Description Of The Device; Frontside - SHOWTEC Compact Par 7x CW/WW V1 Manual

Compact Par 7x CW/WW

Description of the device

Features
The Compact Par 7x CW/WW is a compact light effect with high output and great effects. The new
CW/WW version contains 7 LED's with Warm White and Coolwhite LED's in one ensuring perfect white
balance from 3200K up to 6000K.
● Flat stylish design
● Double bracket
● Input voltage: 100-240V, 50/60Hz
● Never change lamps again!
● Flat Par Housing
● Stylish design
● Power Supply: 100-240V AC
● Peak Power 130 Watt
● Continuous Power 60 Watt
● Drive Current: 250mA
● Refresh rate: 3.9KHz
● LED System: 7 x 2-in-1 LED Technology
● LED Colors: Warm White (3200K) and Cool White (6000K)
● 4 Digits LED Control Display
● Double bracket
● Control Mode: DMX512
● DMX channels: 2 or 4
● Dimmer: 0-100%
● Strobe: 0-20Hz
● Beam Angle: 40°
● Control: Built-in Programs, Auto, Master/Slave, DMX
● DMX-controlled
● 3-pin DMX In and 3-pin DMX Out (XLR 3 Pin)
● IEC Power connector
● Housing: Aluminum and iron
● Color: Dark grey and Black
● Cooling: Aluminum heat sink
● Fuse 1A / 250V
● Dimensions: 272 x 92 x 260 mm (LxWxH)
● Weight: 2,14 kg

Frontside

01) 7 x 4W RGBW LED
02) Adjustment screw
03) Mounting bracket
Ordercode: 42581
7
Fig. 01
