Electrical connection/survey of supply lines

The electrical connection must be carried out by an authorised electrician in accordance with
existing rules and regulations.
The wiring diagram is located in the motor compartment.
The terminal for the electrical connection is located behind the right side plate.
An approved plug outlet or a safety cutout must be located close to the oven so that
the oven can be disconnected during installation and repair. The safety cutout must be
able to cut off all poles with a total distance of break of at least 3 mm. Each of the two
units in a stacked arrangement (CombiPlus) must have its own plug outlet or safety cut-
out.
The warranty does not cover incorrect connection.
Supply lines - survey (applies to all electric models )
(All cross sections in mm² )
375,
AFO ----
388
9 kW
400V 3N ~ 50/60
5x2,5
Hz
400V 3 ~ 50/60
4x2,5
Hz
415V 3N ~ 50/60
5x2,5
Hz
440V 3 ~ 50/60
4x2,5
Hz
200V 3 ~ 50/60
4x4
Hz
230V 3 ~ 50/60
4x4
Hz
480V 3 ~ 50/60
4x2,5
Hz
208V 3 ~ 50/60
4x4
Hz
* Not possible
Recommended supply line: H07RN-F
When you connect the oven, you should
• Follow the installation instructions and the information given on the rating plate.
• Comply with local rules and regulations.
• WHIRLPOOL recommends the use of a (Type B) RCD/RCCB. 300 mA
Installation and Connection
376, 376,
377, 377,
378, 378,
389, 389,
375, 379,
390, 390,
388 392
391 391
Fuse 18 kW Fuse 24 kW
16A 5x4 35A 5x10
16A 4x4 35A 4x10
16A 5x4 25A 5x10
16A 4x4 25A 4x10
35A 4x16 63A 4x25
25A 4x10 50A 4x25
16A 4x4 25A
25A 4x10 50A 4x25
379, 380, 380,
392 393 393
Fuse 36 kW Fuse
50A 5x10 63A
50A 4x10 63A
50A 5x10 50A
50A 4x10 50A
100A 4x35 125A
80A 4x35 100A
4x6 35A 4x10 50A
80A 4x35 100A
- 9 -
382, 382,
395 395
383, 383, 384,
396 396 397
27 kW Fuse 60 kW
5x10 50A 5x25
4x10 50A *
5x10 50A 5x25
4x6 35A *
4x25 80A *
4x25 80A *
4x6 35A *
4x25 80A *
384,
397
Fuse
100A
*
100A
*
*
*
*
*
