Chapter 1- Hardware Description
1-18

RTM ISDN

The following LEDs appear on the RTM ISDN:
Table 1-7 RMX 2000 RTM ISDN LEDs
LED
Function Name
Name
LAN LED (1) LNK
1 Gb
ShMC LEDs H/S
LED Color Description
Green ON with an active network
connection, flickers with Packet
activity.
Amber ON when 1Gb connection is
online, flickers with Packet
activity.
Blue OFF - Normal.
Flashes - This LED is activated
when the MPM/MPM+ card Hot
Swap functionality initiates a
power off routine on the MPM/
MPM+ and RTM ISDN cards.
ON - Power on the RTM ISDN
card has been switched OFF.
This LED is activated by the
MPM/MPM+ card when the
MPM/MPM+'s card Hot Swap
functionality powers off the
MPM/MPM+ and RTM ISDN
cards.
