5 - 2 LI2208 Product Reference Guide

Connecting to an IBM 468X/469X Host

This connection is made directly from the linear imager to the host interface.
IBM Direct Connection
Figure 5-1
To connect the IBM 46XX interface:
Attach the modular connector of the IBM 46XX interface cable to the host port on the bottom of the linear
1.
imager.
Connect the other end of the IBM 46XX interface cable to the appropriate port on the host.
2.
Select the port address by scanning the appropriate bar code from
3.
IMPORTANT
To modify any other parameter options, scan the appropriate bar codes in this chapter.
4.
NOTE The only required configuration is the port number. Other linear imager parameters are typically
The Auto-Host Detect Cable feature automatically detects the host interface type, but
there is no default setting. Scan one of the bar codes below to select the appropriate
port.
controlled by the IBM system.
Port Address on page 5-4.
