Cleaning the Printhead

In order for the printhead to provide good print quality, it must maintain close contact with the
media. Therefore, cleaning media debris from the printhead is very important. You should clean
the printhead after every roll, or 6,000 inches (152m), of media have been printed. Clean more often
if necessary.
Caution
Do not use sharp objects such as knives or screwdrivers to scrape the printhead
clean. Cleaning with sharp objects will damage the printhead. Clean with only a
cotton swab, a clean, lint-free cloth, or a tissue damp with isopropyl alcohol.
Conseil
N'utilisez pas d'objets pointus tels que couteaux ou tournevis pour nettoyer la tête
d'imprimante. Nettoyer avec des objets pointus endommagera la tête d'imprimante.
Nettoyez-la seulement avec de la ouate ou avec un linge propre et libre de peluches,
humecté avec de l'alcool d'isopropyl.
1
O
3440G.044
Turn the on/off switch to the off (O) position and
remove the power cord.
3
3440G.038
Rotate the head lift lever clockwise to release the printhead.
This raises the printhead so that you can clean it.
22
2
3440G.006
Remove the media cover.
4
rm e rm e
c c
3440G.045
Remove the media and ribbon if necessary.

Connecting the Printer to a Power Supply

1
O
3440G.003
Turn the On/Off (|/O) switch on the back of the
printer to the off (O) position.
3
O
3440G.005
Plug the AC power cord into the receptacle at the rear of the
printer.
When you power on the printer, the green LED on the front panel lights, the yellow and orange LEDs flash,
and the platen roller advances. The yellow LED then stays on until you load media.
2
I O
I O
O
3440G.004
Make sure the DIP switches are set to their default settings.
Set switch 1 on (|). Set switches 2
Top Bank
through 8 off (O).
Bottom Bank Set switches 1 through 8 off.
5
4
3440G.007
Turn the On/Off switch to
the on (|) position.
Plug the other end of the
power cord into a
grounded wall outlet or
surge protector.
