We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT:
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
W10203509A
INSTALLATION INSTRUCTIONS
24" (61.0 CM) GAS SINGLE
AND DOUBLE BUILT-IN OVEN
Table of Contents
BUILT-IN OVEN SAFETY ................................ 1
INSTALLATION REQUIREMENTS ................. 3
Tools and Parts ............................................. 3
Location Requirements................................. 3
Electrical Requirements ................................ 4
Gas Supply Requirements ............................ 5
INSTALLATION INSTRUCTIONS ................... 6
Prepare Built-In Oven.................................... 6
Make Gas Connection .................................. 6
Install Oven.................................................... 7
Complete Installation .................................... 8
GAS CONVERSIONS ....................................... 9
LP Gas Conversion ....................................... 9
Natural Gas Conversion.............................. 10
BUILT-IN OVEN SAFETY
Your safety and the safety of others are very important.
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool Gas Single And Double Built-In Oven
Summary of Contents for Whirlpool Gas Single And Double Built-In Oven
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS 24" (61.0 CM) GAS SINGLE AND DOUBLE BUILT-IN OVEN Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. - Page 2 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Tools needed Tape measure Marker or pencil Phillips screwdriver Pipe-joint compound resistant to LP gas Flat-blade screwdriver "... -
Page 4: Electrical Requirements
Product Dimensions - Double Oven A. 22 " (56.8 cm) max. recessed width B. 46 " (117.6 cm) max. overall height C. 23 " (60.6 cm) overall width D. 22 " (57.5 cm) max. recessed depth E. 44 " (113.4 cm) recessed height Cabinet Dimensions - Double Oven Double Oven Installed in Cabinet "... -
Page 5: Gas Supply Requirements
A 120 volt, 60 Hz., AC only, 15-amp fused, electrical circuit is required. A time-delay fuse or circuit breaker is also recommended. It is recommended that a separate circuit serving only this oven be provided. Electronic ignition systems operate within wide voltage limits, but proper grounding and polarity are necessary. -
Page 6: Installation Instructions
Gas Pressure Regulator The gas pressure regulator supplied with this oven must be used. The inlet pressure to the regulator should be as follows for proper operation: Natural gas: Minimum pressure: 5" WCP Maximum pressure: 14" WCP LP gas: Minimum pressure: 11" WCP Maximum pressure: 14"... -
Page 7: Install Oven
3. Use a " combination wrench and an adjustable wrench to attach the flexible connector to the adapters. Check that connector is not kinked. A. Gas pressure regulator E. Manual gas shutoff valve B. Use pipe-joint compound. F. ½" or ¾" gas pipe C. -
Page 8: Complete Installation
3. Securely fasten oven to cabinet using the 0.188 x 2.1" screws (4 for single oven, 6 for double oven) provided. Insert the screws through holes in decorative trim. To avoid cabinet damage, use the 0.140" diameter (number 28) drill bit to pre- drill the pilot holes before driving screws. -
Page 9: Gas Conversions
Gas conversions from Natural gas to LP gas or from LP gas to Natural gas must be done by a qualified installer. WARNING Explosion Hazard Use a new CSA International approved gas supply line. Install a shut-off valve. Securely tighten all gas connections. If connected to LP, have a qualified person make sure gas pressure does not exceed 14"... -
Page 10: Natural Gas Conversion
3. Flip the regulator pin over and snap pin firmly into place. A. Natural gas position B. LP gas position 4. Screw the hex-shaped regulator cap securely back into place. Do not overtighten. To Convert Bake/Broiler Burner 1. Remove racks from inside the broiler cavity. 2. - Page 11 2. Unscrew the hex-shaped regulator cap from the regulator and remove the regulator pin. A. Regulator pin B. Regulator cap 3. Flip the regulator pin over and snap pin firmly into place. A. LP gas position B. Natural gas position 4.
- Page 12 W10203509A © 2008. Whirlpool Corporation. 7/08 All rights reserved. Printed in U.S.A.
