Regulated
Supervised
NAC Outputs
Power Limited
Fig. 4
Ethernet
Connection
Common Trouble Sync
Power Limited
ALL POWER LIMITED
WIRING IS TO BE ROUTED
UNDER THE CHASSIS
(BETWEEN CHASSIS AND BACKBOX)
FireSwitch108
Wiring Diagram:
AC and Battery
Supervision
Power Limited
AC Input
Non-Power Limited
120VAC, 60Hz
4.8 amp
Regulated
NAC Outputs
Power Limited
Aux. Output
Regulated
24VDC @ 1 amp
Power Limited
(0.45 for Canadian
applications)
- 7 -
