3
Panel Status & User Level 1 Functions

3.1 Status Normal

The following control keys function at user access Level 1:
- MUTE BUZZER
- CHANGE TABS
.
With the panel at user access Level 1 and also in the quiescent state,
i.e. the panel status is normal, the following indications are present:
- LCD. This displays the 'Status Normal' screen - no user menus
are shown but the panel name or authorised servicing company
information/logo is displayed.
- POWER LED (green). This is lit continuously when the panel is
powered.
No other front panel LEDs are lit and the internal buzzer is silent.

3.2 Panel Controls and Menus

No control functions or menus are available to the user at access
Level 1, except the
key to display the user level passcode entry
screen. To enable the panel control keys and gain access to the user
level menus requires entry of a valid Level 2 passcode or to insert
and turn the key (clockwise) in the keyswitch.
Refer to Section 4 Enabling user Access (Level 2) for more details.
Access to the commissioning menus requires the entry of a
commissioning engineer's passcode - details of this function are
not provided in this document.
997-670-000-2
www.notifierknowledge.com
Panel Status & User Level 1 Functions
Operating Manual
Section 3 - 1
