Parcan 64 COB UV
Description of the device
Features
The Showtec Parcan 64 COB UV is a blacklight effect with high output.
• Light source: 100W UV COB
• Wavelength: 400nm
• Beam Angle: 90°
• Max distance: 15m
• Power consumption: max 110W
• Input voltage: 100-240V AC, 50/60Hz
• Power cable 1,5m with Schuko connector
• Housing: Die-cast black aluminum
• Cooling: Forced cooling
• IP rating: IP20
• Dimensions: 280 x 265 x 330 mm (LxWxH)
• Weight: 2,3 kg
Overview
Fig. 01
01) Mountingbracket with inclination screw
02) 100W UV COB
Ordercode: 80332
7
