Description of the device

Features
The Showtec Compact Par 18 Tri MKII is a light effect with high output and great effects.
• Compact flat Par Housing
• Stylish design
• Power Supply: 100-240V AC
• Easy Link Up to 15 units
• Convection cooling, 100% silent
• Flicker Free (Suitable for TV Studio)
• Power 60 Watt
• Drive Current: 350mA
• Refresh rate: 7,8 KHz
• LED System: 18 x 3-in-1 LED Technology
• Full 3-in-1 RGB color-mixing
• 4 Digits LED Control Display
• Double bracket
• Lumens: 9600
• Lux @2m: 4170
• Max Distance: 10m
• Control Mode: DMX512
• DMX channels: 1, 3, 4, 6
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Beam Angle: 28°
• Control: Built-in Programs, Auto, Sound-controlled, Master/Slave, DMX
• DMX-controlled
• Music-controlled via built-in microphone
• 3-pin DMX In and 3-pin DMX Out (XLR 3 Pin)
• IEC In and IEC Out
• Housing: Aluminum and iron
• Color: Black
• Cooling: Aluminum heat sink
• Dimensions: 250 x 290 x 96 mm
• Weight: 2,84 kg
• Fuse 1A / 250V
1 2
Overview
Fig. 1
1) Mountingbracket with adjustment screw
2) Lenses
