Page 1: Installation Guide
AL842ULADA NAC Power Extender Installation Guide (See Application Guide for additional information) Altronix Corp. 140 58th St. Brooklyn, NY Rev. 042010... -
Page 2: Specifications
AL842ULADA - NAC Power Extender Overview: The Altronix AL842ULADA is an extremely cost effective 8 amp remote power supply/battery charger. It may be con- nected to any 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements. -
Page 3: Power Supply Specifications
Use two (2) 12VDC / 12AH or two (2) 12VDC / 7AH batteries connected in series. Stand-by/Alarm Current 90mA/175mA Consumption: EOL Resistor (end of line): 2.2K (2200 ohm), Altronix Model # AL-EOL22 (included). Ground fault maximum 1000 ohm. test impedance:... - Page 4 Cooper Wheelock. Note: The AL842ULADA will only synchronize horns, horn/strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.
- Page 5 “Stand-by Specifications” above for ratings. When loads are connected to the “AUX1” and/or “AUX2” outputs during alarm condition, the remaining outputs may not exceed 8 amp total alarm current. (example: AUX1 = 1 amp, AUX2 = 1 amp, outputs up to 7 amp). AL842ULADA - 5 -...
-
Page 6: Led Diagnostics
To reset the memory depress the reset button located on the AL842LGK logic board (Fig. 2c, pg. 7). The LED(s) will extinguish. Note: When indicating circuits have restored, trouble memory reset is not required for normal operation. - 6 - AL842ULADA... -
Page 7: Reset Button
AC and Bat Fail 4-wire Smoke 4-wire Smoke (FACP) and will cause Detector Detector a simultaneous Fire EOL Resistor trouble condition to the Alarm from FACP FACP's IN1 and IN2 Control Panel (Non-Supervised) (FACP) EOL R from AL842ULADA - 7 -... -
Page 8: Maintenance
10 amp @ 250V, Output fuse rating is 15 amp @ 32V. Note: Maximum charging current is 3.2 amp. Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. - 8 - AL842ULADA... -
Page 9: Battery Calculation Worksheet
Current Current For each device use this formula: This column x This column = Equals Current per number of devices. Stand-by: 90mA 90mA AL842ULADA (Current draw from battery) Alarm: 175mA 175mA AL842 Current 90mA 175mA Auxiliary Devices Refer to device manual for current ratings. -
Page 10: Appendix A - Ul Listed Compatible Devices
Appendix A - UL Listed Compatible Devices A.1 Four (4) Wire Smoke Detectors Table A-1 below lists four (4) wire smoke detectors compatible with AL842ULADA AUX output. Max Standby Alarm Smoke Detector/Base Detector Type Current (mA) Current (mA) System Sensor B112LP Base 0.12... - Page 11 System Sensor 6424 Projected Beam 28.4 System Sensor Beam 1224(S) Projected Beam 38.5 * Contact manufacturer for current draws A.2 Relays Table A-3 below lists relays compatible with AL842ULADA AUX output. Manufacturer Model Current (mA) PR-1 PR-2 PR-3 EOLR-1 R-10T...
- Page 12 (114.3mm) (69.85mm) 14.5” (368.3mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIAL842ULADA I04M MEMBER - 12 - AL842ULADA...
