UBI EasyCoder 601 E – User's Manual
PRINTHEAD CLEANING
Cleaning of the printhead on a regular basis, preferably in
connection with each ribbon or paper reload, is important for the
life of the printhead and for the printout quality. Below is a
description on how to clean the printhead by means of Cleaning
Cards. If additional cleaning is required, e.g. for removing
adhesive residue from the print roller or dispenser edge, use a
cotton swab moistened with isopropyl alcohol.
Caution:
Isopropyl alcohol [(CH ) CHOH; CAS 67-63-0] is a highly
3 2
flammable, moderately toxic and mildly irritating substance.
1
2
Fold the locking handle downward/outward (1).
Open the front and right-hand doors. Then turn the printhead lift knob to "Load" position (2)
3 4
Open the Cleaning Card pouch. The cleaning card
contains isopropyl alcohol, see "Caution" above.
Remove the transfer ribbon and paper supplies.
19
