or decreasing too much) when no one is in the room. An air conditioner works automatically if this function is set effective. General Performance of the Outing Function COOL / DRY The air conditioner starts operation when the room temperature increases up to –1...
Page 91 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Outing Function (Continued) Setting the Outing Function Press and hold for more than 2 seconds to display the upper limit temperature setting screen. and the upper limit temperature start ﬂ ashing. (The default value of the upper limit temperature is 38 °C.) Press to select the upper limit temperature and press...
Page 92 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Sleeping Function This function leads you to a comfortable sleep and chang- When the off time comes: es the room temperature during your sleep. The indoor unit stops. You can set the off timer every one hour from 1 to 10 * The temperature returns to the setting at the time when hours.
Page 93 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Sleeping Function (Continued) button does not work. Or if the operation does not start even if is pressed. Check the following table. Item Display of the remote control unit Contents (Lighting/flashing indication) The Error indication flashes The clock is not set.
Page 94: Installation Manual For Timer Remote Controller
Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller INSTALLATION MANUAL FOR TIMER REMOTE CONTROLLER Accessories for remote controller switch Remote controller Wood screws Wire joints Operation manual Installation manual (with 200mm wire) How to install the remote controller Do not supply power to the unit or try to operate it until the tubing and wiring to the outdoor unit is completed.
Page 95: Group Control Using 2 Remote Controllers
Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Use 0.5mm - 1.25mm wires. Provided wire joint (white) Remote controller wiring can be extended to a maximum of Remote controller wiring 500m. (1) Strip the insulation to approximately 14 mm from the ends of the wires that will be connected.
Page 96 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Fig. 3-41 Fig. 3-42 Caution when installing the remote controller *1 Install the remote controller more than 95 mm apart from the wall surface. *2 To install the remote controllers side-by-side, keep the space between each for more than 125 mm. *3 To install the remote controllers one above the other, keep the space between each for more than 25 mm.
Page 97 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Meaning of Alarm Messages Table of Self-Diagnostics Functions and Description of Alarm Displays Alarm Possible cause of malfunction message Remote controller is detecting Error in receiving serial communication signal. (See note) Serial commu- error signal from indoor unit.
Page 98 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Alarm Possible cause of malfunction message Activation of Protective device in outdoor unit Compressor thermal protector is activated. protective is activated. Power supply voltage is unusual. (The voltage is more than 260 V device or less than 160 V between L and N phase.) Incorrect discharge temperature.
Page 99 Control of 3-WAY ECO-i SYSTEM 3. Timer Remote Controller Alarm messages displayed on system controller Error in transmitting serial Indoor or main outdoor unit is not operating correctly. Serial communication signal Mis-wiring of control wiring between indoor unit, main outdoor unit communication and system controller.
Page 100: System Controller
Control of 3-WAY ECO-i SYSTEM 4. System Controller System Controller / SHA-KC64AGB Operation Buttons A: ALL/ZONE/GR ZONE select GROUP select SELECT button button buttons Operation lamp ON button OFF button MODE button Temperature setting buttons M: SET button CHECK I: FAN SPEED button button N: CL button VENTILATION...
Page 101 Control of 3-WAY ECO-i SYSTEM 4. System Controller ON button This button is for turning the selected air conditioner on. OFF button This button is for turning the selected air conditioner off. Operation lamp This lamp lights when the unit is turned on. MODE button Use this button to select one of the following 5 operations: (AUTO)
Page 102 Control of 3-WAY ECO-i SYSTEM 4. System Controller K: CHECK button This button is used only when servicing the air conditioner. Do not use the CHECK button for normal operation. CAUTION L: CENTRAL button Use this button to inhibit individual operation by remote controller as CTRL follows: Individual ON/OFF operation is inhibited.
Page 103 Control of 3-WAY ECO-i SYSTEM 4. System Controller Display Description When the unit is in heating standby status, the indicator appears. The currently selected operation mode is displayed. The currently selected FAN SPEED, Airflow Direction and SWEEP settings are displayed. This indication appears when the filter needs cleaning.
Page 104 Control of 3-WAY ECO-i SYSTEM 4. System Controller How to Start Group Operation To start group operation Stop Power Turn the power supply switch on more than 5 hours before starting operation. Press the SELECT button and select GROUP. Select the ZONE No. including the group to be operated by pressing ZONE button. Select the GROUP No.
Page 105 Control of 3-WAY ECO-i SYSTEM 4. System Controller How to Start Collective Operation To start collective operation (ALL or ZONE) Stop Power Turn the power supply switch on 5 hours or more before starting operation. Press the SELECT button and select ALL or ZONE. In case of ZONE collective operation.
Page 106 Control of 3-WAY ECO-i SYSTEM 4. System Controller How to Install the System Controller Installation site selection Install the system controller at a height of between 1 and 1.5 meters above the floor. Do not install the system controller in a place where it will be exposed to direct sunlight or near a window or other place where it will be exposed to the outside air.
Page 107 Control of 3-WAY ECO-i SYSTEM 4. System Controller Overview of the System Controller Electrical component box Hole for electrical Control unit Unit: mm wiring Mounting plate (for flush mounting) 4-ø5 diameter holes (for mounting) Hole for electrical wiring Rear plate 4-ø5.5 diameter holes (for mounting) Z-view (back side) In order to mount the system controller flush with the wall, an opening...
Page 108 Control of 3-WAY ECO-i SYSTEM 4. System Controller Installation Procedure Mounting plate Electrical component box Hole for electrical wiring a): Normal mounting Rear plate Fig. 3-44 b): Flush mounting Decide how the system controller will be mounted: in the normal manner or flush with the wall.
Page 109 Control of 3-WAY ECO-i SYSTEM 4. System Controller Layout of Electrical Terminals Clamp for electrical wiring Connector (CN02) for weekly timer or schedule timer (optional) P.C. board CN02 Ground for power wiring B3 B2 B1 A3 A2 A1 Fig. 3-45 How to connect electrical wiring Basic wiring Power supply...
Page 110 Control of 3-WAY ECO-i SYSTEM 4. System Controller Basic Wiring Diagram Ensure that wiring connections are correct. (Incorrect wiring will CAUTION damage the equipment.) Outdoor Outdoor Outdoor Outdoor unit 1 unit 2 unit m unit 3 System Power supply controller 50 Hz/60 Hz 220 –...
Page 111: Address Switch Setting
Control of 3-WAY ECO-i SYSTEM 4. System Controller Address Switch Setting To avoid an electric shock hazard, To Installers, DO NOT touch any terminal on the WA R N I N G Printed Circuit Board with a metal After installation and adjust- rod, a screwdriver edge nor a bare ment, be sure to turn the hand when power is supplied.
Page 112 Control of 3-WAY ECO-i SYSTEM 4. System Controller Main/sub selection switch 2 3 4 5 6 7 8 OFF: System controller operates as main controller. ON: System controller operates as sub-controller. ALL/ZONE mode selection switch ALL mode: All indoor units can be controlled by system controller ZONE 1, 2, 3, 4 mode: Indoor units in one of zone 1, 2, 3, or 4 can be controlled by system controller.
Page 113 Control of 3-WAY ECO-i SYSTEM 4. System Controller 2 3 4 5 6 7 8 Weekly timer input switches. Must be set to OFF position. Auxiliary switch Must be set to OFF position. Beep tone switch OFF: Beep tone when each button is pushed. ON: No tone when each button is pushed.
Page 114: Mode Setting
Control of 3-WAY ECO-i SYSTEM 4. System Controller Mode Setting According to function of each system controller, set Central control Remote control SW1 as Fig. 3-49. mode mode Central control/Remote control mode Central control mode 3 4 5 6 3 4 5 6 System controller is used as central control equipment.
Page 115 Control of 3-WAY ECO-i SYSTEM 4. System Controller How to Perform Zone Registration To operate the system controller properly, zone registration is required after finishing the test run (and after setting all indoor unit addresses) using one of the following methods. Zone registration using the remote controller (RCS-TM80BG) Refer to page 3-65 Zone registration using the system controller (SHA-KC64AGB)
Page 116 Control of 3-WAY ECO-i SYSTEM 4. System Controller Zone Registration Table Indoor unit Indoor unit Central Unit Central Unit address ZONE GROUP address GROUP ZONE address location address location (UNIT No.) (UNIT No.) NOTE Assign indoor unit addresses to the desired positions (central addresses) manually.
Page 117 Control of 3-WAY ECO-i SYSTEM 4. System Controller Zone registration using the remote controller (RCS-TM80BG) (Determination of central address) In this case, after confirming which indoor unit is connected to the remote controller and that the air conditioner in the OFF state, you set the central addresses one at a time.
Page 118 Control of 3-WAY ECO-i SYSTEM 4. System Controller Zone registration using the system controller (SHA-KC64AGB) In this case, you set all Central addresses by If no data is system controller at once manually. registered no number Press the buttons at the same is displayed.
Page 119 Control of 3-WAY ECO-i SYSTEM 4. System Controller How to Check Overlapping of Central Address Nos. Press the buttons at the same time for more than 4 seconds. and CODE No. C1 will flash. Select CODE. No. C3 by pressing ( ) button and press the button.
Page 120 Control of 3-WAY ECO-i SYSTEM 4. System Controller System Examples The following diagrams show system examples and the correct setting of the switches on the PCB. For a system without link 3-68...
Page 121 Control of 3-WAY ECO-i SYSTEM 4. System Controller (2) For a system with link 3-69...
Page 122: Schedule Timer
Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Schedule Timer / SHA-TM64AGB Operation Buttons A: PROGRAM button E: HOLIDAY button B: PROG. COPY buttons F: CANCEL button C: CLEAR button G: TIMER OFF button D: Setting buttons PROGRAM button Use to start setting programs and to enter program settings. PROG.
Page 123 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Display A: Today’s day of the week Indicates today’s day of the week. B: Program schedule Appears under days that are scheduled for program operation. indication ( C: Holiday schedule indication Appears around scheduled holidays. D: ERROR indication Displayed when a mistake is made during timer setting.
Page 124 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Setting the Present Time Set the present time. (Example: When the present time is 12:45) STEP 1 Hold down the SET button and press the HH button to set the hour. The hour increases one hour at a time with each single press of the HH button while the SET button is held down.
Page 125 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Setting Today’s Day of the Week Set today’s day of the week. (Example: When today is Wednesday) STEP 1 Hold down the SET button and press the DAY button to set today’s day of the week. blinks and moves one day at a time across the days of the week with each single press of the DAY button while the SET button is held down.
Page 126 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Setting Up Programmed Operations Example settings Correctly set the present time and today’s day of the week. Unless both are correctly set, the programs will not run as expected. Up to 6 programmed operations can be set per day for each group and day of the week.
Page 127 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer STEP 3 Set up the program and press the SET button. Select timer operation with the (timer ON/ OFF) button and (remote controller operation enable/disable) button. Then, set the trigger time with the HH and MM buttons, and press the SET button.
Page 128 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Setting Errors If time is set as shown below while setting up a program, “ERROR” is displayed (the indication blinks). Therefore, correct the time setting. If Program Times are the Same STEP 1 Every time the SET button is pressed, the setting mode switches between programmed operations of the same time setting ( in the above example), therefore select the time setting to correct.
Page 129 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer How to Check Program Times You can check the programmed times for each group and day of the week. STEP 1 Press the GROUP button and select a group whose time you want to check. NOTE Group selection is disabled depending on installation conditions.
Page 130 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer How to Copy Program Times You can copy the already set program of one day into another day (Day Program Copying), as well as copy the entire week programmed for one group into another group (Group Program Copying). Example of Day Program Copying Example of Group Program Copying (Copying Monday’s program into Tuesday)
Page 131 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer STEP 4 Press the SET button to copy. Press the SET button and the program schedule marker ( ) will be displayed. STEP 5 Select other copy destination days if desired. You can copy the selected source day program into other days by repeatedly pressing the DAY button to select a day of the week followed by the SET button to set it.
Page 132 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer How to Copy Group Programs STEP 1 Press the PROG. COPY GROUP button. “CP-1” starts blinking in the present time display area and “CP” (copy) starts blinking in the program area to indicate the copy source. STEP 2 Select a source group program to copy.
Page 133 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer STEP 5 Select other copy destination groups if desired. You can copy the selected source group programs into other groups by repeatedly pressing the GROUP button to select a group followed by the SET button to set it.
Page 134 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer How to Set Holidays in a Scheduled Week of Operation Operations programmed for a specific day during the week can be temporarily disabled by setting that day as a holiday. When the set holiday passes, the holiday setting is canceled and operation is resumed as programmed the following week.
Page 135 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer STEP 4 Press the HOLIDAY button to enter the holiday. The normal display returns. To halt programmed operation for one week or more, you can disable all timer programs. Once the timer has been disabled, programmed operations are not run until the below procedure is performed. NOTE During installation, the remote controller will be set to disable the timer for individual groups.
Page 136 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer How to Clear Programs Press the PROGRAM button. When the PROGRAM button is pressed, the group No. and the present day of the week start blinking and the present time indication changes to a blinking “PG-1”. Press the GROUP button to select a group to clear.
Page 137 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Schedule Timer and Air Conditioner Operation Air conditioners operate either according to operations programmed from the schedule timer (starting/stopping and remote control operation enable/disable) or according to a connected remote controller or system controller. Schedule timer settings (Example) Operation without system controller operation If remote controller operation is enabled, the air conditioner can be started/stopped from the remote controller.
Page 138 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Power Outages If the air conditioner is running when power is lost, the air conditioner remains OFF when power is restored. Also, if remote controller operation was disabled when power was lost, it is enabled for a few minutes when power is restored.
Page 139 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Troubleshooting Before requesting servicing, check the following. Trouble Cause/Remedy blinks on the display. The schedule timer is performing initial communications with connected indoor units. Wait for communications to finish. The timer has been disabled. (Refer to pages 3-76 Air conditioners do not operate as scheduled when and 3-86.) the set time comes.
Page 140 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Accessories for Schedule Timer Supplied parts Supplied parts Q'ty Q'ty T10 power wire Spacers Wire joints (with current fuse) *1 T10 relay wire *2 Operation manual Installation Power wire for manual connection to system controller Machine screws M4 ×...
Page 141 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Installation of Connected Schedule Timers When installing schedule timers (remote controller switches, system controllers, etc.) onto the wall, use the method shown in Figs. 3-58 and 3-59. More than More than More than 95 mm 125 mm More than 125 mm...
Page 142 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Wiring The schedule timer wiring can be connected by the following two methods. Select one of these connection meth- ods according to the actual installation location. When wiring, extend the lengths of the wires using wire joints (provided) and extension wires (field supply). When installing multiple schedule timers, avoid CAUTION the use of cross-over wiring.
Page 143: About The Setting Switches
Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer About the Setting Switches Complete the switch settings before turning ON the schedule timer power. Remote Controller Enable Items (1) Connection (1) If remote controller enable/disable is used, This switch should be OFF for normal this switch sets the range for remote use.
Page 144 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Creating Timer Groups [Setting fixed timer groups] The schedule timer can be set for 6 time status 1 fixed timer group (64 units together) changes. These can be used to create up to 8 Schedule timer 4 fixed timer group (16 units together) groups (timer groups).
Page 145 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer To continue registering addresses, repeat step (3). (Central control address numbers will be added to the right side of the LCD display.) To cancel a registered central control address, use the button in the area to select the timer group, then use the button in the...
Page 146 Control of 3-WAY ECO-i SYSTEM 5. Schedule Timer Installation Work Plan Schedule timer Central Indoor unit control Fixed timer group Use the wired remote controller to check the unit Unit No. Room name addresses System - Indoor No. of the indoor units. (Start the A/C unit with the wired remote con- troller, then press the remote controller UNIT SELECT button once to display the unit No.
Page 147 Control of 3-WAY ECO-i SYSTEM 6. Simpliﬁ ed Remote Controller Simplified Remote Controller / RCS-KR1EG 1. Important Safety Instructions Before using the system, be sure to read these "Important Safety Instructions". After reading this manual, save it in a convenient place. Warning * Installation Precautions 1.
Page 148: Simplified Remote Controller
Control of 3-WAY ECO-i SYSTEM 6. Simplified Remote Controller 2. Names and Operations Operation Section (Start/Stop)button Pushing this button starts, and pushing again stops the unit. (Temperature setting) buttons Changing the temperature setting. (Mode Select) button Pushing this button to select an operation mode. (AUTO /HEAT /DRY /COOL / FAN ). (Fan speed) button Changing the fan speed. (Swing/Air direction) button*1 Use this button to set the auto swing or air direction to a specific angle. *1 Do not move the flap (vertical airflow adjustment board) with your hand.
Page 149 Control of 3-WAY ECO-i SYSTEM 6. Simpliﬁ ed Remote Controller Display Section (Fan mode select) (Centralized control) indication indication Appears when operated in centralized control. The selected fan mode is displayed. If the remote control operation is not permitted to the remote unit, when the (Start/Stop) (Flap position) indication button,...
Page 150 Control of 3-WAY ECO-i SYSTEM 6. Simplified Remote Controller 3. Outing Function Outing function is a function that prevents the room temperature from increasing too much (or decreasing too much) when no one is in the room. An air conditioner works automatically if this function is set effective. General Performance of the Outing Function Outing function COOL / DRY upper limit The air conditioner starts operation when the room temperature increases up to –1°C of the upper limit. The air conditioner stops operation when the room temperature decreases up to –2°C of the upper limit. Room temperature Room temperature HEAT The air conditioner starts operation when the room temperature decreases up to +1°C of the lower limit. The air conditioner stops operation when the room Outing function temperature increases up to +2°C of the lower limit. Lower limit [Precautions] • The outing control only starts/stops the air conditioner. It does not change the operation mode/temperature setting.
Page 151 Control of 3-WAY ECO-i SYSTEM 6. Simplified Remote Controller 4. Basic Installation Parts supplied with simplified remote controller Simplified remote Wood screws Binding strap Instruction manual Installation manual controller Simplified remote controller installation guidelines (Place of installation) 1. Mount the simplified remote controller at a height of 1 to 1.5 meters above the floor where it can sense the average temperature of the room. 2. Do not mount the simplified remote controller in a place exposed to direct sunlight or a place exposed to outside air such as near a window. 3. Do not mount the simplified remote controller behind an object so that it is separated from the air circulation of the room.
Page 152 Control of 3-WAY ECO-i SYSTEM 6. Simpliﬁ ed Remote Controller How to wire the simplified remote controller Connection diagram Terminal block Simplified for wiring remote the remote controller controller of the indoor unit Wiring for simplified remote controller (supplied locally) *1: Use 0.5 mm to 1.25 mm stranded wires.
Page 153 Control of 3-WAY ECO-i SYSTEM 6. Simpliﬁ ed Remote Controller Remote controller setting mode Use the following method to perform simplified remote controller Main/Sub setting and RCU.CK switching. Press both buttons on the remote controller for more than 4 seconds together. ) button to select an item code, and then use button to confirm.
Page 154 Control of 3-WAY ECO-i SYSTEM 6. Simpliﬁ ed Remote Controller Test run setting Press both buttons on the remote controller for more than 4 seconds together, and then press (ON/OFF) button. • “TEST” will appear on the display during test run. •...
Page 155: Remote Sensor
Control of 3-WAY ECO-i SYSTEM 7. Remote Sensor Remote Sensor / ART-K45AGB Parts Supplied with Remote Sensor Supplied parts Remote sensor (comes with 200 mm wire) Machine screws M4 × 25 Wood screws Spacers Wire joints Cable Tie Installation manual Remote Sensor Installation Guidelines Place of installation Mount the remote sensor at a height of 1 to 1.5 meters...
Page 156: Remote Sensor
Control of 3-WAY ECO-i SYSTEM 7. Remote Sensor How to Install the Remote Sensor • Do not twist the remote sensor wiring with the power wiring or run it in the same metal conduit, because this NOTE may cause malfunction. • Install the remote sensor away from sources of electrical noise. • Install a noise filter or take other appropriate action if electrical noise affects the power supply circuit of the unit. Use an electric junction box (supplied locally) (Fig. 3-73) for flush mounting of the remote sensor. Under case (back case) Spacer Remote Sensor Wall Electric junction box for one box (no cover) Machine screws M4 × 25 (2) Fig. 3-73 Fig. 3-74 1. Insert a screwdriver or the like in the groove on the lower side of the remote sensor body to pry off the back case. (Fig. 3-74) 2. Use the 2 supplied M4 machine screws to secure the remote sensor back case. Prior to mounting, clear the cutouts in the back case corresponding to the holes in the wall box using a screwdriver or the like. Use the spacers and take care not to tighten the screws excessively. If the back case will not seat...
Page 157 Control of 3-WAY ECO-i SYSTEM 7. Remote Sensor How to Wire the Remote Sensor Connection diagram Terminal block Remote for wiring the sensor remote controller of the indoor unit Wiring from remote Connector sensor Wiring for remote sensor (supplied locally) 1: 0.5 mm to 1.6 mm wires are used for lead wires.
Page 158 – MEMO – 3-106...
Page 159 3-WAY ECO-i SYSTEM Unit Speciﬁ cations Contents 4. 3-WAY ECO-i SYSTEM UNIT SPECIFICATIONS 1. Outdoor Unit ........................4-3 1-1. Speciﬁ cations .......................4-3 1-2. Dimensional Data .......................4-21 1-3. Multiple Unit Installation Example ................4-22 1-4. Refrigerant Flow Diagram ...................4-24 1-5. Noise Criterion Curves ....................4-26 2.
Page 160 3-WAY ECO-i SYSTEM Unit Speciﬁ cations Contents 8. Concealed Duct High Static Pressure Type (D Type) ...........4-299 8-1. Speciﬁ cations ......................4-299 8-2. Major Component Speciﬁ cations ................4-304 8-3. Dimensional Data .....................4-309 8-4. Noise Criterion Curves .....................4-311 8-5. Indoor Fan Performance ...................4-313 9.
Page 161 Unit Speciﬁ cations (1) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <8, 10 horsepower> Model No. SPW-C0705DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz...
Page 162 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (2) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <12, 14, 16 horsepower> Model No. SPW-C1155DZH8 SPW-C1305DZH8 SPW-C1405DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 163 3-WAY ECO-i Capacity Control Outdoor Unit <18 horsepower> General Model No. SPW-C1605DZH8 Component Outdoor Unit SPW-C0905DZH8 SPW-C0705DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 164 3-WAY ECO-i SYSTEM Unit Specifications 1. Outdoor Unit Unit Specifications (4) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <20 horsepower> General Model No. SPW-C1805DZH8 Component Outdoor Unit SPW-C0905DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 165 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (5) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <22 horsepower> General Model No. SPW-C2055DZH8 Component Outdoor Unit SPW-C1155DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 166 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (6) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <24 horsepower> General Model No. SPW-C2205DZH8 Component Outdoor Unit SPW-C1305DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 167 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (7) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <26 horsepower> General Model No. SPW-C2305DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 168 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (8) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <28 horsepower> General Model No. SPW-C2555DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1155DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 169 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (9) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <30 horsepower> General Model No. SPW-C2705DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1305DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 170 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (10) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <32 horsepower> General Model No. SPW-C2805DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1405DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance Cooling capacity...
Page 171 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (11) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <34 horsepower> General Model No. SPW-C3105DZH8 Component Outdoor Unit SPW-C1305DZH8 SPW-C0905DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 172 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (12) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <36 horsepower> General Model No. SPW-C3205DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C0905DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 173 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (13) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <38 horsepower> General Model No. SPW-C3455DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1155DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 174 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (14) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <40 horsepower> General Model No. SPW-C3605DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1305DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 175 3-WAY ECO-i SYSTEM Unit Specifications 1. Outdoor Unit Unit Specifications (15) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <42 horsepower> General Model No. SPW-C3705DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1405DZH8 SPW-C0905DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 176 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (16) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <44 horsepower> General Model No. SPW-C3955DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1405DZH8 SPW-C1155DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 177 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (17) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <46 horsepower> General Model No. SPW-C4105DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1405DZH8 SPW-C1305DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 178 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit Unit Speciﬁ cations (18) Model Name 3-WAY ECO-i Capacity Control Outdoor Unit <48 horsepower> General Model No. SPW-C4205DZH8 Component Outdoor Unit SPW-C1405DZH8 SPW-C1405DZH8 SPW-C1405DZH8 Power Source 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz 380 - 400 - 415 V / 3N / 50 Hz Performance...
Page 179 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit 1-2. Dimensional Data SPW-C0705, C0905, C1155, C1305, C1405DZH8 4-21...
Page 180 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit 1-3. Multiple Unit Installation Example 4-22...
Page 181 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit 4-23...
Page 182: Refrigerant Flow Diagram
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit 1-4. Refrigerant Flow Diagram SPW-C0705DZH8 -C0905DZH8 -C1155DZH8 Distribution joint kit High pressure switch Low pressure sensor (Purchased separately) (AC1) Compressor (INV) Compressor separator Balance tube (for 0705-1155 model: ø9.52) Oil drain Suction tube (1155 model: ø25.4)
Page 183 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit SPW-C1305DZH8 -C1405DZH8 Distribution joint kit High pressure switch Low pressure sensor (Purchased separately) (AC1) Compressor (INV) Compressor separator (AC2) Balance tube Check valve Compressor (for 1305, 1405 model: ø9.52) Oil drain Suction tube (1405 model: ø28.58) (1305 model: ø25.4)
Page 184 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 1. Outdoor Unit 1-5. Noise Criterion Curves SPW-C0705, C0905, C1155, C1305, C1405DZH8B MODEL : SPW-C0705DZH8 MODEL : SPW-C0905DZH8 SOUND LEVEL : SOUND LEVEL : 54.5 55.0 db (A) db (A) 50Hz 50Hz CONDITION CONDITION...
Page 185: Way Air Discharge Semi-Concealed Type (X, Xm Types)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) 2-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-XDR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h...
Page 186 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-XDR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 187 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-XDR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 188 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-XDR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 189 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-XDR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 190 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-XDR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 191 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (G) MODEL No. Indoor Unit SPW-XDR364GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000...
Page 192 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (H) MODEL No. Indoor Unit SPW-XDR484GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800...
Page 193 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (I) MODEL No. Indoor Unit SPW-XDR604GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600...
Page 194 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (J) MODEL No. Indoor Unit SPW-X075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 195 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (K) MODEL No. Indoor Unit SPW-X095XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 196 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (L) MODEL No. Indoor Unit SPW-X125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 197 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (M) MODEL No. Indoor Unit SPW-X165XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 198 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (N) MODEL No. Indoor Unit SPW-X185XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 199 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (O) MODEL No. Indoor Unit SPW-X255XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 200 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (P) MODEL No. Indoor Unit SPW-X365XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000...
Page 201 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (Q) MODEL No. Indoor Unit SPW-X485XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800...
Page 202 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (R) MODEL No. Indoor Unit SPW-X605XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600...
Page 203 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (S) MODEL No. Indoor Unit SPW-XM075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 204 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (T) MODEL No. Indoor Unit SPW-XM095XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 205 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (U) MODEL No. Indoor Unit SPW-XM125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 206 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (V) MODEL No. Indoor Unit SPW-XM165XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 16,000 17,000 Air circulation (Hi / Me / Lo)
Page 207 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Unit speciﬁ cations (W) MODEL No. Indoor Unit SPW-XM185XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 208 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) 2-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-XDR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor...
Page 209 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (B) MODEL No. SPW-XDR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 210 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (C) MODEL No. SPW-XDR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 211 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (D) MODEL No. SPW-XDR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 212 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (E) MODEL No. SPW-XDR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 213 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (F) MODEL No. SPW-XDR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 214 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (G) MODEL No. SPW-XDR364GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 215 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (H) MODEL No. SPW-XDR484GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 216 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (I) MODEL No. SPW-XDR604GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 217 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (J) MODEL No. SPW-X075XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 218 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (K) MODEL No. SPW-X095XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 219 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (L) MODEL No. SPW-X125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 220 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (M) MODEL No. SPW-X165XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 221 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (N) MODEL No. SPW-X185XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 222 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (O) MODEL No. SPW-X255XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-53B280H...50 W...
Page 223 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (P) MODEL No. SPW-X365XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 224 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (Q) MODEL No. SPW-X485XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 225 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (R) MODEL No. SPW-X605XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Turbo (1...ø460) Fan motor Model...Nominal output DK8-93C280H...90 W...
Page 226 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (S) MODEL No. SPW-XM075XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-XM075XH (Microprocessor), POW-XM075XH Fan (Number...diameter) Turbo (1...ø322, L147) Fan motor Model...Nominal output SIC-72FV-D866-1...20 W...
Page 227 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (T) MODEL No. SPW-XM095XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-XM075XH (Microprocessor), POW-XM075XH Fan (Number...diameter) Turbo (1...ø322, L147) Fan motor Model...Nominal output SIC-72FV-D866-1...20 W...
Page 228 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (U) MODEL No. SPW-XM125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-XM075XH (Microprocessor), POW-XM075XH Fan (Number...diameter) Turbo (1...ø322, L147) Fan motor Model...Nominal output SIC-72FV-D866-1...20 W...
Page 229 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (V) MODEL No. SPW-XM165XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-XM075XH (Microprocessor), POW-XM075XH Fan (Number...diameter) Turbo (1...ø322, L147) Fan motor Model...Nominal output SIC-72FV-D866-1...20 W...
Page 230 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit (W) MODEL No. SPW-XM185XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-XM075XH (Microprocessor), POW-XM075XH Fan (Number...diameter) Turbo (1...ø322, L147) Fan motor Model...Nominal output SIC-72FV-D866-1...20 W...
Page 231 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) 2-3. Dimensional Data Indoor unit: SPW-XDR74 / 94 / 124 / 164 / 184 / 254GXH56(A/B) SPW-X075 / 095 / 125 / 165 / 185 / 255XH 860 –...
Page 232 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit: SPW-XDR364 / 484 / 604GXH56(A/B) SPW-X365 / 485 / 605XH 4-74...
Page 233 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Indoor unit: SPW-XM075 / 095 / 125 / 165 / 185XH 4-75...
Page 234 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Both 50Hz and 60Hz 2-4. Noise Criterion Curves Strong Weak MODEL : SPW-XDR74/94/124/164/184/GXH56 (A/B) MODEL : SPW-XDR254GXH56 (A/B), -X255XH -X075/095/125/165/185XH SOUND LEVEL : 31 dB(A) SOUND LEVEL : 34 dB(A) STRONG...
Page 235 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) Both 50Hz and 60Hz Strong Weak MODEL SPW-XM075/095XH MODEL SPW-XM125XH SOUND LEVEL STRONG 30 dB(A) SOUND LEVEL STRONG 32 dB(A) WEAK 25 dB(A) WEAK 26 dB(A) CONDITION 1.5 m directly below unit CONDITION...
Page 236 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) 2-5. Air Flow Distance / Temperature Chart If an ultra long-life filter or high performance filter (65% by colorimetric method) is installed, the vertical air flow distance for heating and cooling will be approximately 0.2 m less than the values shown in the graph below.
Page 237 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XDR254GXH56(A/B), X255XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20...
Page 238 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XDR364GXH56(A/B), X365XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20...
Page 239 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XDR484/604GXH56(A/B), X485/605XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.65 ) (Room temperature approx.20...
Page 240 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XM075/095/125XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.60 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.60 ) (Room temperature approx.20...
Page 241 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 2. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XM165/185XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.60 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.60 ) (Room temperature approx.20...
Page 242: Way Air Discharge Semi-Concealed Type (S Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) 3-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-SR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500...
Page 243 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-SR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 244 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-SR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 245 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-SR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 246 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-SR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 247 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-SR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 248 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) 3-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-SR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor...
Page 249 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit (B) MODEL No. SPW-SR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output UF4X-31C3P...30 W Source...
Page 250 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit (C) MODEL No. SPW-SR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output UF4X-31C3P...30 W Source...
Page 251 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit (D) MODEL No. SPW-SR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output UF4X-31C3P...30 W Source...
Page 252 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit (E) MODEL No. SPW-SR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output UF4X-31C3P...30 W Source...
Page 253 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit (F) MODEL No. SPW-SR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-51F3P...50 W Source...
Page 254 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) 3-3. Dimensional Data Indoor unit: SPW-SR74 / 94 / 124 / 164 / 184GXH56(A/B) Refrigerant liquid line (ø6.35) Refrigerant gas line (ø12.7 : 7,9,12,16,18 types) Drain connection (25 A. O.D. 32 mm) Power supply entry 4-96...
Page 255 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) Indoor unit: SPW-SR254GXH56(A/B) Refrigerant liquid line (ø9.52) Refrigerant gas line (ø15.88) Drain connection (25 A. O.D. 32 mm) Power supply entry 4-97...
Page 256 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) 3-4. Noise Criterion Curves Both 50Hz and 60Hz Strong Weak MODEL : SPW-SR74GXH56 (A/B) MODEL : SPW-SR94/124GXH56 (A/B) SOUND LEVEL : STRONG 30 dB(A) SOUND LEVEL : STRONG 33 dB(A) HIGH...
Page 257 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 3. 2-Way Air Discharge Semi-concealed Type (S Type) 3-5. Air Flow Distance Chart (Indoor temp.: Cooling 27°C, heating 20°C) SPW-SR74GXH56 (A/B) SPW-SR94/124GXH56 (A/B) Horizontal air flow distance (m) Horizontal air flow distance (m) Air speed at center Air speed at center Path at center Path at center...
Page 258: Way Air Discharge Semi-Concealed Type (A Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) 4-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-ADR74GXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500...
Page 259 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-ADR94GXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 260 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-ADR124GXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 261 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) 4-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-ADR74GXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output...
Page 262 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) Indoor unit (B) MODEL No. SPW-ADR94GXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63E280H...20 W Source...
Page 263 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) Indoor unit (C) MODEL No. SPW-ADR124GXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63E280H...20 W Source...
Page 264 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) 4-3. Dimensional Data Indoor unit: SPW-ADR74 / 94 / 124GXH56B 4-106...
Page 265 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) 4-4. Noise Criterion Curves 4-107...
Page 266 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 4. 1-Way Air Discharge Semi-concealed Type (A Type) 4-5. Air Flow Distance / Temperature Chart (Immediate wind A blow angle 60 degrees) (Room temperature 20 degrees Celsius) Heating equipment 1.5m/s Wind velocity 1.0m/s distribution 0.5m/s 0.3m/s Horizontal distance(m)
Page 267: Wall-Mounted Type (K Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) 5-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-KR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 268 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-KR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo) 600 / 480 / 360 Moisture removal (High)
Page 269 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-KR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo) 600 / 480 / 360 Moisture removal (High)
Page 270 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-KR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo) 720 / 600 / 480 Moisture removal (High)
Page 271 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-KR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo) 720 / 600 / 480 Moisture removal (High)
Page 272 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-KR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo) 960 / 840 / 600 Moisture removal (High)
Page 273 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (G) MODEL No. Indoor Unit SPW-K075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo) 540 / 450 / 360 Moisture removal (High)
Page 274 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (H) MODEL No. Indoor Unit SPW-K095XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo) 540 / 450 / 360 Moisture removal (High)
Page 275 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Unit speciﬁ cations (I) MODEL No. Indoor Unit SPW-K125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo) 600 / 510 / 390 Moisture removal (High)
Page 276 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) 5-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-KR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR74GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø88 / L740) Fan motor Model...Nominal output UF4Q-31G5P...11 W...
Page 277 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (B) MODEL No. SPW-KR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR74GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø88 / L740) Fan motor Model...Nominal output UF4Q-31G5P...11 W Source...
Page 278 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (C) MODEL No. SPW-KR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR74GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø88 / L740) Fan motor Model...Nominal output UF4Q-31G5P...11 W Source...
Page 279 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (D) MODEL No. SPW-KR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR74GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø88 / L740) Fan motor Model...Nominal output UF4Q-31G5P...15 W Source...
Page 280 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (E) MODEL No. SPW-KR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR74GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø88 / L740) Fan motor Model...Nominal output UF4Q-31G5P...15 W Source...
Page 281 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (F) MODEL No. SPW-KR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-KR254GXH56 (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø100 / L848) Fan motor Model...Nominal output KFT4Q-31A5P-S...23 W Source...
Page 282 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (G) MODEL No. SPW-K075XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-K075XH (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø94 / L634) Fan motor Model...Nominal output SIC-39CVL-D847-6 …...
Page 283 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (H) MODEL No. SPW-K095XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-K075XH (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø94 / L634) Fan motor Model...Nominal output SIC-39CVL-D847-6 …...
Page 284 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit (I) MODEL No. SPW-K125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-K075XH (Microprocessor) Fan (Number...diameter) Cross-ﬂ ow (1...ø94 / L634) Fan motor Model...Nominal output SIC-39CVL-D847-6 …...
Page 285 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) 5-3. Dimensional Data Indoor unit: SPW-KR74/94/124/164/184GXH56(A/B) unit : mm 15cm 15cm 15cm Front view Installation minimum space 53.5 53.5 147.5 147.5 Z view Refrigerant tubing (liquid tube) 6.35(flared) (length approx. 470mm) FILTER SIZE Refrigerant tubing (gas tube) 12.7(flared) (length approx.
Page 286 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) Indoor unit: SPW-K075/095/125XH 4-128...
Page 287 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) 5-4. Noise Criterion Curves Both 50Hz and 60Hz Strong Weak MODEL : SPW-KR74/94GXH56(A/B), -KR124/164GXH56(A/B) MODEL : SPW-KR184GXH56(A/B) SOUND LEVEL : STRONG 36 dB(A) SOUND LEVEL : STRONG 39 dB(A) HIGH 32 dB(A) HIGH...
Page 288 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) 5-5. Air Flow Distance / Temperature Chart SPW-KR74/94/124GXH56(A/B) Air Flow Cooling Temperature Cooling (Strong / Outlet Angle=30 ) (Strong / Outlet Angle=30 ) 1.5m/s 1.2m/s 0.3m/s 0.6m/s 0.3m/s 0.9m/s 0.6m/s Horizontal air flow distance (m) Horizontal air flow distance (m)
Page 289 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) SPW-KR254GXH56(A/B) Air Flow Cooling Temperature Cooling (Strong / Outlet Angle=30 ) (Strong / Outlet Angle=30 ) 1.5m/s 0.3m/s 0.6m/s 0.3m/s 0.9m/s 0.6m/s 0.9m/s 1.2m/s Horizontal air flow distance (m) Horizontal air flow distance (m) Air Flow Heating...
Page 290 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 5. Wall-Mounted Type (K Type) SPW-K125XH Air Flow Cooling Temperature Cooling (Strong / Outlet Angle=30 ) (Strong / Outlet Angle=30 ) 1.5m/s 1.2m/s 0.3m/s 0.6m/s 0.3m/s 0.9m/s 0.6m/s Horizontal air flow distance (m) Horizontal air flow distance (m) Air Flow Heating Temperature...
Page 291: Ceiling-Mounted Type (T Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) 6-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-TDR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 292 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-TDR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo) 780 / 660 / 540 Moisture removal (High)
Page 293 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-TDR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo) 780 / 660 / 540 Moisture removal (High)
Page 294 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-TDR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo) 1110 / 900 / 840 Moisture removal (High)
Page 295 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-TDR364GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 296 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-TDR484GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo) 1800 / 1560 / 1320...
Page 297 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (G) MODEL No. Indoor Unit SPW-T125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo) 720 / 600 / 540 Moisture removal (High)
Page 298 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (H) MODEL No. Indoor Unit SPW-T165XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo) 780 / 660 / 540 Moisture removal (High)
Page 299 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (I) MODEL No. Indoor Unit SPW-T185XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo) 780 / 660 / 540 Moisture removal (High)
Page 300 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (J) MODEL No. Indoor Unit SPW-T255XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo) 1110 / 900 / 840 Moisture removal (High)
Page 301 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (K) MODEL No. Indoor Unit SPW-T365XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 302 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Unit speciﬁ cations (L) MODEL No. Indoor Unit SPW-T485XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo) 1800 / 1560 / 1320...
Page 303 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) 6-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-TDR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W...
Page 304 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (B) MODEL No. SPW-TDR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W Source 340 VDC...
Page 305 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (C) MODEL No. SPW-TDR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W Source 340 VDC...
Page 306 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (D) MODEL No. SPW-TDR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø140) Fan motor Model...Nominal output DK8-63D280H...40 W Source 340 VDC...
Page 307 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (E) MODEL No. SPW-TDR364GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (4...ø140) Fan motor Model...Nominal output DK8-123C280H...80 W Source 340 VDC...
Page 308 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (F) MODEL No. SPW-TDR484GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (4...ø140) Fan motor Model...Nominal output DK8-123C280H...80 W Source 340 VDC...
Page 309 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (G) MODEL No. SPW-T125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W Source 340 VDC...
Page 310 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (H) MODEL No. SPW-T165XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W Source 340 VDC...
Page 311 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (I) MODEL No. SPW-T185XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...30 W Source 340 VDC...
Page 312 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (J) MODEL No. SPW-T255XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø140) Fan motor Model...Nominal output DK8-63D280H...40 W Source 340 VDC...
Page 313 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (K) MODEL No. SPW-T365XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (4...ø140) Fan motor Model...Nominal output DK8-123C280H...80 W Source 340 VDC...
Page 314 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) Indoor unit (L) MODEL No. SPW-T485XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (4...ø140) Fan motor Model...Nominal output DK8-123C280H...80 W Source 340 VDC...
Page 315 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) 6-3. Dimensional Data Length Type Air intake SPW -TDR124/164/184GXH56(A/B) -T125/165/185XH SPW -TDR254GXH56(A/B) 1125 1180 -T255XH Ceiling side SPW -TDR364/484GXH56(A/B) 1540 1595 -T365/485XH 27.5 27.5 Unit: mm (Suspension bolt pitch) Rear (Figure shows view from front) Left side Right side...
Page 316 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) 6-4. Noise Criterion Curves Both 50Hz and 60Hz Strong Weak MODEL : SPW-TDR124GXH56(A/B), -T125XH MODEL : SPW-TDR164/184GXH56(A/B), -T165/185XH SOUND LEVEL : STRONG 35 dB(A) SOUND LEVEL : STRONG 36 dB(A) HIGH 32 dB(A) HIGH...
Page 317 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) 6-5. Air Flow Distance / Temperature Chart SPW-TDR124/164/184GXH56(A/B), T125/165/185XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.54 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.54 )
Page 318 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) SPW-TDR254/364GXH56(A/B), T255/365XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.54 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.54 ) (Room temperature approx.20 Horizontal air flow distance (m)
Page 319 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 6. Ceiling-Mounted Type (T Type) SPW-TDR484GXH56(A/B), T485XH Heating : Distribution of wind velocity (Strong wind : Discharge angle approx.54 ) (Room temperature approx.20 1.5m/s 1.0m/s 0.5m/s 0.3m/s Horizontal air flow distance (m) Heating : Distribution of temperature (Strong wind : Discharge angle approx.54 ) (Room temperature approx.20 Horizontal air flow distance (m)
Page 320: Concealed Duct Type (U, Us Types)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) 7-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-UR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500...
Page 321 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-UR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 322 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-UR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 323 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-UR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 324 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-UR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 325 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-UR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 326 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (G) MODEL No. Indoor Unit SPW-UR364GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 327 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (H) MODEL No. Indoor Unit SPW-UR484GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 328 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (I) MODEL No. Indoor Unit SPW-UR604GXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 329 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (J) MODEL No. Indoor Unit SPW-U075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 330 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (K) MODEL No. Indoor Unit SPW-U095XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 331 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (L) MODEL No. Indoor Unit SPW-U125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 332 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (M) MODEL No. Indoor Unit SPW-U165XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 333 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (N) MODEL No. Indoor Unit SPW-U185XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 334 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (O) MODEL No. Indoor Unit SPW-U255XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 335 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (P) MODEL No. Indoor Unit SPW-U365XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 336 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (Q) MODEL No. Indoor Unit SPW-U485XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 337 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (R) MODEL No. Indoor Unit SPW-U605XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 338 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (S) MODEL No. Indoor Unit SPW-U075XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 339 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (T) MODEL No. Indoor Unit SPW-U095XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 340 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (U) MODEL No. Indoor Unit SPW-U125XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 341 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (V) MODEL No. Indoor Unit SPW-U165XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 342 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (W) MODEL No. Indoor Unit SPW-U185XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 343 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (X) MODEL No. Indoor Unit SPW-U255XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 344 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (Y) MODEL No. Indoor Unit SPW-U365XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 345 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (Z) MODEL No. Indoor Unit SPW-U485XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 346 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-1) MODEL No. Indoor Unit SPW-U605XHN POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 347 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-2) MODEL No. Indoor Unit SPW-UR74SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 348 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-3) MODEL No. Indoor Unit SPW-UR94SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 349 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-4) MODEL No. Indoor Unit SPW-UR124SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 350 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-5) MODEL No. Indoor Unit SPW-UR164SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 351 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-6) MODEL No. Indoor Unit SPW-UR184SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 352 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-7) MODEL No. Indoor Unit SPW-UR254SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 353 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-8) MODEL No. Indoor Unit SPW-UR304SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.0 Capacity BTU / h 30,000 34,000 Air circulation (Hi / Me / Lo)
Page 354 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-9) MODEL No. Indoor Unit SPW-UR364SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 355 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-10) MODEL No. Indoor Unit SPW-UR484SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 356 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-11) MODEL No. Indoor Unit SPW-UR604SXH56B POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 357 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-12) MODEL No. Indoor Unit SPW-U075SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 358 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-13) MODEL No. Indoor Unit SPW-U095SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 359 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-14) MODEL No. Indoor Unit SPW-U125SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 360 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-15) MODEL No. Indoor Unit SPW-U165SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 361 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-16) MODEL No. Indoor Unit SPW-U185SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 362 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-17) MODEL No. Indoor Unit SPW-U255SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 363 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-18) MODEL No. Indoor Unit SPW-U305SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.0 Capacity BTU / h 30,000 34,000 Air circulation (Hi / Me / Lo)
Page 364 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-19) MODEL No. Indoor Unit SPW-U365SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 365 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-20) MODEL No. Indoor Unit SPW-U485SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 366 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-21) MODEL No. Indoor Unit SPW-U605SXH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 367 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-22) MODEL No. Indoor Unit SPW-U075SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 368 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-23) MODEL No. Indoor Unit SPW-U095SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 369 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-24) MODEL No. Indoor Unit SPW-U125SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 370 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-25) MODEL No. Indoor Unit SPW-U165SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 371 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-26) MODEL No. Indoor Unit SPW-U185SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 372 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-27) MODEL No. Indoor Unit SPW-U255SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 373 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-28) MODEL No. Indoor Unit SPW-U305SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.0 Capacity BTU / h 30,000 34,000 Air circulation (Hi / Me / Lo)
Page 374 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-29) MODEL No. Indoor Unit SPW-U365SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000 39,000 Air circulation (Hi / Me / Lo)
Page 375 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-30) MODEL No. Indoor Unit SPW-U485SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800 54,600 Air circulation (Hi / Me / Lo)
Page 376 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-31) MODEL No. Indoor Unit SPW-U605SXHT POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 16.0 18.0 Capacity BTU / h 54,600 61,500 Air circulation (Hi / Me / Lo)
Page 377 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-32) MODEL No. Indoor Unit SPW-US075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 378 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-33) MODEL No. Indoor Unit SPW-US095XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo)
Page 379 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-34) MODEL No. Indoor Unit SPW-US125XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 380 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-35) MODEL No. Indoor Unit SPW-US165XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 381 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Unit speciﬁ cations (A-36) MODEL No. Indoor Unit SPW-US185XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 382 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) 7-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-UR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output...
Page 383 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (B) MODEL No. SPW-UR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 384 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (C) MODEL No. SPW-UR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 385 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (D) MODEL No. SPW-UR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 386 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (E) MODEL No. SPW-UR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 387 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (F) MODEL No. SPW-UR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71B5P...70 W Source...
Page 388 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (G) MODEL No. SPW-UR364GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 389 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (H) MODEL No. SPW-UR484GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 390 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (I) MODEL No. SPW-UR604GXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 391 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (J) MODEL No. SPW-U075XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 392 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (K) MODEL No. SPW-U095XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 393 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (L) MODEL No. SPW-U125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 394 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (M) MODEL No. SPW-U165XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 395 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (N) MODEL No. SPW-U185XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 396 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (O) MODEL No. SPW-U255XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Source...
Page 397 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (P) MODEL No. SPW-U365XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Source...
Page 398 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (Q) MODEL No. SPW-U485XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Source...
Page 399 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (R) MODEL No. SPW-U605XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Source...
Page 400 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (S) MODEL No. SPW-U075XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 401 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (T) MODEL No. SPW-U095XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 402 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (U) MODEL No. SPW-U125XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 403 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (V) MODEL No. SPW-U165XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 404 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (W) MODEL No. SPW-U185XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 405 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (X) MODEL No. SPW-U255XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Power source...
Page 406 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (Y) MODEL No. SPW-U365XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Power source...
Page 407 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (Z) MODEL No. SPW-U485XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Power source...
Page 408 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-1) MODEL No. SPW-U605XHN Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...140 W Power source...
Page 409 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-2) MODEL No. SPW-UR74SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 410 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-3) MODEL No. SPW-UR94SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 411 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-4) MODEL No. SPW-UR124SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 412 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-5) MODEL No. SPW-UR164SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 413 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-6) MODEL No. SPW-UR184SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Source...
Page 414 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-7) MODEL No. SPW-UR254SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71B5P...70 W Source...
Page 415 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-8) MODEL No. SPW-UR304SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71B5P...70 W Source...
Page 416 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-9) MODEL No. SPW-UR364SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 417 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-10) MODEL No. SPW-UR484SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 418 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-11) MODEL No. SPW-UR604SXH56B Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141A5P...140 W Source...
Page 419 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-12) MODEL No. SPW-U075SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 420 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-13) MODEL No. SPW-U095SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 421 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-14) MODEL No. SPW-U125SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 422 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-15) MODEL No. SPW-U165SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 423 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-16) MODEL No. SPW-U185SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 424 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-17) MODEL No. SPW-U255SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Power source...
Page 425 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-18) MODEL No. SPW-U305SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Power source...
Page 426 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-19) MODEL No. SPW-U365SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 427 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-20) MODEL No. SPW-U485SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 428 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-21) MODEL No. SPW-U605SXH Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 429 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-22) MODEL No. SPW-U075SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 430 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-23) MODEL No. SPW-U095SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 431 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-24) MODEL No. SPW-U125SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 432 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-25) MODEL No. SPW-U165SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 433 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-26) MODEL No. SPW-U185SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output SFG4X-51C3P...50 W Power source...
Page 434 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-27) MODEL No. SPW-U255SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Power source...
Page 435 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-28) MODEL No. SPW-U305SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø190) Fan motor Model...Nominal output KFG4X-71D5P-S...70 W Power source...
Page 436 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-29) MODEL No. SPW-U365SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 437 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-30) MODEL No. SPW-U485SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 438 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-31) MODEL No. SPW-U605SXHT Power source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CB-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (3...ø190) Fan motor Model...Nominal output KFC4X-141D5P-S...160 W Power source...
Page 439 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-32) MODEL No. SPW-US075XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-US075XH (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63G280H...60 W Source...
Page 440 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-33) MODEL No. SPW-US095XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-US075XH (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63G280H...60 W Source...
Page 441 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-34) MODEL No. SPW-US125XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-US075XH (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63G280H...60 W Source...
Page 442 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-35) MODEL No. SPW-US165XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-US075XH (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63G280H...60 W Source...
Page 443 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit (A-36) MODEL No. SPW-US185XH Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-US075XH (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø190) Fan motor Model...Nominal output DK8-63G280H...60 W Source...
Page 444 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) 7-3. Dimensional Data Indoor unit: SPW-UR74 / 94 / 124 / 164 / 184GXH56(A/B) -U075 / 095 / 125 / 165 / 185XH -U075 / 095 / 125 / 165 / 185XHN (Air intake duct flange) (Suspension bolt pitch)
Page 445 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-UR254GXH56(A/B) -U255XH -U255XHN (Air intake duct flange) (Suspension bolt pitch) Refrigerant liquid line ø9.52 (narrow tube) (Use the tube connector) Refrigerant gas line ø15.88 (wide tube) Upper drain port (O.D.
Page 446 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-UR364 / 484 / 604GXH56(A/B) -U365 / 485 / 605XH -U365 / 485 / 605XHN (Air intake duct flange) (Suspension bolt pitch) Refrigerant liquid line ø9.52 (narrow tube) Refrigerant gas line ø15.88 (wide tube) Upper drain port (O.D.
Page 447 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-UR74 / 94 / 124 / 164 / 184SXH56B -U075 / 095 / 125 / 165 / 185SXH -U075 / 095 / 125 / 165 / 185SXHT Ceiling Inspection access panel Inspection access...
Page 448 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-UR254 / 304SXH56B -U255 / 305SXH -U255 / 305SXHT Ceiling Inspection access panel Inspection access (450 × 450) (Field supply) (Flange O.D.) 26 - ø 3.1 (Hole) 20 - ø...
Page 449 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-UR364 / 484 / 604SXH56B -U365 / 485 / 605SXH -U365 / 485 / 605SXHT Ceiling Inspection access panel Inspection access (450 × 450) (Field supply) (Flange O.D.) 26 - ø...
Page 450 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Indoor unit: SPW-US075 / 095 / 125 / 165 / 185XH unit: mm 4-292...
Page 451 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Flange for Air Intake Duct (Field supply) For Concealed Duct Type Thickness more than T1.2 mm Thickness more than T1.2 mm (mm) 662 12–ø3.3 200P = 600 8–ø6 7, 9, 12, 16, 18 type ×...
Page 452 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) 7-4. Noise Criterion Curves MODEL : SPW-UR164/184GXH56(A/B) MODEL : SPW-UR74/94/124GXH56(A/B) -U075/095/125XH(N) -U165/185XH(N) -UR74/94/124SXH56B -UR164/184SXH56B -U075/095/125SXH(T) -U165/185SXH(T) SOUND LEVEL : HIGH 29 dB(A), NC 20 / LOW 22 dB(A), NC 13 SOUND LEVEL : HIGH 30 dB(A), NC 23 / LOW 25 dB(A), NC 17 CONDITION : Under the unit 1.5 m...
Page 453 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) : SPW-UR484GXH56(A/B) MODEL : SPW-UR364GXH56(A/B) MODEL -U485XH(N) -U365XH(N) -UR484SXH56B -UR364SXH56B -U485SXH(T) -U365SXH(T) SOUND LEVEL : HIGH 38 dB(A), NC 30 / LOW 31 dB(A), NC 21 SOUND LEVEL : HIGH 40 dB(A), NC 33 / LOW 33 dB(A), NC 25 CONDITION : Under the unit 1.5 m CONDITION...
Page 454 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) Both 50Hz and 60Hz Strong Weak MODEL SPW-US075XH MODEL : SPW-US095XH SOUND LEVEL STRONG 28 dB(A) SOUND LEVEL STRONG 30 dB(A) WEAK 25 dB(A) WEAK 27 dB(A) CONDITION CONDITION 1.5 m directly below unit...
Page 455 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) 7-5. Increasing the Fan Speed Booster Cable for Concealed Duct Type If external static pressure is too great (due to long extension of ducts, for example), the air flow volume may drop too low at each air outlet.
Page 456 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 7. Concealed Duct Type (U, US Types) For Short Circuit Connection The standard (before shipment) external static pressure is shown in the table below. When using with a higher static pressure, it is necessary to change to the high static pressure mode. External static pressure White Yellow Red Type...
Page 457: Concealed Duct High Static Pressure Type (D Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) 8-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-DR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h...
Page 458 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-DR364GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 10.6 11.4 Capacity BTU / h 36,000...
Page 459 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-DR484GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 14.0 16.0 Capacity BTU / h 47,800...
Page 460 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-DR764GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating 22.4 25.0 Capacity BTU / h 76,400...
Page 461 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-DR964GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50 Hz PERFORMANCE Cooling Heating 28.0 31.5 Capacity BTU / h 95,500...
Page 462 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) 8-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-DR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø220) Fan motor...
Page 463 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Indoor unit (B) MODEL No. SPW-DR364GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø220) Fan motor Model...Nominal output KFC4X-201B5P...200 W...
Page 464 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Indoor unit (C) MODEL No. SPW-DR484GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø250) Fan motor Model...Nominal output KFC4Q-401A5P...350 W...
Page 465 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Indoor unit (D) MODEL No. SPW-DR764GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø220) Fan motor Model...Nominal output KFC4X-201B5P...200 W...
Page 466 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Indoor unit (E) MODEL No. SPW-DR964GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø250) Fan motor Model...Nominal output KFC4X-401B3P...400 W...
Page 467 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) 8-3. Dimensional Data Indoor unit: SPW-DR254 / 364 / 484GXH56(A/B) SPW-DR254/ 364GXH56(A/B) SPW- DR484GXH56(A/B) Refrigerant liquid line (ø9.52) Refrigerant gas line (ø15.88) Power supply entry Drain connection (20A / VP20) Duct connection for suction Duct connection for discharge...
Page 468 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Indoor unit: SPW-DR764 / 964GXH56(A/B) Refrigerant liquid line ø9.52 (narrow tube) Refrigerant gas line 764: ø19.05, 964: ø22.22 Power supply outlet Drain port (OD 32 mm) Duct connection for suction Duct connection for discharge 4 - 37 ×12...
Page 469 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) 8-4. Noise Criterion Curves MODEL : SPW-DR364GXH56(A/B) MODEL : SPW-DR254GXH56(A/B) SOUND LEVEL : HIGH 44dB(A), NC38 SOUND LEVEL : HIGH 45dB(A), NC39 CONDITION : Under the unit 1.5 m CONDITION : Under the unit 1.5 m SOURCE...
Page 470 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) MODEL : SPW-DR764GXH56(A/B) MODEL : SPW-DR964GXH56(A/B) SOUND LEVEL : HIGH 48dB(A), NC42 SOUND LEVEL : HIGH 51dB(A), NC43 CONDITION : Under the unit 1.5 m CONDITION : Under the unit 1.5 m SOURCE...
Page 471 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) 8-5. Indoor Fan Performance How to Read the Diagram The vertical axis is the EXTERNAL STATIC PRESSURE (mmAq) while the horizontal axis represents the AIR FLOW (m /minute).
Page 472 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 8. Concealed Duct High Static Pressure Type (D Type) Increasing the Fan Speed (96 type only) If external static pressure is too great (due to long Electrical component box extension of ducts, for example), the air flow Booster cable volume may drop too low at each air outlet.
Page 473: Floor-Standing Type (F Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) 9-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-FR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 474 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-FR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo) 420 / 360 / 300 Moisture removal (High)
Page 475 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-FR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo) 540 / 420 / 360 Moisture removal (High)
Page 476 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-FR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo) 720 / 540 / 480 Moisture removal (High)
Page 477 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-FR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo) 900 / 780 / 660 Moisture removal (High)
Page 478 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-FR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 24,000 27,000 Air circulation (Hi / Me / Lo) 1,020 / 840 / 720 Moisture removal (High)
Page 479 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) 9-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-FR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output KFT6Q-11A3P...10W...
Page 480 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Indoor unit (B) MODEL No. SPW-FR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output KFT6Q-11A3P...10 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 481 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Indoor unit (C) MODEL No. SPW-FR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output KFT4Q-21B3P...20 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 482 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Indoor unit (D) MODEL No. SPW-FR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...20 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 483 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Indoor unit (E) MODEL No. SPW-FR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...30 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 484 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) Indoor unit (F) MODEL No. SPW-FR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...60 W Source 220 - 230 - 240 V, single-phase,...
Page 485 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) 9-3. Dimensional Data Indoor unit: SPW-FR74 / 94 / 124 / 164 / 184 / 254GXH56(A/B) Liquid Indoor unit tube tube 1065 SPW-FR74/94/124GXH56(A/B) SPW-FR164GXH56(A/B) 6.35 12.7 ø ø SPW-FR184GXH56(A/B) 1380 9.52 15.88...
Page 486 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) 9-4. Noise Criterion Curves MODEL : SPW-FR74/94GXH56(A/B) MODEL : SPW-FR124GXH56(A/B) SOUND LEVEL : HIGH 33dB(A), NC27 SOUND LEVEL : HIGH 39dB(A), NC33 LOW 28dB(A), NC23 LOW 29dB(A), NC23 CONDITION : In front of the unit 1 m, HEIGHT 1 m CONDITION : In front of the unit 1 m, HEIGHT 1 m...
Page 487 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 9. Floor-Standing Type (F Type) 9-5. Air Flow Distance Chart SPW-FR74/94GXH56(A/B) SPW-FR124GXH56(A/B) AIR OUTLET CEILING AIR OUTLET CEILING HEATING HEATING COOLING COOLING HEATING HEATING COOLING COOLING FLOOR FLOOR HORIZONTAL DISTANCE (m) HORIZONTAL DISTANCE (m) SPW-FR164/184GXH56(A/B) SPW-FR254GXH56(A/B) AIR OUTLET...
Page 488: Concealed Floor-Standing Type (Fm Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-FMR74GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 7,500 8,500 Air circulation (Hi / Me / Lo)
Page 489 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-FMR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 9,600 11,000 Air circulation (Hi / Me / Lo) 420 / 360 / 300...
Page 490 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-FMR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo) 540 / 420 / 360...
Page 491 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-FMR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo) 720 / 540 / 480...
Page 492 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-FMR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo) 900 / 780 / 660...
Page 493 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Unit speciﬁ cations (F) MODEL No. Indoor Unit SPW-FMR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 24,000 27,000 Air circulation (Hi / Me / Lo) 1020 / 840 / 720...
Page 494 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-FMR74GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output...
Page 495 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Indoor unit (B) MODEL No. SPW-FMR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output KFT6Q-11A3P...10 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 496 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Indoor unit (C) MODEL No. SPW-FMR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø153) Fan motor Model...Nominal output KFT4Q-21B3P...20 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 497 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Indoor unit (D) MODEL No. SPW-FMR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...20 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 498 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Indoor unit (E) MODEL No. SPW-FMR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...30 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 499 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) Indoor unit (F) MODEL No. SPW-FMR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-UXRP71B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø153) Fan motor Model...Nominal output KFG4Q-61C3P...60 W Source 220 - 230 - 240 V, single-phase, 50 Hz...
Page 500 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10-3. Dimensional Data Indoor unit: SPW-FMR74 / 94 / 124 / 164 / 184 / 254GXH56(A/B) Liquid Indoor unit tube tube SPW-FMR74/94/124GXH56(A/B) SPW-FMR164GXH56(A/B) ø6.35 ø12.7 1219 SPW-FMR184GXH56(A/B) 1007 1002 SPW-FMR254GXH56(A/B) ø9.52 ø15.88...
Page 501 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10-4. Noise Criterion Curves : SPW-FMR74GXH56(A/B) MODEL -FMR94GXH56(A/B) MODEL : SPW-FMR124GXH56(A/B) SOUND LEVEL : HIGH 33dB(A), NC27 SOUND LEVEL : HIGH 39dB(A), NC33 LOW 28dB(A), NC23 LOW 29dB(A), NC23 CONDITION : In front of the unit 1 m, HEIGHT 1 m CONDITION...
Page 502 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10-5. Air Flow Distance Chart SPW-FMR74/94GXH56(A/B) SPW-FMR124GXH56(A/B) AIR OUTLET CEILING AIR OUTLET CEILING HEATING HEATING COOLING COOLING HEATING HEATING COOLING COOLING FLOOR FLOOR HORIZONTAL DISTANCE (m) HORIZONTAL DISTANCE (m) SPW-FMR164/184GXH56(A/B) SPW-FMR254GXH56(A/B) AIR OUTLET...
Page 503 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 10. Concealed Floor-Standing Type (FM Type) 10. Concealed Floor-Standing Type (FM Type) 10-6. Indoor Fan Performance How to Read the Diagram The vertical axis is the EXTERNAL STATIC PRESSURE (mmAq) while the horizontal axis represents the AIR FLOW (m /minute).
Page 504: Way Air Discharge Semi-Concealed Slim Type (L Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) 11-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL No. Indoor Unit SPW-LDR94GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h...
Page 505 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Unit speciﬁ cations (B) MODEL No. Indoor Unit SPW-LDR124GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 12,000 14,000 Air circulation (Hi / Me / Lo)
Page 506 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Unit speciﬁ cations (C) MODEL No. Indoor Unit SPW-LDR164GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 15,000 17,000 Air circulation (Hi / Me / Lo)
Page 507 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Unit speciﬁ cations (D) MODEL No. Indoor Unit SPW-LDR184GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 19,000 21,000 Air circulation (Hi / Me / Lo)
Page 508 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Unit speciﬁ cations (E) MODEL No. Indoor Unit SPW-LDR254GXH56(A/B) POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi / Me / Lo)
Page 509 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) 11-2. Major Component Speciﬁ cations Indoor unit (A) MODEL No. SPW-LDR94GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (1...ø140) Fan motor...
Page 510 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Indoor unit (B) MODEL No. SPW-LDR124GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...50 W...
Page 511 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Indoor unit (C) MODEL No. SPW-LDR164GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...50 W...
Page 512 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Indoor unit (D) MODEL No. SPW-LDR184GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...50 W...
Page 513 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) Indoor unit (E) MODEL No. SPW-LDR254GXH56(A/B) Source 220 - 230 - 240 V, single-phase, 50/60 Hz Controller P.C.B. Ass'y CR-SXRP56B-B (Microprocessor) Fan (Number...diameter) Centrifugal (2...ø140) Fan motor Model...Nominal output DK8-63C280H...50 W...
Page 514 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) 11-3. Dimensional Data Indoor unit: SPW-LDR94 / 124 / 164 / 184 / 254GXH56(A/B) 4-356...
Page 515 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) 11-4. Noise Criterion Curves MODEL : SPW-LDR94GXH56(A/B) MODEL : SPW-LDR164GXH56(A/B) -LDR124GXH56(A/B) SOUND LEVEL : HIGH 36 dB(A), NC 29 / LOW 33 dB(A), NC 25 SOUND LEVEL : HIGH 36 dB(A), NC 29 / LOW 34 dB(A), NC 27 CONDITION : Under the unit 1.5 m...
Page 516 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 11. 1-Way Air Discharge Semi-concealed Slim Type (L Type) 11-5. Air Flow Distance Chart SPW-LDR94GXH56(A/B), -LDR124GXH56(A/B), -LDR164GXH56(A/B) HORIZONTAL DISTANCE (m) AXIS AIR VELOCITY SPW-LDR184GXH56(A/B) HORIZONTAL DISTANCE (m) AXIS AIR VELOCITY SPW-LDR254GXH56(A/B) HORIZONTAL DISTANCE (m) AXIS AIR VELOCITY 1 : LOUVER ANGLE 15 in Cooling mode Condition Fan Speed : Hi...
Page 517: Total Heat Exchanger With Dx Coil (Gu Type)
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) 12-1. Speciﬁ cations Unit speciﬁ cations (A) MODEL NAME Heat Recovery with Direct-expansion Coil MODEL No. SPW-GU055XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating...
Page 518 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) Unit speciﬁ cations (B) MODEL NAME Heat Recovery with Direct-expansion Coil MODEL No. SPW-GU075XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating...
Page 519 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) Unit speciﬁ cations (C) MODEL NAME Heat Recovery with Direct-expansion Coil MODEL No. SPW-GU105XH POWER SOURCE 220 - 230 - 240 V, single-phase, 50/60 Hz PERFORMANCE Cooling Heating...
Page 520 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) 12-2. Control Speciﬁ cations Unit speciﬁ cations MICROCOMPUTER CONTROL Cooling 18 °C – 30 °C Preset temperature range Heating 16 °C – 30 °C Thermal modulation Auto 17 °C –...
Page 521 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) 12-3. Dimensional Data SPW-GU055XH Inspection access 450 450 Field supply Inspection Inspection access access 450 450 450 450 1 Refrigerant tubing joint (Liquid tube ø6.35 flare) Field supply Field supply 2 Refrigerant tubing joint (Gas tube ø12.7 flare)
Page 522 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) SPW-GU105XH Inspection access 450 450 Field supply Inspection Inspection access access 450 450 450 450 Field supply Field supply Refrigerant tubing joint (Liquid tube ø6.35 flare) Refrigerant tubing joint (Gas tube ø12.7 flare) 1903 Suspension bolt hole (4 –...
Page 523 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) 12-4. Noise Criterion Curves MODEL SPW-GU055XH MODEL SPW-GU075XH SOUND LEVEL 50dB(A) SOUND LEVEL 51dB(A) CONDITION Under the unit 1.5 m CONDITION Under the unit 1.5 m NC-70 NC-70 NC-60...
Page 524 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) 12-5. Indoor Fan Performance How to Read the Diagram The vertical axis is the EXTERNAL STATIC PRESSURE (Pa) while the horizontal axis represents the AIR FLOW (m /h).
Page 525 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 12. Total Heat Exchanger with DX coil (GU Type) SPW-GU105XH Air charge Air discharge 1000 1100 1200 1000 1100 1200 Air Flow Volume (m Air Flow Volume (m Electrical component box motor Fan motor socket (At shipment) (Connected external static pressure line switching...
Page 526: Intaking Fresh Air Of Semi-Concealed Type And Concealed-Duct Type
3-WAY ECO-i SYSTEM Unit Speciﬁ cations 13. Intaking Fresh Air of Semi-Concealed Type and Concealed-Duct Type Precautions Regarding External Air Intake (1) Ventilation Load Ensure that the design of the air-conditioner takes air-conditioning loads into consideration when external air intake is involved. (2) Restrictions on External Air Intake Ensure that the design conforms to the restrictions on air intake volume stipulated in accordance with the model of the indoor unit and the intake method.
Page 527 3-WAY ECO-i SYSTEM Unit Speciﬁ cations 13. Intaking Fresh Air of Semi-Concealed Type and Concealed-Duct Type X, XM Types When an External Air Intake Flange (ø100) is in Use External Air Intake Volume and Resistance and With the External Air Intake Flange Attached Operation Noise Characteristics within the Unit X Type XM Type...
Page 528 – MEMO – 4-370...
Page 529 Test Run Contents 5. TEST RUN 1. Preparing for Test Run .......................5-2 2. Test Run Procedure ......................5-3 3. Main Outdoor Unit PCB Setting..................5-4 4. Auto Address Setting ......................5-6 5. Remote Controller Test Run Settings ................5-13 6. Caution for Pump Down ....................5-13 7.
Page 530: Preparing For Test Run
Test Run 1. Preparing for Test Run 1. Preparing for Test Run Before attempting to start the air conditioner, check the following. (1) The control wiring is correctly connected and all elect- rical connections are tight. (2) The transportation pads for the indoor fan have been removed.
Page 531: Test Run Procedure
Test Run 2. Test Run Procedure 2. Test Run Procedure Items to Check Before the Test Run Turn the remote power switch on at least 5 Recheck the items to check before the test run. hours before the test, in order to energize the crank case heater.
Page 532: Main Outdoor Unit Pcb Setting
Test Run 3. Main Outdoor Unit PCB Setting 3. Main Outdoor Unit PCB Setting (CR-C1155DZH8) S002 S004 S007 S006 S003 S005 CN100 CN101 CN003 Fig. 5-4...
Page 533 Test Run 3. Main Outdoor Unit PCB Setting Examples of the No. of indoor units settings (S005, S004) Indoor unit setting (S005) Indoor unit setting (S004) No. of indoor units (3P DIP switch, blue) (Rotary switch, red) 10 20 30 1 unit (factory setting) All OFF Set to 1...
Page 534: Auto Address Setting
Test Run 4. Auto Address Setting 4. Auto Address Setting Basic wiring diagram: Example (1) • If link wiring is not used (The inter-unit control wires are not connected to multiple refrigerant systems.) Indoor unit addresses can be set without operating the compressors. No.
Page 535 Test Run 4. Auto Address Setting Basic wiring diagram: Example (2) • If link wiring is used When multiple outdoor main units exist, remove the socket that is used to short-circuit the terminal plug (CN003) from No. 1 (main unit) settings all outdoor unit PCBs except for 1.
Page 536 Test Run 4. Auto Address Setting Case 2 Automatic Address Setting (no compressor operation) Indoor and outdoor unit power can be turned ON for each system separately. Indoor unit addresses can be set without operating the compressors. Automatic Address Setting from Outdoor Unit 1.
Page 537 Test Run 4. Auto Address Setting Case 3A Automatic Address Setting in Heating Mode Indoor and outdoor unit power cannot be turned ON for each system separately. In the following, automatic setting of indoor unit addresses is not possible if the compressors are not operating. Therefore perform this process only after completing all refrigerant tubing work.
Page 538 Test Run 4. Auto Address Setting Case 3B Automatic Address Setting in Cooling Mode  Indoor and outdoor unit power cannot be turned ON for each system separately. In the following, automatic setting of indoor unit addresses is not possible if the compressors are not operating. Therefore perform this process only after completing all refrigerant tubing work. Automatic address setting can be performed during Cooling operation. Automatic Address Setting from Outdoor Unit 1. Perform steps 1 - 4 in the same way as for Case 2 . 5. Turn the indoor and outdoor unit power ON at all systems. 6. To perform automatic address setting in Cooling mode , on the outdoor main unit control PCB in the refrigerant system where you wish to set the addresses, short-circuit the mode change 2P pin (CN101). At the same time, short-circuit the automatic address pin (CN100) for 1 second or longer, then release it. (Be sure to perform this process for one system at a time. Automatic address settings cannot be performed for more than one system at the same time.) (Communication for automatic address setting begins, the compressors turn ON, and automatic address setting in Cool- ing mode begins.) (All indoor units operate.) * To cancel, again short-circuit the automatic address pin (CN100) for 1 second or longer, then release it. The...
Page 539 Test Run 4. Auto Address Setting Display during automatic address setting On outdoor main unit PCB Do not short-circuit the automatic address setting pin (CN100) again while automatic address setting is in progress. Doing so will cancel the setting operation and will cause LEDs 1 and 2 to turn OFF. Blink alternately When automatic address setting has been successfully completed, both LEDs 1 and 2 turn OFF.
Page 540 Test Run 4. Auto Address Setting Request concerning recording the indoor/outdoor unit combination Nos. After automatic address setting has been completed, be sure to record them for future reference. List the outdoor main unit system address and the addresses of the indoor units in that system in an easily visible location (next to the nameplate), using a permanent marking pen or similar means that cannot be removed easily. Example: (Outdoor) 1 – (Indoor) 1-1, 1-2, 1-3… (Outdoor) 2 – (Indoor) 2-1, 2-2, 2-3… These numbers are necessary for later maintenance. Please be sure to indicate them. Checking the indoor unit addresses Use the remote controller to check the indoor unit address. <If 1 indoor unit is connected to 1 remote controller> Press and hold the button and button for 4 seconds or longer (simple settings mode). 2. The address is displayed for the indoor unit that is connected to the remote controller. (Only the address of the indoor unit that is connected to the remote controller can be checked.) Press the button again to return to normal remote controller mode. <If multiple indoor units are connected to 1 remote controller (group control)>...
Page 541: Remote Controller Test Run Settings
Test Run 4. Auto Address Setting 5. Remote Controller Test Run Settings 6. Caution for Pump Down Chart of setting change according to each method An alarm will occur or the air conditioner will not operate properly unless proper setting changes are performed. Be sure to change the setting as follows. Shared solenoid Change necesasry Change of indoor How to change Combination valve kit YES/NO unit YES/NO Method 1 only — — Method 2 included Method 2 only From indoor unit *1 *method 3 excluded...
Page 542: Meaning Of Alarm Messages
Test Run 7. Meaning of Alarm Messages 7. Meaning of Alarm Messages Table of Self-Diagnostics Functions and Description of Alarm Displays. Alarm messages are indicated by the blinking of LED 1 and 2 (D72, D75) on the outdoor unit PCB. They are also displayed on the wired remote controller.
Page 543 Test Run 7. Meaning of Alarm Messages Alarm Possible cause of malfunction message Activation of Protective device in outdoor unit Compressor thermal protector is activated. protective is activated. Power supply voltage is unusual. (The voltage is more than 260 V device or less than 160 V between L and N phase.) Incorrect discharge temperature.
Page 544 Test Run 7. Meaning of Alarm Messages Alarm Alarm messages displayed on system controller message Indoor or main outdoor unit is not operating correctly. Serial Error in transmitting serial communication signal Mis-wiring of control wiring between indoor unit, main outdoor unit communication and system controller.
Page 545 Electrical Data Contents 6. ELECTRICAL DATA 1. Outdoor Unit ........................(1) SPW-C0705/0905/1155DZH8 ..................6-2 (2) SPW-C1305/1405DZH8 ....................6-4 2. Indoor Unit ......................... 6-6 (1)-1 SPW-XDR74/94/124/164/184/254/364/484/604GXH56(A/B) SPW-X075/095/125/165/185/255/365/485/605XH .............6-6 (1)-2 SPW-XM075/095/125/165/185XH ................6-8 SPW-SR74/94/124/164/184/254GXH56(A/B) ............6-9 SPW-ADR74/94/124GXH56(A/B) ................6-11 SPW-LDR94/124/164/184/254GXH56(A/B) ..............6-13 (5)-1 SPW-KR74/94/124/164/184GXH56(A/B) ..............6-15 (5)-2 SPW-KR254GXH56(A/B) ..................6-17 (5)-3 SPW-K075/095/125XH .....................6-19 SPW-TDR124/164/184/254/364/484GXH56(A/B)
Page 546 Electrical Data 1. Outdoor Unit (1) Electric Wiring Diagram SPW-C0705/0905/1155DZH8...
Page 547 Electrical Data 1. Outdoor Unit Schematic Diagram SPW-C0705/0905/1155DZH8...
Page 548 Electrical Data 1. Outdoor Unit (2) Electric Wiring Diagram SPW-C1305/1405DZH8...
Page 549 Electrical Data 1. Outdoor Unit Schematic Diagram SPW-C1305/1405DZH8...
Page 550 Electrical Data 2. Indoor Unit (1)-1 Electric Wiring Diagram SPW-XDR74/94/124/164/184/254/364/484/604GXH56(A/B) SPW-X075/095/125/165/185/255/365/485/605XH...
Page 551 Electrical Data 2. Indoor Unit Schematic Diagram SPW-XDR74/94/124/164/184/254/364/484/604GXH56(A/B) SPW-X075/095/125/165/185/255/365/485/605XH...
Page 552 Electrical Data 2. Indoor Unit (1)-2 Electric Wiring Diagram SPW-XM075/095/125/165/185XH...
Page 553 Electrical Data 2. Indoor Unit (2) Electric Wiring Diagram SPW-SR74/94/124/164/184/254GXH56(A/B)
Page 554 Electrical Data 2. Indoor Unit Schematic Diagram SPW-SR74/94/124/164/184/254GXH56(A/B) 6-10...
Page 555 Electrical Data 2. Indoor Unit (3) Electric Wiring Diagram SPW-ADR74/94/124GXH56(A/B) 6-11...
Page 556 Electrical Data 2. Indoor Unit Schematic Diagram SPW-ADR74/94/124GXH56(A/B) 6-12...
Page 557 Electrical Data 2. Indoor Unit (4) Electric Wiring Diagram SPW-LDR94/124/164/184/254GXH56(A/B) 6-13...
Page 558 Electrical Data 2. Indoor Unit Schematic Diagram SPW-LDR94/124/164/184/254GXH56(A/B) 6-14...
Page 559 Electrical Data 2. Indoor Unit (5)-1 Electric Wiring Diagram SPW-KR74/94/124/164/184GXH56(A/B) 6-15...
Page 560 Electrical Data 2. Indoor Unit Schematic Diagram SPW-KR74/94/124/164/184GXH56(A/B) 6-16...
Page 561 Electrical Data 2. Indoor Unit (5)-2 Electric Wiring Diagram SPW-KR254GXH56(A/B) 6-17...
Page 562 Electrical Data 2. Indoor Unit Schematic Diagram SPW-KR254GXH56(A/B) 6-18...
Page 563 Electrical Data 2. Indoor Unit (5)-3 Electric Wiring Diagram SPW-K075/095/125XH 6-19...
Page 564 Electrical Data 2. Indoor Unit (6) Electric Wiring Diagram SPW-TDR124/164/184/254/364/484GXH56(A/B) SPW-T125/165/185/255/365/485XH 6-20...
Page 565 Electrical Data 2. Indoor Unit Schematic Diagram SPW-TDR124/164/184/254/364/484GXH56(A/B) SPW-T125/165/185/255/365/485XH 6-21...
Page 566 Electrical Data 2. Indoor Unit (7)-1 Electric Wiring Diagram SPW -UR74/94/124/164/184/254/364/484/604GXH56(A/B) 6-22...
Page 567 Electrical Data 2. Indoor Unit Schematic Diagram SPW -UR74/94/124/164/184/254/364/484/604GXH56(A/B) 6-23...
Page 568 Electrical Data 2. Indoor Unit (7) -2 Electric Wiring Diagram SPW-U075/095/125/165/185/255/365/485/605XH 6-24...
Page 569 Electrical Data 2. Indoor Unit Schematic Diagram SPW-U075/095/125/165/185/255/365/485/605XH 6-25...
Page 570 Electrical Data 2. Indoor Unit (7)-3 Electric Wiring Diagram SPW-U075/095/125/165/185/255/365/485/605XHN -UR74/94/124/164/184/254/304/364/484/604SXH56B -U075/095/125/165/185/255/305/365/485/605SXH -U075/095/125/165/185/255/305/365/485/605SXHT 6-26...
Page 571 Electrical Data 2. Indoor Unit Schematic Diagram SPW-U075/095/125/165/185/255/365/485/605XHN -UR74/94/124/164/184/254/304/364/484/604SXH56B -U075/095/125/165/185/255/305/365/485/605SXH -U075/095/125/165/185/255/305/365/485/605SXHT 6-27...
Page 572 Electrical Data 2. Indoor Unit (7)-4 Electric Wiring Diagram SPW-US075/095/125/165/185XH 6-28...
Page 573 Electrical Data 2. Indoor Unit Schematic Diagram SPW-US075/095/125/165/185XH 6-29...
Page 574 Electrical Data 2. Indoor Unit (8)-1 Electric Wiring Diagram SPW-DR254GXH56(A/B) 6-30...
Page 575 Electrical Data 2. Indoor Unit Schematic Diagram SPW-DR254GXH56(A/B) 6-31...
Page 576 Electrical Data 2. Indoor Unit (8)-2 Electric Wiring Diagram SPW-DR364GXH56(A/B) 6-32...
Page 577 Electrical Data 2. Indoor Unit Schematic Diagram SPW-DR364GXH56(A/B) 6-33...
Page 578 Electrical Data 2. Indoor Unit (8)-3 Electric Wiring Diagram SPW-DR484GXH56(A/B) 6-34...
Page 579 Electrical Data 2. Indoor Unit Schematic Diagram SPW-DR484GXH56(A/B) 6-35...
Page 580 Electrical Data 2. Indoor Unit (8)-4 Electric Wiring Diagram SPW-DR764GXH56(A/B) 6-36...
Page 581 Electrical Data 2. Indoor Unit Schematic Diagram SPW-DR764GXH56(A/B) 6-37...
Page 582 Electrical Data 2. Indoor Unit (8)-5 Electric Wiring Diagram SPW-DR964GXH56(A/B) 6-38...
Page 583 Electrical Data 2. Indoor Unit Schematic Diagram SPW-DR964GXH56(A/B) 6-39...
Page 584 Electrical Data 2. Indoor Unit (9) Electric Wiring Diagram SPW-FR74/94/124/164/184/254GXH56(A/B) 6-40...
Page 585 Electrical Data 2. Indoor Unit Schematic Diagram SPW-FR74/94/124/164/184/254GXH56(A/B) 6-41...
Page 586 Electrical Data 2. Indoor Unit (10) Electric Wiring Diagram SPW-FMR74/94/124/164/184/254GXH56(A/B) 6-42...
Page 587 Electrical Data 2. Indoor Unit Schematic Diagram SPW-FMR74/94/124/164/184/254GXH56(A/B) 6-43...
Page 588 Electrical Data 2. Indoor Unit (11) Electric Wiring Diagram SPW-GU055/075/105XH 6-44...
Page 589 Electrical Data 2. Indoor Unit Schematic Diagram SPW-GU055/075/105XH 6-45...
Page 590 – MEMO – 6-46...
Page 591 PCB and Functions Contents 7. PCB AND FUNCTIONS 1. Outdoor Unit Control PCB ....................7-2 1-1. Outdoor Unit Control PCB CR-C1155DZH8 ..............7-2 1-2. Functions (for CR-C1155DZH8) .................. 7-3 2. Indoor Unit Control PCB Switches and Functions ............7-6 2-1. For AC Fan Motor (CR-UXRP71B-B / S, U, FM, F, D and GU) ........
Page 592: Outdoor Unit Control Pcb
PCB and Functions 1. Outdoor Unit Control PCB 1-1. Outdoor Unit Control PCB CR-C1155DZH8 S002 S004 Alarm LED Alarm LED S007 EEPROM (LED1)(D72) (LED 2)(D75) S003 S005 S010 memory IC S006 (IC018) A. ADD (CN100) pin OAC (CN105) pin MODE (CN101) pin AP (CN102) pin STOP (CN104) pin CHK (CN023) pin...
Page 593 PCB and Functions 1. Outdoor Unit Control PCB 1-2. Functions (for CR-C1155DZH8) 2P plug (white): Automatic address setting pin Automatic address setting Short-circuit this pin for 1 second or longer to automatically set the addresses at the (CN100) indoor units that are connected to that outdoor unit and are within the same system. The system address is "1"...
Page 594 PCB and Functions 1. Outdoor Unit Control PCB LED1, 2 LED (red 2) DO72, DO75 LED 1 and 2 blink alternately while automatic address setting is in progress. Display the alarm contents for alarms which were detected by the outdoor unit. LED (red): Power indicator Indicates the DC 5V power on the outdoor unit control PCB.
Page 595 PCB and Functions 1. Outdoor Unit Control PCB Table 1.Setting the System Address[S002: Rotary switch (black), S003: 2P DIP (blue)] (for CR-C1155DZH8) S003 setting S002 setting (system Outdoor system address No. address switch) 1P (10s digit) 2P (20s digit) 1 refrigerant system only Link wiring Table 3.Setting the Number of Outdoor Units...
Page 596: Indoor Unit Control Pcb Switches And Functions
PCB and Functions 2. Indoor Unit Control PCB Switches and Functions Indoor Unit Control PCB Switches and Functions Indoor unit control PCB T10: 6P plug (yellow):Used for remote control. (Refer to the remote control section.) (CN061) Control items: (1) Start/stop input (2) Remote controller prohibit input (3) Start signal output (4) Alarm signal output...
Page 597 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-1. For AC Fan Motor (CR-UXRP71B-B* / S, U, FM, F, D and GU) * Some models of the type U use CB-UXRP71B-B instead of CR-UXRP71B-B. EEPROM (IC010) OC (CN040) EMG (CN044) VARISTOR (VA100) JP001...
Page 598 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-3. Explanation of Functions (CR-UXRP71B-B*) * Some models of the type U use CB-UXRP71B-B instead of CR-UXRP71B-B. 6P plug (YEL): Used for remote control operation. (CN061) Control items: Start/stop input Remote controller prohibit input (for remote control operation) Start signal output...
Page 599 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2P (RED)/Used for Humidiﬁ er output. (CN079) OPTION 6P (WHT), Outputs external signals as shown in the ﬁ gure below. (CN060) Relay (DC 12V, field supply) (Note) Fan signal OPTION (WHT) Heater signal...
Page 600 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-4. T10 Terminal Wiring Example No Signal OFF Control No Signal OFF Control This is a method to control the Indoor unit individually, and is to connect to the Indoor unit. In case of group control, the unit can be operated even if each indoor unit (Control PCB) is connected within the group.
Page 601 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions Indoor Unit Control PCB 2-5. CR1 (for CR-KR74GXH56/SPW-KR74GXH56~SPW-KR184GXH56) (Wall-Mounted) If the fuse (F002) has CHK (test) pin DISP pin blown, determine the (CN011) (CN010) cause and correct it. Then change the socket from the OC plug to the EMG plug.
Page 602 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-6. CR1 (for CR-KR254GXH56/SPW-KR254GXH56) (Wall-Mounted) If the fuse (F002) has blown, determine the cause and correct it. CHK (test) pin Then change the socket (CN011) from the OC plug to the DISP pin EMG plug.
Page 603 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-7. CR2 (for POW-KR74GXH56/SPW-KR74GXH56~SPW-KR254GXH56) (Wall-Mounted) Control circuit fuse (F201) T20 plug (CN204) TRANS-S plug (CN202) OP1 plug (CN203) 7-13...
Page 604 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-8. CR1 (for CR-K075XH/SPW-K075/095/125XH) (Wall-Mounted) Power LED (D002) EMG plug OC plug OPTION plug Indoor heat exchanger (E2) sensor EXCT plug Indoor heat exchanger (E1) sensor DISP pin Microcomputer T10 plug JP001 CHK (test) pin...
Page 605 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions 2-9. Explanation of Functions (CR-KXRP56AN, CR-KXRP80AN, POW-KRP50A) 6P plug (yellow): Used for remote control. (CN105) Control items: Start/stop input Remote controller prohibit input (For remote control) Start signal output Alarm signal output EXCT 2P plug (red): Can be used for demand control.
Page 606 PCB and Functions 2. Indoor Unit Control PCB Switches and Functions OPTION 6P (white): Outputs external signals as shown in the figure below. (CN014) Relay (DC 12V, field supply) (Note) Fan signal OPTION (white) Heat start signal DC 12V Cool start signal Indoor unit control PCB (CR1) Thermostat signal Defrost signal...
Page 607 Capacity Table Contents 8. CAPACITY TABLE 1. Capacity Ratio of Outdoor Unit ..................8-2 1-1. SPW-C0705DZH8 (Cooling) ..................8-2 1-2. SPW-C0705DZH8 (Heating) ..................8-4 1-3. SPW-C0905DZH8 (Cooing) ..................8-6 1-4. SPW-C0905DZH8 (Heating) ..................8-8 1-5. SPW-C1155DZH8 (Cooling) ..................8-10 1-6. SPW-C1155DZH8 (Heating) ..................8-12 1-7. SPW-C1305DZH8 (Cooling) ..................8-14 1-8.
Page 608: Capacity Ratio Of Outdoor Unit
Capacity Table 1. Capacity Ratio of Outdoor Unit 1-1. SPW-C0705DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB...
Page 609: Capacity Table
Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C0705DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB...
Page 610 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-2. SPW-C0705DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB...
Page 611 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C0705DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB...
Page 612 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-3. SPW-C0905DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 24.1...
Page 613 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C0905DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 17.9...
Page 614 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-4. SPW-C0905DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 615 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C0905DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 616 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-5. SPW-C1155DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 28.9...
Page 617 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1155DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 21.4...
Page 618 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-6. SPW-C1155DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 619 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1155DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 620 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-7. SPW-C1305DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 34.5...
Page 621 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1305DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 25.6...
Page 622 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-8. SPW-C1305DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 623 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1305DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 624 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-9. SPW-C1405DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 38.8...
Page 625 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1405DZH8 (Cooling) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CWB Combination(%): Outdoor 16.0 17.0 18.0 19.0 20.0 21.0 22.0 Indoor/outdoor air temp. capacity ratio °CDB -5.0 28.8...
Page 626 Capacity Table 1. Capacity Ratio of Outdoor Unit 1-10. SPW-C1405DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 627 Capacity Table 1. Capacity Ratio of Outdoor Unit SPW-C1405DZH8 (Heating) Capacity Ratio 50-130% TC: Total capacity (kW), PI: Power input (kW) Indoor air temp. : °CDB Outdoor Combination(%): 15.0 17.0 19.0 20.0 21.0 23.0 25.0 air temp. Indoor/outdoor capacity ratio °CDB °CWB -19.8...
Page 628: Cooling Capacity Of Indoor Unit
Capacity Table 2. Cooling Capacity of Indoor Unit 2-1. 4-Way Air Discharge Semi-concealed Type (X, XM Types) SPW-XDR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 15.5 m /min CONDENSER...
Page 629 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 15.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 630 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 15.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 631 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 15.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 632 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW AIR FLOW 16.0 m /min RATING CAPACITY: CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 633 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW AIR FLOW 20.0 m /min RATING CAPACITY: CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 634 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR364GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 10.6 kW RATING CAPACITY: AIR FLOW 28.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 635 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR484GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 14.0 kW RATING CAPACITY: AIR FLOW 33.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 636 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XDR604GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 16.0 kW AIR FLOW 34.0 m /min RATING CAPACITY: CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 637 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XM075XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 638 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XM095XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 639 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XM125XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 640 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XM165XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.7 kW RATING CAPACITY: AIR FLOW 10.7 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 641 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-XM185XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 12.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 642 Capacity Table 2. Cooling Capacity of Indoor Unit 2-2. 2-Way Air Discharge Semi-concealed Type (S Type) SPW-SR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER...
Page 643 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-SR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 644 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-SR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.6 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 645 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-SR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 11.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 646 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-SR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 11.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 647 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-SR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 19.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 648 Capacity Table 2. Cooling Capacity of Indoor Unit 2-3. 1-Way Air Discharge Semi-concealed Type (A Type) SPW-ADR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER...
Page 649 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-ADR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 650 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-ADR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 651 Capacity Table 2. Cooling Capacity of Indoor Unit 2-4. Wall-Mounted Type (K Type) SPW-KR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR...
Page 652 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-KR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 653 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-KR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 654 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-KR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 655 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-KR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 656 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-KR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 16.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 657 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-K075XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 658 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-K095XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 659 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-K125XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 660 Capacity Table 2. Cooling Capacity of Indoor Unit 2-5. Ceiling-Mounted Type (T Type) SPW-TDR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR...
Page 661 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-TDR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 13.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 662 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-TDR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 13.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 663 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-TDR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 18.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 664 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-TDR364GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 10.6 kW RATING CAPACITY: AIR FLOW 27.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 665 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-TDR484GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 14.0 kW RATING CAPACITY: AIR FLOW 30.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 666 Capacity Table 2. Cooling Capacity of Indoor Unit 2-6. Concealed Duct Type (U, US Types) SPW-UR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR...
Page 667 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 668 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 10.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 669 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 670 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 671 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 18.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 672 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR364GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 10.6 kW RATING CAPACITY: AIR FLOW 30.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 673 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR484GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 14.0 kW RATING CAPACITY: AIR FLOW 33.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 674 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-UR604GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 16.0 kW RATING CAPACITY: AIR FLOW 33.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 675 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-US075XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 8.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 676 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-US095XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 8.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 677 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-US125XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 678 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-US165XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.7 kW RATING CAPACITY: AIR FLOW 10.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 679 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-US185XH Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 12.5 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 680 Capacity Table 2. Cooling Capacity of Indoor Unit 2-7. Concealed Duct High Static Pressure Type (D Type) SPW-DR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 23.0 m /min CONDENSER...
Page 681 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-DR364GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 10.6 kW RATING CAPACITY: AIR FLOW 30.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 682 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-DR484GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 14.0 kW RATING CAPACITY: AIR FLOW 36.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 683 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-DR764GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 22.4 kW RATING CAPACITY: AIR FLOW 56.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 684 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-DR964GXH56B Power supply : 220/230/240V 1phase-50Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 28.0 kW RATING CAPACITY: AIR FLOW 72.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP. ( W.B. D.B. 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 20.6 14.2 14.2 14.2 14.2...
Page 685 Capacity Table 2. Cooling Capacity of Indoor Unit 2-8. Floor-Standing Type (F Type) SPW-FR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 7.0 m /min CONDENSER EVAPORATOR...
Page 686 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 7.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 687 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 688 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 689 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 15.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP. ( W.B. D.B. 8-83...
Page 690 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.1 kW RATING CAPACITY: AIR FLOW 17.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 691 Capacity Table 2. Cooling Capacity of Indoor Unit 2-9. Concealed Floor-Standing Type (FM Type) SPW-FMR74GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.2 kW RATING CAPACITY: AIR FLOW 7.0 m /min CONDENSER EVAPORATOR...
Page 692 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FMR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 7.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 693 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FMR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 9.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 694 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FMR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 695 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FMR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 15.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 696 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-FMR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.1 kW RATING CAPACITY: AIR FLOW 17.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 697 Capacity Table 2. Cooling Capacity of Indoor Unit 2-10. 1-Way Air Discharge Semi-concealed Slim Type (L Type) SPW-LDR94GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 2.8 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER...
Page 698 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-LDR124GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 3.6 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 699 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-LDR164GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 4.5 kW RATING CAPACITY: AIR FLOW 12.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 700 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-LDR184GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 5.6 kW RATING CAPACITY: AIR FLOW 13.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 701 Capacity Table 2. Cooling Capacity of Indoor Unit SPW-LDR254GXH56B Power supply : 220/230/240V 1phase-50,60Hz TC : Total Cooling Capacity (kW) , SHC : Sensible Heat Capacity (kW) 7.3 kW RATING CAPACITY: AIR FLOW 18.0 m /min CONDENSER EVAPORATOR AIR INTAKE. TEMP AMBIENT TEMP.
Page 702 – MEMO – 8-96...
Page 703 SANYO Electric Co., Ltd. 200812B DC Printed in Japan...

This manual is also suitable for:

Spw-c1405dzh8 Spw-c0905dzh8 Spw-c1305dzh8 Spw-c1155dzh8

Sanyo SPW-C0705DZH8 Technical Data Manual

Section 1: OUTLINE of 3-WAY ECO-I SYSTEM

Section 2: DESIGN of 3-WAY ECO-I SYSTEM

1 Main Operating Functions

1 Main Operating Functions

Section 3: Control of 3-WAY ECO-I SYSTEM

2 Wireless Remote Controller

2 Wireless Remote Controller

4 System Controller

Section 4: 3-WAY ECO-I SYSTEM UNIT SPECIFICATIONS

Quick Links

TECHNICAL DATA

Related Manuals for Sanyo SPW-C0705DZH8

Summary of Contents for Sanyo SPW-C0705DZH8

This manual is also suitable for:

Table of Contents
