Start Menu - Whirlpool Light programmable oven Service & Installation Manual

Change oven
temperature with
turn switch
Change time with
turn switch
Core temperature
on C and K models.
Injection time on B
model.
Program key
Step key
Alarm key
Set temperature (press temperature key, temperature flashes, set temperature with
turn switch, press temperature key again to save).
Set time (press time key, time flashes, set time with turn switch).
Set core temperature (press core temperature key, set temperature with turn switch).
C and K models only.
Set injection time (press injection key, time flashes, set injection time with turn
switch). B model only.

Start Menu

Main switch
Start/Stop
- 14 -
HOT AIR selected if
control lamp on
COMBI STEAMING
selected if upper or
middle control lamp
is on. REHEATING is
selected if lower
control lamp is on
.
Steaming on C and
K, preheating on B
Exhaust open if
control lamp on
Fan speed can be
set between 20 and
100%. Control lamp
is on when speed
< 100.
Turn switch
