2. Auto Run Program

1) Press the MODE button on the device, until the display shows
2) With this menu you can set the Auto Mode of the Compact Par.

3. DMX Mode

With this menu you can set the DMX address.
1) Press the MODE button, until the display shows
2) You can choose 512 different DMX addresses.
Use the Up / Down buttons to select the required address from
3) You can also press the SETUP button to set 4 different DMX Modes.
Use the Up / Down buttons to select the required Mode.
1 Channel
3 Channels
4 Channels
6 Channels

4. Slave Mode

When the display shows:

5. Sound control Mode

1) Press the MODE button on the device, until the display shows
Compact Par will react to the beat of the music.
You can adjust the sensitivity from low sensitive to high sensitive.
, the device is a slave device. It will now react the same as its master.
13
.
.
. Turn on the music and the
.
