Customer:
Address:
By:
Serial No of the oven:
1. Connection:
Water connection – dirt filter (may need tightening)
Electrical connection (may need tightening)
Drain connection (may need tightening)
Positioning of oven
2. Door:
Closing device (may need adjusting)
Catch (may need adjusting)
Sealing (must be tight at 100°C steam or combi steam)
Hinging (may need adjusting)
Interior glass (hinging, fastening)
Calibrate door sensor
3. Inside:
Interior light
Jets (may need cleaning)
Fan (should rotate freely and be tightly fitted)
Heating element (may need tightening)
4. Under oven:
Drain system (check for leaks and blocks)
Condensation jet and drain sensor
Drip tray (clean hose for discharge connection piece)
Drip slide on oven door
5. Motor room:
Connection to heating elements
Load distribution on phases
Wire connection (overloading, bad connection, and tightening)
Exhaust motor
Fan motor (may need tightening)
Frequency transformer (check regulation)
ClimaOptima
Cooling fan
Filter for intake (may need cleaning)
Cooling plate for solid-state relays (clean)
Check for moisture

Annual Service Check

Postal code:
Model:
- 12 -
Functioning correctly YES NO
