Whirlpool Light programmable oven Service & Installation Manual page 30

Error code 3: GENRA HOT
Error code 4: OVEN HOT
Error code 5: FAN HOT
Error code 6: DRAIN > 75
Error code 7: OVEN SENS
Error code 8: PROBE SENS
Error code 9: GENER SENS
Error code 10: DRAIN SENS
Error code 11: WATER SHOR
Error code 12: SSR HOT
Error code 13: GENER > 130
Error code 14: FAN SPEED
Error code 15: CPU HOT
Error code 16: IO BRD HOT
Error code 18: DATA ERROR
Error code 19: WRONG LANG
Error code 20: NO COM IO
Error code 22: NO RESTART
Error code 23: OVEN WARM
Error code 24: DRAIN ERR
Error code 25: PROBE ERR
Error code 28: ALARM ERR
Error code 29: DOOR SENS
Error code 34: WATER PRES
Error code 40: IO BRD HOT
Error code 43: WRONG SW
Error code 44: DAMPER ERR
Error code 45: 24 V ERROR
Error codes
Generator too hot (Generator thermoswitch has tripped. Reconnect
by pressing button under oven.)
Oven too hot (Oven chamber thermoswitch has tripped. Reconnect
by pressing button under oven.)
Fan too hot (Thermoswitch in motor has tripped. Wait for 10
minutes and try again.
Drain too hot (Drain temperature has been above 75°C for more
than 5 min. Check that jet in drain is working.)
Oven sensor defective (Temperature sensor in oven chamber not
working properly.)
Core temp. probe not connected (A program using core temp.
probe has been selected but probe has not been connected.)
Generator sensor defective (Temperature sensor in generator not
working.)
Drain sensor defective (Sensor in drain not working. Oven can still
be used.)
Water shortage (Steam generator was not filled within two minutes.
Check that the water has been turned on.)
SSR too hot (Solid-state relay too hot.)
Generator too hot (Temperature in steam generator higher than
130°C. If fault recurs, descale generator)
Fan running too slow
CPU board too hot (> 60°C)
IO board too hot (> 60°C)
Error in set-up data
Wrong language
Internal defect (Failure in communication between computer and IO
board.)
Restart not possible (Oven has been without power too long.)
Oven too hot at CombiWash start-up
Draining failure (Drain blocked or failure of drain pump. Water level
in generator still high after 10 seconds of draining.)
Core temperature probe defective (1, 2 or 3 of the elements in
the core temperature probe defective.)
Configuration error in main alarms (3, 4, 5, 12) (warning)
Wrong door sensor signal (warning)
Water pressure too low (Check that water is turned on.)
Temperature in IO board critical (Warning after program run.)
Wrong software version (Visual Cooking I oven)
Failure during initialisation of exhaust at oven start-up
24 V missing or failure of main contactor output
- 30 -
