SERVICE MANUAL

SPW-X253GH56 ⁄ SPW-C253GH5
SPW-X253GH56 ⁄ SPW-C253GH8
SPW-X363GH56 ⁄ SPW-C363GH8
SPW-X483GH56 ⁄ SPW-C483GH8
SPLIT SYSTEM AIR CONDITIONER
INDOOR MODEL No.
SPW-X253GH56
SPW-X253GH56
SPW-X363GH56
SPW-X483GH56
Indoor Unit
SPW-X253GH56
SPW-X363GH56
SPW-X483GH56
85464849133001
PRODUCT CODE No.
OUTDOOR MODEL No.
854 011 35
SPW-C253GH5
854 011 35
SPW-C253GH8
854 011 36
SPW-C363GH8
854 011 37
SPW-C483GH8
0406_X_S
0407_X_S
FILE NO.
PRODUCT CODE No.
854 012 18
854 012 19
854 012 20
854 012 21
Outdoor Unit
0408_C_S
SPW-C253GH5
SPW-C253GH8
0409_C_S
SPW-C363GH8
SPW-C483GH8
REFERENCE NO.
Section
1
2
3
4
5
SM
830033

Advertisement

Table of Contents
loading

Related Manuals for Sanyo SPW-X253GH56

Summary of Contents for Sanyo SPW-X253GH56

  • Page 1: Service Manual

    SERVICE MANUAL FILE NO. SPW-X253GH56 ⁄ SPW-C253GH5 SPW-X253GH56 ⁄ SPW-C253GH8 SPW-X363GH56 ⁄ SPW-C363GH8 SPW-X483GH56 ⁄ SPW-C483GH8 SPLIT SYSTEM AIR CONDITIONER Section INDOOR MODEL No. PRODUCT CODE No. OUTDOOR MODEL No. PRODUCT CODE No. SPW-X253GH56 854 011 35 SPW-C253GH5 854 012 18...

  • Page 2: Table Of Contents

    WHO SHOULD USE THIS MANUAL This service manual is made to assist the service technician apply his knowledge and training to this model air conditioner. This manual is written both for experienced service persons and those who are new to air conditioning service. To help those with less experience or who are new to this kind of unit we have included more explanations of basic procedures in simple language than is usual in some service manuals.
  • Page 3 2-10 Defrosting Control, Outdoor Heat Exchanger Coil (Heating)......36 2-11 4-Way Valve, Solenoid Control ................37 (A) Normal Control Mode ..................37 (B) AUTO Control Mode ..................38 2-12 Automatic Restart after Power Interruption ............38 2-13 Electronic Refrigerant Control Valve ..............39 2-14 Compressor Discharge Gas Temperature ............
  • Page 4 Introduction: Read Me First! WHAT IS IN THIS MANUAL This manual will help you understand and service the air conditioner. To help you find the information you need, we have divided it into 5 main sections. Each section is divided into chapters with charts, tables and explanations to help you find and repair problems.
  • Page 5 SM830033 – 6 –...

  • Page 6: Specifications

    1. SPECIFICATIONS Unit Specifications ..................8 Major Component Specifications ..............12 (A) Indoor Unit ....................12 (B) Outdoor Unit ................... 14 Other Component Specifications ..............17 Dimensional Data ...................19 (A) Indoor Unit ....................19 (B) Outdoor Unit .....................21 Refrigerant Flow Diagram ................23 Operating Range ....................24 SM830033 –...

  • Page 7: Unit Specifications

    1. Specifications 1-1 Unit Specifications MODEL No. Indoor Unit SPW-X253GH56 Outdoor Unit SPW-C253GH5 POWER SOURCE 220 - 230 - 240 V / 1 Phase / 50 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi/Me/Lo) m3 / h...
  • Page 8 1. Specifications 1-1 Unit Specifications MODEL No. Indoor Unit SPW-X253GH56 Outdoor Unit SPW-C253GH8 POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz PERFORMANCE Cooling Heating Capacity BTU / h 25,000 27,000 Air circulation (Hi/Me/Lo) m3 / h...
  • Page 9 1. Specifications 1-1 Unit Specifications MODEL No. Indoor Unit SPW-X363GH56 Outdoor Unit SPW-C363GH8 POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz PERFORMANCE Cooling Heating Capacity 10.6 11.4 BTU / h 36,000 39,000 Air circulation (Hi/Me/Lo) m3 / h 1,920/1,680/1,320 Moisture removal(High)
  • Page 10 1. Specifications 1-1 Unit Specifications MODEL No. Indoor Unit SPW-X483GH56 Outdoor Unit SPW-C483GH8 POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz PERFORMANCE Cooling Heating Capacity BTU / h 47,800 54,600 Air circulation (Hi/Me/Lo) m3 / h 1,920/1,680/1,320 Moisture removal(High) Liters/ h...

  • Page 11: Major Component Specifications

    1. Specifications 1-2 Major Component Specifications (A) Indoor Unit MODEL No. SPW-X253GH56 Source 220 - 230 - 240 V / 1 phase / 50 Hz Controller P.C.B. Ass’y CR - X253GH (Microprocessor) Fan (Number…diameter) Turbo (1...ø490) Fan Motor Model…Nominal output SFG6X - 41A5P...40 W...
  • Page 12 1. Specifications 1-2 Major Component Specifications (A) Indoor Unit MODEL No. SPW-X363GH56 SPW-X483GH56 Source 220 - 230 - 240 V / 1 phase / 50 Hz Controller P.C.B. Ass’y CR - X253GH (Microprocessor) Fan (Number…diameter) Turbo (1...ø490) Fan Motor Model…Nominal output SFG6X - 61A3P...60 W Source 220 - 230 - 240 V / 1 phase / 50 Hz...

  • Page 13: (B) Outdoor Unit

    1. Specifications 1-2 Major Component Specifications (B) Outdoor Unit Unit Model No. SPW-C253GH5 Source 220 - 230 - 240 V / 1 phase / 50 Hz Controller P.C.B. Ass'y CR - C253GH5 (Microprocessor) Control circuit fuse 250 V, 3.15 A Compressor Rotary (Hermetic) Model ..
  • Page 14 1. Specifications 1-2 Major Component Specifications (B) Outdoor Unit Unit Model No. SPW-C253GH8 Source 380 - 400 - 415 V / 3 phase / 50 Hz Controller P.C.B. Ass'y CR - C253GH (Microprocessor) Control circuit fuse 250 V, 3.15 A Compressor Rotary (Hermetic) Model ..
  • Page 15 1. Specifications 1-2 Major Component Specifications (B) Outdoor Unit Unit Model No. SPW-C363GH8 SPW-C483GH8 Source 380 - 400 - 415 V / 3 phase / 50 Hz Controller P.C.B. Ass'y CR - C253GH (Microprocessor) Control circuit fuse 250 V, 3.15 A Compressor Rotary (Hermetic) Scroll (Hermetic)

  • Page 16: Other Component Specifications

    1. Specifications 1-3 Other Component Specifications Unit model No. Indoor Unit Outdoor Unit SPW-X253GH56 SPW-C253GH5, SPW-C253GH8 Power Transformer ATR - II215TA ATR - I65B Rated Primary V. Hz AC 230 V, 50 Hz AC 230, 50 Hz Secondary 10.2V , 1.4 A 14 V , 0.4 A...
  • Page 17 1. Specifications 1-3 Other Component Specifications Unit model No. Indoor Unit Outdoor Unit SPW-X363GH56 SPW-X483GH56 SPW-C363GH8 SPW-C483GH8 Power Transformer ATR - II215TA ATR - I65B Rated Primary V. Hz AC 230 V, 50 Hz AC 230, 50 Hz Secondary 10.2V , 1.4 A 14 V , 0.4 A 14 V , 0.5 A —...

  • Page 18: Dimensional Data

    1. Specifications 1-4 Dimensional Data (A) Indoor Unit : SPW-X253GH56 820 (Ceiling opening) 590 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line (ø 6.35) Refrigerant gas line (ø 15.88) Drain connection Power supply entry For discharge duct...
  • Page 19 1. Specifications 1-4 Dimensional Data (A) Indoor Unit : SPW-X363GH56,SPW-X483GH56 820 (Ceiling opening) 590 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line (ø9.52) Refrigerant gas line (ø19.05) Drain connection Power supply entry For discharge duct Humidifier (option) mounting hole Suspention bolt mounting 0183_X_I Fig.

  • Page 20: (B) Outdoor Unit

    1. Specifications 1-4 Dimensional Data (B) Outdoor Unit : SPW-C253GH5, SPW-C253GH8 Dimension : mm Hole for anchor bolt (4-ø13) Refrigerant tube joint (narrow tube) Flare connection 1/4 in (6.35 mm) Refrigerant tube joint (wide tube) Flare connection 5/8 in (15.88 mm) Refrigerant tubing inlet Power supply inlet 0411_C_S...
  • Page 21 1. Specifications 1-4 Dimensional Data (B) Outdoor Unit : SPW-C363GH8, SPW-C483GH8 Dimension : mm Hole for anchor bolt (4-ø13) Refrigerant tube joint (narrow tube) Flare connection 3/8 in (9.52 mm) Refrigerant tube joint (wide tube) Flare connection 3/4 in (19.05 mm) Refrigerant tubing inlet Power supply inlet 0412_C_S...

  • Page 22: Refrigerant Flow Diagram

    1. Specifications 1-5 Refrigerant Flow Diagram Outdoor Unit : SPW-C253GH5 Indoor Unit : SPW-X253GH56 SPW-C253GH8 Compressor Accumulator Accumulator Gas line service valve Gas line O.D. nipple ø15.88mm (5/8") High Muffler pressure switch 4-way valve Heat exchanger Heat exchanger Distributor Strainer Electronic ref.control...

  • Page 23: Operating Range

    1. Specifications 1-5 Refrigerant Flow Diagram Outdoor Unit : SPW-C363GH8 Indoor Unit : SPW-X363GH56 SPW-C483GH8 SPW-X483GH56 Compressor *Accumulator Accumulator Gas line service valve Gas line High pressure O.D. nipple switch ø19.05mm (3/4") Muffler 4-way valve Heat exchanger Heat exchanger Distributor Strainer Electronic Distributor...

  • Page 24: Processes And Functions

    2. Processes and functions 2. PROCESSES AND FUNCTIONS Room Temperature Control ................26 (A) Cooling .....................26 (B) Heating .....................27 Cold Draft Prevention (Heating Cycle) ............28 Automatic Fan Speed (Indoor Unit)............... 29 (A) Cooling .....................29 (B) Heating .....................29 Outdoor Fan Speed Control ................30 (A) Cooling .....................30 (B) Heating .....................30 Freeze Prevention (Cooling) .................

  • Page 25: Room Temperature Control

    2. Processes and functions 2-1 Room Temperature Control The unit adjusts room temperature by turning the outdoor unit’s compressor ON and OFF. This process is controlled by the thermostat located in the indoor unit. The figures on this and the next page show how each part of the system performs as the room temperature changes and the thermostat activates the compressor to start (thermo ON) or stop (thermo OFF).

  • Page 26: (B) Heating

    2. Processes and functions (B) Heating THERMO. ON THERMO. ON REMOTE CONTROL THERMO. OFF THERMO. OFF SENSOR (Only for wireless THERMO. ON remote controller) SET. +1°C SETTING TEMP. SET. –1°C THERMO. OFF THERMO. OFF BODY SENSOR THERMO. ON THERMO. ON THERMO.

  • Page 27: Cold Draft Prevention (Heating Cycle)

    2. Processes and functions 2-2 Cold Draft Prevention (Heating Cycle) The cold draft prevention function controls indoor fan speed so a strong draft of cold air will not blow out before the indoor heat exchange coils have warmed up. STANDBY shows on the remote controller when the indoor fan speed is LL (very low) or OFF.

  • Page 28: Automatic Fan Speed (Indoor Unit)

    2. Processes and functions 2-3 Automatic Fan Speed (Indoor Unit) By pressing the FAN SPEED button on the remote controller, the fan speed can be set at one of four steps: AUTO., HI., MED., or LO. When set at AUTO. the indoor unit fan speed will be automatically adjusted to the room temperature as the two charts shown below.

  • Page 29: Outdoor Fan Speed Control

    2. Processes and functions 2-4 Outdoor Fan Speed Control To optimize the performance of air conditioner, the outdoor fan speed is selected automatically according to the outdoor temperature. Note that in both Cooling and Heating modes, the fan comes on at first at high speed (H mode) for 5 seconds.

  • Page 30: Freeze Prevention (Cooling)

    2. Processes and functions 2-5 Freeze Prevention (Cooling) Freeze Prevention keeps the indoor heat exchange coil from freezing. Freezing reduces the efficiency of the unit, and frost buildup on the coil blocks cool air circulation from the indoor unit's fan. MIN.

  • Page 31: Condensing Temperature Control (Cooling)

    2. Processes and functions 2-6 Condensing Temperature Control (Cooling) Condensing temperature is controlled by the outdoor heat exchanger coil temperature as sensed by sensor C2. OUTDOOR UNIT COIL TEMP. C2 (°C) OUTDOOR FAN FORCED SPEED H, M H, M ELECTRONIC REF. CONTROL VALVE OPEN 0436_M_S...

  • Page 32: Overload Protection (Heating)

    2. Processes and functions 2-7 Overload Protection (Heating) This function prevents the air conditioner from overloading. (°C) INDOOR UNIT COIL TEMP. (E2) OVERLOAD PROTECTION OVERLOAD PROTECTION FUZZY CONTROL FUZZY CONTROL ELECTRONIC REF. CONTROL VALVE OPEN OPEN START UP OUTDOOR FM COMPENSATION H OR M H OR M...

  • Page 33: Discharge Temperature Control (Cooling And Heating)

    2. Processes and functions 2-8 Discharge Temperature Control (Cooling and Heating) This function prevents the compressor motor from burnout by overheating. (135) 115 (125) 105 (115) 95 (113) 93 DISCHARGE GAS TEMP. (°C) (110) 90 (105) 85 THE TEMPERATURES IN THE PARENTHESIS IS FOR 48 TYPE.
  • Page 34 2. Processes and functions 2-9 Auto. Mode for Automatic Heating/Cooling Switching COOLING SELECTION TEMP. +2.5 deg SHIFT SET TEMP. +2 deg REMOTE CONTROLLED SET TEMP. SHIFT SET TEMP. –2 deg HEATING SELECTION TEMP. –3 deg HEATING COOLING HEATING 0440_M_S Fig. 12 Chart summary and Explanations This chart shows how the Operation Mode (COOLING or HEATING) is determined by the microprocessor taking the room temperature into consideration.

  • Page 35: Defrosting Control, Outdoor Heat Exchanger Coil (Heating)

    2. Processes and functions 2-10 Defrosting Control, Outdoor Heat Exchanger Coil (Heating) When the outdoor temperature is low, frost may form on the outdoor heat exchanger coil. When this occurred, the defrosting system operates. The microprocessor in the outdoor unit monitors the relationship between the temperature of the outdoor heat exchanger coil and the outdoor temperature so it can defrost when necessary.

  • Page 36: 4-Way Valve, Solenoid Control

    2. Processes and functions 2-11 4-Way Valve, Solenoid Control The basic function of the 4-way valve is to direct the refrigerant in the correct direction according to the Operation Mode (COOLING or HEATING) selected. The following two charts show conditions of the controls and functions listed in the left hand column when the solenoid is ON or OFF.

  • Page 37: (B) Auto Control Mode

    2. Processes and functions (B) AUTO Control Mode POWER SOURCE OPERATION BUTTON MORE THAN 10 MINUTES MORE THAN 10 MINUTES (THERMO. OFF) (THERMO. OFF) AUTO COOL COOL MODE CONTROL HEAT HEAT HEAT THERMO. OFF THERMO. ON 3 MINUTES MORE THAN 3 MINUTES COMPRESSOR MORE THAN...

  • Page 38: Electronic Refrigerant Control Valve

    2. Processes and functions 2-13 Electronic Refrigerant Control Valve This valve allows very precise and smooth control of the amount of refrigerant flow in the system. Since the valve is operated by a step motor, the control circuits can open or close it in very exact amounts, so the degree of heating or cooling can be changed by just a little, or changed very quickly or slowly.

  • Page 39: Compressor Current Detection Circuit

    2. Processes and functions 2-15 Compressor Current Detection Circuit The Compressor Current Detection Circuit detects the compressor current and, depending on the current range, can stop the compressor motor so it will not be damaged by overcurrent. Overcurrent can be caused by several factors, particularly mechanical seizing of the compressor or liquid backflow.

  • Page 40: Dehumidifying Operation

    2. Processes and functions 2-16 Dehumidifying Operation Dehumidifying operation uses the cooling cycle to remove moisture from the air, but by running an indoor fan at a low speed, to dehumidify without greatly lowering room temperature. In this mode, the microprocessor automatically controls the ON-OFF operation between +2 deg.

  • Page 41: Auto-Flap Control

    2. Processes and functions 2-17 Auto-flap Control Auto flap can control the air flow in 5 steps. Auto-flap 20° 40° F4 F5 0450_M_S Fig. 21 Flap position Operation mode Automatic setting Optional setting Cooling/dehumidifying F1 • F2 • F3 • Swing F1 •...

  • Page 42: Electronic Refrigerant Control Valve Control

    2. Processes and functions 2-19 Electronic Refrigerant Control Valve Control The circulation volume of the refrigerant is controlled by a pulse type electronic control valve. When the power is switched ON, the opening degree of the electronic control valve is controlled between 90 and 480 steps after setting the initial step at the time when the thermostat is ON.

  • Page 43: Voltage Detection Control

    2. Processes and functions 2-20 Voltage Detection Control When the power voltage falls below 160 V (voltage between N phase and each phase) or rises above 260 V, the “P2” alarm is issued to protect the compressor and electrical components. SM830033 –...

  • Page 44: Electrical Data

    3. Electrical data 3. ELECTRICAL DATA Indoor Unit (Electric Wiring Diagram, Schematic Diagram) ....... 46 Outdoor Unit (Electric Wiring Diagram, Schematic Diagram)......48 SM830033 – 45 –...

  • Page 45: Indoor Unit (Electric Wiring Diagram, Schematic Diagram)

    3. Electrical data Indoor Unit 1 1 1 1 1 SPW-X253GH56, SPW-X363GH56, SPW-X483GH56 SM830033 – 46 –...
  • Page 46 3. Electrical data Indoor Unit 1 1 1 1 1 SPW-X253GH56, SPW-X363GH56, SPW-X483GH56 • Schematic Diagram CR-X253GH Controller 8P-R1 F1(5A) 8P-1(L) 8P-R2 RC12V 8P-R3 230V 8P-2(N) 49FI Room Thermistor Indoor Coil Indoor Coil DP.DPH Indoor Coil DC12V To Outdoor Unit...

  • Page 47: Outdoor Unit (Electric Wiring Diagram, Schematic Diagram)

    3. Electrical data 3-2 Outdoor Unit 1 1 1 1 1 SPW-C253GH5 SM830033 – 48 –...
  • Page 48 3. Electrical data 3-2 Outdoor Unit 1 1 1 1 1 SPW-C253GH5 • Schematic Diagram Terminal CR-C253GH5 Plate (6P) Controller 63PH 2P-1 2P-2 L1 F1(3.15A) 63PH AC 230V AC 14V 49FO Outdoor Coil C1 Outdoor Coil C2 Discharge DC12V Symbols Description Symbols Description...
  • Page 49 3. Electrical data 3-2 Outdoor Unit 2 2 2 2 2 SPW-C253GH8 SM830033 – 50 –...
  • Page 50 3. Electrical data 3-2 Outdoor Unit 2 2 2 2 2 SPW-C253GH8 • Schematic Diagram Terminal CR-C253GH Plate (8P) Controller 63PH 2P-1 2P-2 L1 F1(3.15A) 63PH AC 230V 49FO AC 14V Outdoor Coil C1 Outdoor Coil C2 Discharge DC12V N L3 L2 F2(3.15A) L3 N Symbols...
  • Page 51 3. Electrical data 3-2 Outdoor Unit 3 3 3 3 3 SPW-C363GH8 SM830033 – 52 –...
  • Page 52 3. Electrical data 3-2 Outdoor Unit 3 3 3 3 3 SPW-C363GH8 • Schematic Diagram Terminal CR-C253GH Plate (8P) Controller 63PH 2P-1 2P-2 L1 F1(3.15A) 63PH AC 230V 49FO1 AC 14V Outdoor Coil C1 49FO2 Outdoor Coil C2 FMO1 FMO2 Discharge DC12V N L3 L2...
  • Page 53 3. Electrical data 3-2 Outdoor Unit 4 4 4 4 4 SPW-C483GH8 SM830033 – 54 –...
  • Page 54 3. Electrical data 3-2 Outdoor Unit 4 4 4 4 4 SPW-C483GH8 • Schematic Diagram Terminal CR-C253GH Plate (8P) Controller 63PH 2P-1 2P-2 L1 F1(3.15A) 63PH AC 230V 49FO1 AC 14V Outdoor Coil C1 49FO2 Outdoor Coil C2 FMO1 FMO2 Discharge DC12V N L3 L2...
  • Page 55 3. Electrical data SM830033 – 56 –...

  • Page 56: Service Procedures

    4. Service procedures 4. SERVICE PROCEDURES Troubleshooting .....................58 (1) Check before and after Troubleshooting ..........59 (2) General Troubleshooting Flow Chart: Diagnosis and Remedy ....61 (3) Meanings of alarm messages ..............63 (4) LED Indication on the Outdoor Unit’s P.C.B. Ass’y ........ 65 (5) Symptoms and parts to inspect ..............

  • Page 57: Troubleshooting

    4. Service procedures 4-1 Troubleshooting This section explains: What the LED codes mean What the remote control unit display screen messages mean How to use the flow charts to find and solve problems How to use the self-diagnostic tests to find parts that aren’t working right This unit is made to be trouble free, and not need much service.

  • Page 58: Check Before And After Troubleshooting

    4. Service procedures (1)-1 Check before and after Troubleshooting (SPW-C253GH5) Many problems may happen because of wiring or power supply problems, so you should check these areas first. Problems here can cause false results in some of the other tests, and so should be corrected first.
  • Page 59 4. Service procedures (1)-2 Check before and after Troubleshooting (SPW-C253GH8, C363GH8, C483GH8) Many problems may happen because of wiring or power supply problems, so you should check these areas first. Problems here can cause false results in some of the other tests, and so should be corrected first.

  • Page 60: General Troubleshooting Flow Chart: Diagnosis And Remedy

    4. Service procedures (2) General Troubleshooting Flow Chart: Diagnosis and Remedy When you have found a major problem, such as refrigerant not flowing in the system or reduced air circulation, come to this section and find the box listing the problem. Connected to the box are the main causes of the problem and their remedies.
  • Page 61 4. Service procedures (B) Heating b. Heating Poor heating Is setting temp. Change the setting temp. suitable ? Is heating load Review heating load too large ? estimate. Refrigerant flow 4-way valve is Replace the valve. failure defective. Refrigerant Charge with shortage refrigerant.

  • Page 62: Meanings Of Alarm Messages

    4. Service procedures Meanings of alarm messages If an error occurred in the air conditioner, the error condition is presented by indicating the error code in the wired remote controller display or by the combination of lamp statuses for operation, timer and heat stand-by (OFF status and flashing status). Wired remote Wireless remote Possible causes of troubles...
  • Page 63 4. Service procedures Wired remote Wireless remote Possible causes of troubles controller controller display display Operation lamp Indoor thermistor is either Indoor coil temp. (E1 = TH2) cannot be detected. and heat stand-by open or short. Indoor coil temp. (E2 = TH3) cannot be detected. lamp flash Indoor room temperature cannot be detected.

  • Page 64: Led Indication On The Outdoor Unit's P.c.b. Ass'y

    4. Service procedures (4) LED Indication on the Outdoor Unit’s P.C.B. Ass’y If something goes wrong with the outdoor unit, LED lamps on the outdoor P.C.B. Ass’y light up to show the cause of the trouble, in addition to the Alarm message on the remote controller.

  • Page 65: Symptoms And Parts To Inspect

    4. Service procedures Symptoms and parts to inspect Symptom: LCD on the remote controller does not display and remote controller does not operate. Start Is the LED (D80) on the indoor unit PCB lit? Is there 12 V DC Is there 12 V DC Repair the between R2 and R3 between 2 and 3...
  • Page 66 4. Service procedures 2) Symptom: LCD on the remote controller displays “CHECK E01”. (Unusual communication between remote controller and indoor unit.) Start Remote controller judges itself Replace the remote controller. with self-diagnostic functions Is there an open or a contact defect in the No.
  • Page 67 4. Service procedures Symptom: LCD on the remote controller is displaying “CHECK E04”. (Unusual communication between the indoor and outdoor units.) Start Cut the breaker and remove the Is the contact good at the 2P Correct the connections. indoor/outdoor unit control lines connector for indoor serial connected to U1 and U2 of the communications on the outdoor...
  • Page 68 4. Service procedures Symptom: LCD on the remote controller is displaying “CHECK E06”. (Unusual communication between the indoor and outdoor units) Start Correct the setting. Is the setting for the indoor address on the indoor unit PCB inappropriate? Is there a cut line or contact Correct wiring.
  • Page 69 4. Service procedures Symptom: LCD on the remote controller displays “CHECK P01”. (Indoor fan protection thermostat operation warning) Start Is there 220-240 V AC between S4 and T20-3 on the indoor unit PCB? Correct the connection Is there 220-240 V AC between Is the indoor fan wire winding T20-3 and S4 after T20-1 and T20-3 protection thermostat (49FI) off?
  • Page 70 4. Service procedures 11) Symptom: LCD on the remote controller displays “CHECK P02”. (Compressor / outdoor fan protection thermostat operation warning / power supply voltage abnormality) Start Is the power supply to the outdoor Check the power breaker etc. unit normal? and repair.
  • Page 71 4. Service procedures 12) Symptoms: LCD on the remote controller displays “CHECK P03”. (Alarm for unusual discharge temp. of compressor) Start Unusual discharge gas temperature • Refrigerant shortage • Clogged refrigerant circuit • Electronic refrigerant control valve defect (indoor unit) 0343_M_I 13) Symptom: LCD on the remote controller displays “CHECK P04”.
  • Page 72 4. Service procedures 14) Symptom: LCD on the remote controller displays “CHECK P05”. (Negative phase detection operation warning) Start Is the power supply to the outdoor Check the power breaker etc. unit normal? and repair (Voltage defective phase?) Does the outdoor unit operate when No problem two of the three phases are changed? (Actuation of negative phase protector)
  • Page 73 4. Service procedures 16) Symptom: LCD on the remote controller displays “CHECK E16”. Start When the group of the units are Repair the wiring. installed, is there any mis-cross between inter unit control wiring and refrigerant tubing? Are the total capacities of indoor units Select indoor units which match with to that of outdoor units more than 107%? the outdoor capacity.
  • Page 74 4. Service procedures 19) Symptom: LCD on the remote controller displays “CHECK H01, H02, H03”. (PC compressor current detection) * Please check the related part described in the following chart after confirming the code setting (S4) of the outdoor unit’s capacity on the PCB in the outdoor unit. Start “CHECK H01”...

  • Page 75: Procedures When A Specific Component Does Not Work

    4. Service procedures Procedures When a Specific Component Does Not Work Indoor fan does not operate. Is fan motor capacitor Replace the capacitor. normal ? Is there voltage output Replace the P.C.B. Ass'y of P.C.B. Ass'y for fan in the indoor unit. motor ? •...
  • Page 76 4. Service procedures Compressor motor does not operate. Does compressor motor magnetic Replace the compressor contactor (52C) actuate ? motor magnetic contactor. Check resistance of compressor motor winding. Replace the compressor. 0461_M_I Outdoor fan does not operate. Are auxiliary relays (1Y, 2Y) Replace the relays.

  • Page 77: Service Functions Of Remote Controller

    4. Service procedures Service Functions of Remote Controller From the remote controller you can control both the operation and settings of the unit as well as perform several useful service checks. This section explains how to use the remote controller on the following items from (A) to (J). (A) Set service check switches.
  • Page 78 4. Service procedures (B) Use the test run procedure The purpose of the test run function is to let you control the operation of the unit directly without turning the unit on or off by thermostat. As indicated in the following procedure, be sure to stop test run operation when you finish the procedure, or the air conditioner may be damaged.
  • Page 79 4. Service procedures (C) Check the sensor temperature readings The air conditioner has thermo sensors which are used to control the unit. Each sensor has an address which is made up of the indoor unit address, and the sensor address. The indoor unit address is used only when several units are hooked up to one remote controller (group control).
  • Page 80 4. Service procedures Refer to the table below for the relationship between the sensor address and the location of the sensor. Relationship between the sensor address and the location of sensor Sensor Address Location of Sensor (Themistor) (CODE No.) Indoor Unit —...
  • Page 81 4. Service procedures This picture shows the service check display. UNIT No. UNIT No. 1–1 R.C. CODE Refrigerant Circuit No. CODE No. CHECK Alarm message SERVICE 0358_M_I c. A maximum of 4 alarm messages can be accessed by pressing either SET TEMP button as follows.
  • Page 82 4. Service procedures Important Never press CL (clear) button unless you want to erase the accessed data in memory. Follow the procedure below only when erasing is necessary. To erase accessed data, press the CL button. When erasing is finished,“----” mark appears on the controller’s display. CAUTION After checking the alarm messages, be sure to press the TEST / CHK button.
  • Page 83 4. Service procedures (F) Execute the auto. address operation Auto. address operation is executed by pressing the A. ADD (S1) button of outdoor unit’s PCB usually. For your convenience it can be executed by remote controller also. a Press the TEST / CHK and ) buttons at the same time for more than 4 seconds.
  • Page 84 4. Service procedures (G) Confirm and change the indoor unit address The purpose of the above function is to let you confirm the indoor unit address after the auto. address operation, and change the indoor unit address if it is needed.
  • Page 85 4. Service procedures e Set the required new indoor unit’s No. by pressing the ) button. AIR FLOW UNIT MODE Ex: UNIT No. 3-6: currently registered indoor unit address R.C. FLAP SET TEMP. CODE TIMER SET FAN SPEED SETTING DATA Required new indoor No.8: SET DATA In this case, UNIT No.
  • Page 86 4. Service procedures (H) Change the shift temperature in heating mode If the indoor unit is installed at high location (ex. ceiling level), the thermostat tends to turn off at heating mode because of the hot air temperature around ceiling level. In order to solve the problem, the shift temp.
  • Page 87 4. Service procedures ( I ) Set the indoor unit address This function is usable if the auto. address operation is not available. Indoor unit address can be set one by one by remote controller in such case. NOTE 1) In case of group control, branch wiring for group control should be removed temporarily.
  • Page 88 4. Service procedures d Set the No. of R. C. which you want to set with ) button. Ex. No. of R. C. will be set 2. AIR FLOW UNIT MODE UNIT No. R.C. FLAP SET TEMP. CODE TIMER SET FAN SPEED SETTING DATA...
  • Page 89 4. Service procedures i Select the code No. 14 to set group setting with the (SET TEMP) button. j Set the No. of group setting as shown below with the ) button. Nos. of group setting. AIR FLOW 0 : Standard system (except group UNIT MODE UNIT No.
  • Page 90 4. Service procedures (J) Change the period of the filter timer If the period of filter timer is not suitable (for example in case of dirty environment), the period can be shortened to half as follows: a Press the TEST / CHK button for more than 4 seconds. AIR FLOW UNIT MODE...

  • Page 91: Checking The Electrical Components

    4. Service procedures 4-2 Checking the Electrical Components Measurement of Insulation Resistance • The insulation is in good condition if the resistance exceeds 1 MΩ. Power Supply Wires Clamp the earthed wire of the Power Supply wires with a lead clip of the insulation resis- Earthed wire tance tester and measure the resistance by placing a probe on either of the power wires.
  • Page 92 4. Service procedures Measurement of Insulation Resistance for Electrical parts Probe • Disconnect the connector of the desired electric part from terminal plate, P.C.B. Ass’y, etc. (Fig. 42) • Similary, disconnect the lead wires from Clip compressor, capacitor, etc. (Fig. 43) Copper tube or •...

  • Page 93: Checking The Protective Devices

    4. Service procedures Checking the Protective Devices • Disconnect the connector, which consists of P (plug) and S (socket) when you want to check the protective device. • Then check continuity among plug’s (and/or socket’s) terminal as in Fig. 44. •...

  • Page 94: Checking The Electrical Parts

    4. Service procedures Checking the Electrical Parts Power transformer (TR1) ....Indoor unit *Measure the coil resistance. • Primary ; Measure the resistance between No.1 and No.3 (WHT lead wires) terminals of 3P (WHT) socket connected to power transformer. • Secondary 14V ;...
  • Page 95 4. Service procedures Solenoid coil of the electronic refrigerant *Measure the coil resistance. control valve (ERCV) ………… Indoor unit • Measure the resistance between No. 5 (GRY lead wire) and other terminals (another color of lead wires) of 5P (WHT) plug connected to the solenoid coil. Refer to “1-2-(A) Major component specifications”.
  • Page 96 4. Service procedures Fuse on indoor and outdoor P.C.B. Ass’y …. Both in indoor and outdoor unit *Check the continuity. • Remove the P.C.B. Ass’y from the electrical component box. Then pull out the fuse from the P.C.B. Ass’y. (Fig. 46) Fuses Fuses Indoor P.C.B.

  • Page 97: Sensor And Solenoid Layout Diagram

    4. Service procedures Sensor and Solenoid Layout Diagram Indoor Unit • SPW-X363GH56 • SPW-X253GH56 • SPW-X483GH56 Electronic refrigerant control valve (ERCV) Electronic refrigerant control valve (ERCV) (E1), (RED) TH3 (E2), (BLK) TH3 (E2), (BLK) TH2 (E1), (RED) (E3), (BRN) TH4 (E3), (BRN)
  • Page 98 4. Service procedures • SPW-C363GH8 TH6, 7, 8 TH7 (C2), (RED) 63PH TH8 (GRN) ( Discharge gas) TH6 (C1), (BLK) 0585_C_S 0584_C_S • SPW-C483GH8 TH6, 7, 8 TH7 (C2), (RED) 63PH TH8 (GRN) ( Discharge gas) TH6 (C1), (BLK) 0585_C_S 0586_C_S SM830033 –...

  • Page 99: Thermistor Characteristic Curve

    4. Service procedures (5) Thermistor Characteristic Curve (1) Room temp. sensor : TH1 (KTEC-35) (2) Indoor heat exch. coil sensor : TH2(E1), TH3(E2), TH4(E3) Outdoor heat exch. coil sensor : TH6(C1), TH7(C2) ( PBC-41E) ( PB3M-41E) –20 –15 –10 –5 Temperature (°C) 0375_M_I Temperature (°C)

  • Page 100: Pcb Setting

    4. Service procedures (6) PCB Setting Setting of outdoor control PCB (A) Standard control (single outdoor unit) In case of single outdoor unit installation, no indoor unit’s setting is necessary for twin, triple or quartet types (2, 3 or 4 indoor units).

  • Page 101: Address Setting Method

    4. Service procedures (7) R.C. Address Setting Method Outdoor unit R.C. address setting method In case of group control or central control, set the R.C. address to 1, 2, 3, ... according to the No. of outdoor units. Outdoor control PCB CN4 (2P Black) Refrigerant circuit address (factory setting = 0)

  • Page 102: Automatic Address Setting Method

    4. Service procedures (8) Automatic Address Setting Method Displaying Indoor / Outdoor Unit Combination Numbers — For group control and central control with multiple outdoor units — Display the indoor / outdoor unit address after automatic address setting. Carry out automatic address setting with 1) When installing multiple units, match the remote controller.

  • Page 103: Items To Check Prior To Test Run

    4. Service procedures (10) Items to Check Prior to Test Run 1) Turn on the power supply switch more than 5 hours before in order to charge the crank case heater. 2) Fully open the outdoor service valve after making the leak inspection of field connected tubing, vacuuming, and gas charging if necessary.

  • Page 104: Test Run Procedure

    4. Service procedures (11) Test Run Procedure Start Turn on RCU address SW Multiple remote of sub remote control unit control? Recheck the test items before test operation. (See 4-2-(10)) Check the indoor and outdoor unit combination (wiring). Single type? Multiple indoor (One indoor unit and one units for one outdoor...
  • Page 105 4. Service procedures SM830033 – 106 –...

This manual is also suitable for:
