Specifications for the Synesso™ Line of Semi Automatic Espresso Machines
Model
Voltage
Hertz
Amps - max draw
Brew and Steam Specifications:
Watts per Element, Steam Tank
Total Steam Element Wattage
Steam Tank Capacity (Liters)
Watts per Element, Brew Tank
Brew Tank Capacities (Liters)
Machine Dimensions:
Height
(Steam Wand 21", Handle 20.5")
Width
(Steam Handle to Handle add 3")
Depth
Weights & Dimensions:
Machine Weight, Empty
Machine Weight, Full of Water
Shipping Weight (approximate)
Boxed Dimensions: L" x W" x H"
Boxed Dimensions: L x W x H m/m
Plumbing (Compression)
· Certified by ETL for Sanitation to NSF / ANSI Standard 4
· Certified by ETL for Electrical Safety to ANSI / UL Standard 197
· Certified by ETL for Electrical Safety to CSA Standard C22.2 No. 109
· CE Compliant (By request)
· C-Tick Compliant (By request)
Technical Manual
1 Group 1 Group
110 220
60 50 / 60
20 16
1000 1000 x 2
1000 2000
3.2 3.2
700 700
1.9 1.9
Inches / mm Inches / mm Inches / mm Inches / mm
18" / 457 18" / 457
18" / 457 18" / 457
23" / 584 23" / 584
Lbs / Kgs Lbs / Kgs
106 / 48 106 / 48
115 / 52 115 / 52
175 / 80 175 / 80
20"x30"x31" 20"x30"x31"
508x762x787 508x762x787
3/8" OD 3/8" OD
9
2 Group 3 Group
220 220
50 / 60 50 / 60
28 36
2000 x 2 2500 x 2
4000 5000
7.7 12.3
700 x 2 700 x 3
1.9 x 2 1.9 x 3
18" / 457 18" / 457
29" / 736 40" / 1016
23" / 584 23" / 584
Lbs / Kgs Lbs / Kgs
154 / 70 190 / 86
173 / 77 215 / 98
225 / 103 270 / 123
41"x32"x31" 49"x32"x31"
1042x762x787 1245x813x787
3/8" OD 3/8" OD
