Access to the oven:
Recommended distance for service and for installation near other heat-
generating appliances (all oven sizes).
Left side minimum
Rear side minimum
Right side minimum
Drain connection:
Heat-resistant drain tube connected.
Fall of at least 3º or 5%.
CombiPlus fitted with open drain for both ovens.
The drain must never end directly under the oven.
Voltage and water supply:
(Please insert the measured value)
Voltage measured at:
Water pressure measured at: (min. 2 bar/28,5 psi max. 6 bar/88
psi).
Does the voltage on site comply with the voltage stated on the
approval plate?
Dirt filter fitted.
Function test:
All electrical connections are tight.
All water connections are tight and have been fastened.
All functions are operable.
All equipment is operable.
All ovens
50 mm (2")
50 mm (2")
400 mm (15")
- 32 -
Distance measured in mm
Yes No
Yes No
Yes No
