Page 1: Installation Manual
Installation Manual WITH PC5O15 Version 2.2 W W W W W ARNING ARNING ARNING ARNING ARNING This manual contains information on limitations regarding product DLS-3 version 1.3 or higher use and function and information on the limitations as to liability of the manufacturer. -
Page 2: Limited Warranty
Locks and latches on windows and doors must be secure and operate as intended. Windows, doors, extent that they do not function upon delivery. In such cases, DSC can replace or credit at its option. walls, ceilings and other building materials must be of sufficient strength and construction to provide the level of protection expected. -
Page 3: Table Of Contents
Table of Contents Section 1: Introduction Zone Attributes ..............23 Communicator - Dialing ............. 24 PC5015 Specifications ............1 Communicator - Phone Numbers ........24 Additional Devices ............... 2 Communicator - Account Numbers ........25 Out of the Box ..............4 Communicator - Reporting Formats ........ -
Page 4: Pc5015 Specifications
System Introduction PC5015 Specifications Flexible Zone Configuration: • 8 Fully Programmable Zones • 38 Access Codes: 32 User, 1 System Master, 2 Partition Master, 2 Duress and 1 maintenance • Expandable to 32 Zones • Keypads with zone inputs available (PC5502Z2, PC5508Z, PC5516Z, PC5532Z, LCD5500Z, LCD5501Z) •... -
Page 5: Additional Devices
• Daylight Savings time option • Downlook support (DLM-4L: v1.0L and PC5108L) Additional Devices In addition to the information below, see the inside back cover for a DSC Module Compatability table. 1.2.1 Keypads A maximum of eight (8) keypads can be connected to the control panel and can be any combination of the following listed. - Page 6 1.2.4 PC5200/PC5204 Power Supply Output Module The PC5200 and PC5204 can provide up to 1 Amp of additional power for modules or devices connected to the control panel. The PC5204 module requires a 16.5 volt AC 40 VA transformer and 4 AH battery. In addition, the module provides 4 program- mable high current voltage outputs (see PC5204 Installation Instructions for details).
-
Page 7: Out Of The Box
1.2.11 PC5700 Fire Module This is a zone expansion module with four general purpose zone inputs, two Class A supervisory waterflow zone inputs, ground fault detection and dual-supervised telephone line inputs. 1.2.12 Cabinets Several different cabinets are available for the PC5015 modules. They are as follows: PC500C Control panel enclosure (Recommended use: Household Fire &... -
Page 8: Section 2: Getting Started
Getting Started The following sections provide a complete description of how to wire and configure devices and zones. Installation Steps The following steps are provided to assist with the installation of the panel. It is suggested that you read over this section briefly to get an overall understanding of the order of installation. - Page 9 Auxiliary Power Terminals - AUX+ and GND These terminals provide up to 550 mA of additional current at 12 V for devices requiring power. Connect the positive side of any device requiring power to the AUX+ terminal, the negative side to GND. The AUX output is protected;...
-
Page 10: Wire Routing For Power & Non-Power Limited
Current Ratings - Modules and Accessories In order for the Power 832 system to operate properly, the power output capabilities of the main control and expansion devices must not be exceeded. Use the data presented below to ensure that no part of the system is overloaded and cannot function properly. -
Page 11: Assigning Zones To Zone Expanders
BELL: 700 mA. Continuous Rating. 3.0 A. Short Term. Available only with stand-by battery connected. • PC5200/5204 VAUX:1.0 A. Continuous Rating. Subtract for each device connected. 3.0 A. Short Term. Available only with stand-by battery connected. • PC5208 VAUX: 250 mA. Subtract for each device connected. Subtract the total load on this terminal from the PC5015 VAUX/Keybus output. -
Page 12: Keypad Assignment
Keypad Assignment There are 8 available addresses for keypads. The LED, LCD5501Z and the LCD5501Z32-433 keypads by default are assigned to address 1 while the LCD5500(Z) is assigned by default to address 8. Keypads can each be assigned to a different address (1 to 8) which offers two advantages. The panel can supervise the keypad connection to indicate a trouble condition if it is removed. -
Page 13: Removing Modules
Removing Modules If a module is no longer required on the system the panel must be told to no longer supervise the module. To do this remove the module from the Keybus and perform the Enable supervision function again ( See Section 2.7 “Enable Supervision”). - Page 14 The following chart shows zone status under certain conditions: Loop Resistance Loop Status 0Ω (shorted wire, loop shorted) Fault 5600Ω (contact closed) Secure Infinite (broken wire, loop open) Tamper 11200Ω (contact open) Violated ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ End-of-Line Resistors ..........
-
Page 15: Keypad Zones
2.10.8 LINKS Supervisory (24 Hour Supervisory) When using the LINKS1000 cellular communicator, any main board zone may be configured for LINKS Supervision. Program this zone as zone type [09], 24 Hour Supervisory in section [001]. With a 24 Hour Supervisory zone, if the LINKS1000 experiences a trouble, the zone will be violated, causing the panel to report the event to the central station. -
Page 16: Section 3: Keypad Commands
Keypad Commands All keypads provide complete information and control of the alarm panel. The panel can be completely programmed via any keypad on the system. LED keypads provide function indicator lights and individual zone indicator lights for the alarm circuits. The LCD keypad provides function indicator lights and word descriptions for zone status. The following sections describe how to arm, disarm and perform other keypad functions. -
Page 17: Auto Bypass
system was not Ready. When the correct code is entered and the system is Ready the panel will beep six times rapidly and the ‘Armed’ light will turn on. Exit the premises through the designated entry/exit door. Other methods of arming are available (See Section 3.4 “[ ✱ ] Commands - [ ✱ ] [0] Quick Arm, [ ✱ ] [9] Arming Without Entry Delay” and Section 3.5 “Function Keys”) . - Page 18 The various troubles are described below: Light Trouble Service Required: Press [1] to determine the specific trouble. If one of the following zone lights is on, the corresponding trouble is present: • Light [1] – Low Battery: Main panel backup battery charge is low (below 11.5 volts under load).Trouble is restored when the battery charges over 12.5 volts.
- Page 19 [✱ ✱ ✱ ✱ ✱ ] [5] Programming Access Codes All 37 access codes are programmed in this section. For instructions on programming access codes, see the PC5015 Instruction Manual (“Programming Access Codes”). [✱ ✱ ✱ ✱ ✱ ] [6] User Functions To program user functions, perform the following: 1.
-
Page 20: Function Keys
[✱ ✱ ✱ ✱ ✱ ] [0] Quick Arm If the Quick Arm Enable option is enabled the panel can be armed by entering [✱][0]. This is a useful method of arming a Partition when someone without a access code will be required to arm a Partition. The Quick Ar The Quick Ar The Quick Ar... - Page 21 [06] - [✱]+[4] Door Chime On/Off This function key provides the user a simple method for turning the Door Chime feature on and off (See Section 3.4 “[ ✱ ] Commands, [ ✱ ] [4] Door chime on/off”) . [07] - [✱]+[6]...[4] System Test This function key provides the user with a simple method for testing the system (See Section 3.4 “[ ✱...
-
Page 22: Global And Partition Keypad Operation
[24] - Recall Bypass Group #1 This function key will recall zones in Bypass Group #1. This group is programmed by the user in the [*][1] Bypass menu. The function key will follow the Code Required for Bypass option. If the option is enabled, a valid access code with the Bypass attribute enabled must be entered after the function key is pressed. -
Page 23: Section 4: How To Program
How to Program The following section of the manual describes how to enter Installer Programming and how to program the various sections. It is extr It is extr emely impor emely impor tant that you r tant that you r ead the following section of the manual to completely understand how to ead the following section of the manual to completely understand how to It is extr... -
Page 24: Programming Toggle Option Sections
Example: for the three digit account number ‘403’, you would enter [4], [✱] [1] [✱] [3], [0]. [4] to enter the digit 4 [✱] to enter Hexadecimal mode (Ready light flashes) [1] to enter A [✱] to return to decimal mode (Ready light is solid) [3] to enter the digit 3 [0] to enter the digit 0 as a filler digit. -
Page 25: Section 5: Program Descriptions
Program Descriptions The following section explains all the programmable features including how the feature operates, options that pertain to the feature and a summary of program locations that require programming. Zone Definitions These sections will allow you to select how each of the 32 zones will operate. Each zone requires a 2 digit entry. -
Page 26: Zone Attributes
[09] 24 Hour Supervisory Zone If this zone is violated, whether armed or disarmed, the panel will report to the central station, and log the zone fault. This zone gives a silent alarm by default. Do not wir Do not wir e 24-Hour Super e 24-Hour Super visor... -
Page 27: Communicator - Dialing
Force Arm Enable Determines if the system can be armed with the zone violated. At the end of exit delay, if this type of zone is violated, it will be ignored by the panel. Once the zone is secured it will be added back into the system. This zone attribute is useful for a garage door. -
Page 28: Communicator - Account Numbers
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 1st Phone Number ..........Section [301] 2nd Phone Number .......... - Page 29 Please refer to Appendix A: “Reporting Codes”for a list of Contact ID Identifiers. ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Contact ID Uses Programmed/Automatic Codes ..
-
Page 30: Communicator - Reporting Codes
Communicator – Reporting Codes Reporting codes must be programmed in order for the panel to report events to the central station. Reporting codes are two digits and can use hexidecimal digits A through F. To disable a reporting code, program it as “FF”... -
Page 31: Downloading
on the Bell Output of the main panel. The Bell Circuit Trouble Restoral Reporting Code will be transmitted as soon as the problem is corrected. A Fire Trouble Alarm Reporting Code will be transmitted immediately when an open condition is measured on any Fire type zone (See Section 5.1 “Zone Definitions”). -
Page 32: Partitions/Zone Assignment
The time to complete a successful download can be significantly reduced with the use of the PC-Link. This adaptor ✱ makes it possible to perform on-site downloading. To Initiate Local Downloading via the PC-Link, enter [ ] [8] [Installer’s Code] [499] [Installer’s Code] [499]. All keypads will be busy for the duration of the PC-Link connection. The status LEDs will display the current system status on the keypad where the PC-Link was initiated. - Page 33 Please refer to the Control Panel Wiring Diagram in this manual for wiring instructions. e Smoke and [20] [ ✱ ] [7] [2] Command Output Only ONE of options [03] Sensor Reset, [04] 2-W Only ONE of options [03] Sensor Reset, [04] 2-W Only ONE of options [03] Sensor Reset, [04] 2-Wir ir ir ir ire Smoke and [20] [ e Smoke and [20] [ e Smoke and [20] [...
- Page 34 [15] Remote Operation (DLS-3 Support) This output can be activated and deactivated remotely using DLS software. [16] LINKS1000 Support (PGM1 Only) The output will be used as a data wire to communicate phone number information for the LINKS1000 cellular unit. [17] Away Armed The output will activate when the system is armed with the Stay/Away zones activated.
-
Page 35: Telephone Line Monitor (Tlm)
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ PGM Output Attributes ..........Section [141]-[142] PC5208 Attributes ..........Section [143]-[150] PC5204 Attributes .......... -
Page 36: Fire, Auxiliary, Panic Keys
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Test Transmission Reporting Codes ...... Section [352] Test Transmission Time of Day ......Section [371] Test Transmission Cycles ........ -
Page 37: Event Buffer
exists. (See Section 5.17 “Swinger Shutdown”.) The event buffer can be viewed three different ways. It can be viewed through an LCD keypad, printed on-site using the PC5400 printer module (See Section 5.29 “On-Site Printer”) or it can be uploaded through the DLS software. 5.16.1 Viewing the Event Buffer The following is the procedure for viewing the event buffer through the LCD keypad:... -
Page 38: Automatic Arming
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Arm/Disarm Bell Squawk ........Section [014], Option [1] Bypass Status Displayed While Armed .... -
Page 39: Keypad Blanking
5.23 Keypad Blanking If the Keypad Blanking Option is enabled the panel will turn off all lights and LCDs on the keypads if no key is pressed for 30 seconds. The keys, however, will remain backlit. The panel will turn the lights and LCDs back on if entry delay begins or an audible alarm occurs. The lights and LCDs will also come on if a key is pressed or, if the Code Required to Restore Blanking Option is enabled, a valid access code is entered. -
Page 40: Module Programming
5.26.4 LINKS Special Preamble In some areas of North America, dialing #DAT or ✱DATA reduces the cellular billing increment. The LINKS Special Preamble (section [393]), allows the use of [✱] and [#] characters for the programming of #DAT and ✱DATA. The LINKS Special Preamble is sent BEFORE the Preamble programmed in Sections [390] to [392]. -
Page 41: Installer Lockout
5.28.2 Factory Default Main Panel (Software) and other Modules Step 1 - Enter Installer Programming. Step 2 - Enter Program Section [99X]. Step 3 - Enter the Installer Code. Step 4 - Enter Program Section [99X] again. The panel will take a few seconds to reset. When the keypad is operational, the default is complete. ○... -
Page 42: Appendix A: Reporting Codes
Reporting Codes Contact ID SIA Format (Level 2—Hardcoded) This format will send the Account Code along with its The first digit (in parentheses) will automatically be sent by the control. The last two digits are programmed to indicate data transmission. At the receiver, the transmission specific information about the signal. - Page 43 Section Reporting Code Code Sent When... Dialer Auto- SIA Auto Direction* matic Contact Codes** [344-348] Openings system disarmed (user 01-34, 40-42 indicated) (4) A2 OP-UU [348] Auto Arm Cancellation auto arm cancelled (4) A5 CE-00 [348] Special Opening Opening (disarming) using one of the following (4) AA OP-00 methods: keyswitch, maintenance code, DLS...
-
Page 44: Appendix B: Zone Reporting Codes
The person of The control panel must be in the Attack Resistant Enclosure mutual interest is not the alarm installing company. (DSC Model CMC-1, P/PC4050CAR, P/PC4004C). Bell Location Grade B Central Station and Police Connect... -
Page 45: Appendix C: Control Panel Wiring Diagram
PC5015 Control Panel Wiring Diagram WWW.DIYALARMFORUM.COM... -
Page 46: Appendix D: Modules Supported On The Pc5015 V2.2
Modules Supported on the PC5015 v2.2 i t n e i f ; t r n i t WWW.DIYALARMFORUM.COM... - Page 47 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 48 ©2002 Digital Security Controls Ltd. Direct all comments and sugges- tions concerning DSC publications Toronto, Canada • www.dsc.com to pubs@dscltd.com Technical Support: 1-800-387-3630 Printed in Canada 29003272 R005 WWW.DIYALARMFORUM.COM...
