6. Steam generator:
Heating elements (check for leaks)
Load distribution on phases
Level sensor – to be cleaned
Drain pump
May need descaling
7. Functional test:
Components (use test function)
Core temperature probe
Operation modes
CombiWash (clean jet head)
Service engineer: Date and signature
Parts to be replaced at 12-, 24- and 36-month service intervals:
12-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Bearing for nozzle arm
Update software
Functioning correctly
24-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Main contactor
Spring for handle
Bearing for nozzle arm
Update software
- 13 -
YES NO
36-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Exhaust for damper motor
Detergent and rinse pump
Nozzle arm assy
Update software
