USER MANUAL
ENGLISH
V2
Cameleon Spot 18/3
Product code: 42690
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cameleon Spot 18/3 and is the answer not in the manual?

Questions and answers

Related Manuals for SHOWTEC Cameleon Spot 18/3

Summary of Contents for SHOWTEC Cameleon Spot 18/3

  • Page 1 USER MANUAL ENGLISH Cameleon Spot 18/3 Product code: 42690 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2 Cameleon Spot 18/3 Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
  • Page 3 Cameleon Spot 18/3 Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 LEDs Lifespan ............................... 4 Text Conventions ..............................4 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................6 Safety ..................................
  • Page 4 Cameleon Spot 18/3 Preventive Maintenance ..........................30 Basic Cleaning Instructions ........................30 Corrective Maintenance ..........................30 Deinstallation, Transportation and Storage ....................31 Instructions for Deinstallation ..........................31 Instructions for Transportation ........................31 Storage ................................31 10. Disposal ................................31 11. Approval ................................31 Product code: 42690...
  • Page 5 Cameleon Spot 18/3 Introduction Before Using the Product Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual.
  • Page 6 Cameleon Spot 18/3 Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury.
  • Page 7 Cameleon Spot 18/3 Symbols on the Information Label This product is provided with an information label. The information label is located on the backside of the device. The information label contains the following symbols: This device shall not be treated as household waste.
  • Page 8 Cameleon Spot 18/3 Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions...
  • Page 9 Cameleon Spot 18/3 ● Make sure that the cable run is not too heavy. A heavy cable run can cause damage to the connectors. If the connectors are damaged, their ingress protection (IP) can deteriorate. WARNING Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy.
  • Page 10 Cameleon Spot 18/3 Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ● The safety devices are not damaged.
  • Page 11 Cameleon Spot 18/3 Description of the Device The Showtec Cameleon Spot 18/3 is a compact but powerful fixture for both indoor and outdoor use. The specially designed housing has a stylish design and has the function of convection cooling which eliminates the use of fans.
  • Page 12 Cameleon Spot 18/3 Back View Fig. 03 04) 3-pin IP65 DMX signal connector IN 05) IP65 power IN 06) LED Display + Menu Buttons 07) IP65 power OUT 08) 3-pin IP65 DMX signal connector OUT Product code: 42690...
  • Page 13 Cameleon Spot 18/3 Product Specifications Model: Cameleon Spot 18/3 Electrical: Input voltage: 100–240 V AC, 50/60 Hz Drive current: 350 mA Power consumption: 70 W Physical: Dimensions: 320 x 212 x 195 mm (LxWxH) Weight: 4,4 kg Optics: Light source:...
  • Page 14 Cameleon Spot 18/3 Optional Accessories The Cameleon Spot 18/3 is delivered with accessories. You can additionally purchase the following accessories: ● Product code: 42698 (Power extension cable end capset Male/female) ● Product code: 42699 (DMX extension cable end cap set Male/female) ●...
  • Page 15 Cameleon Spot 18/3 Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing.
  • Page 16 Cameleon Spot 18/3 Rigging The device can be positioned on a flat surface or mounted to a truss or other rigging structure in any orientation. Make sure that all loads are within the pre-determined limits of the supporting structure. Fig. 05 CAUTION Restrict the access under the work area during rigging and/or derigging.
  • Page 17 Cameleon Spot 18/3 To mount the device, follow the steps below: 01) Use a clamp to attach the device to the supporting structure, as shown in Fig. 05. Make sure that the device cannot move freely. 02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the secondary suspension can hold 10 times the weight of the device.
  • Page 18 Cameleon Spot 18/3 Angle Adjustment You can adjust the angle of the device with the adjustment screw (01). 01) Turn the adjustment screw (01) counterclockwise to release it. 02) Tilt the device to the desired angle (see Fig. 07). 03) Turn the adjustment screw (01) clockwise to tighten it. Make sure that the device cannot move freely after the adjustment screw (01) is tightened.
  • Page 19 Cameleon Spot 18/3 Free-standing Bracket Installation 01) Put the free-standing bracket on the Cameleon Spot 18/3. 02) Install all elements as shown in Fig. 08. 03) Tighten the screws. Fig. 08 Connecting to Power Supply Attention Power supply This device falls under IEC protection class II. This device shall be connected to an external power supply.
  • Page 20 Disconnect power supply before connecting or disconnecting data cables. Stand-alone Setup When the Cameleon Spot 18/3 is not connected to a controller or to other devices, it functions as a stand-alone device. It can be operated in auto mode or manually.
  • Page 21 Fig. 09. Fig. 09 Master/Slave Setup The Cameleon Spot 18/3 supports master/slave control mode. To connect multiple devices in master/slave setup, follow the steps below: 01) Connect the first device’s DMX OUT connector to the second device’s DMX IN connector.
  • Page 22 04) Continue assigning the starting addresses of the remaining devices by adding each time 6 to the previous number. Make sure that you do not have any overlapping channels in order to control each Cameleon Spot 18/3 correctly. If two or more devices are addressed similarly, they will work similarly.
  • Page 23 Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device. Control Mode The Cameleon Spot 18/3 supports the following control modes: ● Stand-alone: Auto, manual, built-in programs ●...
  • Page 24 Cameleon Spot 18/3 Control Panel A) LED display MODE Button C) ENTER Button D) UP Button DOWN Button Fig. 12 ● Use the MODE function in each menu to exit the current submenu and to return to the Main Menu.
  • Page 25 Cameleon Spot 18/3 Menu Overview Product code: 42690...
  • Page 26 Cameleon Spot 18/3 Main Menu Options The main menu has the following options: Auto Programs DMX Address Slave Built-in Programs Press the UP/DOWN buttons to navigate through the main menu. 02) Press the ENTER button to open the submenus. Auto Program Mode In this menu you can select the auto program.
  • Page 27 Cameleon Spot 18/3 Built-in Programs In this menu you can create set the built-in program and add strobe effect. 01) Press the UP/DOWN buttons to select a parameter. There are 10 options available: Manual Color Mode 01) If you have selected Program 01, you can further select one of the 7 color presets and add strobe effect.
  • Page 28 Cameleon Spot 18/3 DMX Channels 1 Channel No Function 001–022 023–045 Green 046–068 Blue 069–091 Blue – Green 092–114 Yellow Macro Colors 115–137 Orange 138–160 Pink 161–183 Purple 184–206 Dark Blue 207–229 Pale Green 230–252 White 253–255 Pale Pink 3, 4, 6 Channels...
  • Page 29 Cameleon Spot 18/3 3 CH 4 CH 6 CH Function Value Setting Program Speed 000–255 Speed adjustment of the built-in chases, from slow (If CH6=26–255) to fast Green 000–255 From low to high intensity (0–100 %) Blue 000–255 From low to high intensity (0–100 %) 000–009...
  • Page 30 Cameleon Spot 18/3 Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage.
  • Page 31 Cameleon Spot 18/3 Maintenance Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded.
  • Page 32 Cameleon Spot 18/3 Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device.
  • Page 33 Cameleon Spot 18/3 Product code: 42690...
  • Page 34 Cameleon Spot 18/3 Product code: 42690...
  • Page 35 Cameleon Spot 18/3 Product code: 42690...
  • Page 36 ©2021 Showtec...
