Start-Up Instructions
1. To fill the coffee brew tanks, turn the water ON.
2. Switch the electronics On/Off switch to ON. This activates
the machine's water auto-fill feature for the steam tank and
the electronics, but NOT the heating elements.
3. The water level sight glass for the steam tank is located on
the right side of the machine. As the tank fills, the water level
will rise in the sight glass and will automatically stop when
the preset level is reached.
4. Turn the brew group to the BREW position, (see sketch on
the right) allow the air to escape and return the brew group
to the OFF position. Volumetric machines: Activate the
pitcher button on the right side of the keypad. Once the
water flows in a steady stream, press the pitcher button
again to stop the water.
5. Make sure the water level in the sight glass reads at least ½ full and then turn the heating
element breaker to the ON or (1) position.
6. To adjust the pump pressure, activate the pump infusion by turning the brew group to the
BREW position.
7. Locate and read the pump pressure on the brew gauge. The brew gauge is found on the right
hand side of the brew group.
8. Set the pump pressure to 9 Bar. To do this, locate the pump adjusting screw on the right side
of the brass pump housing. Loosen the lock nut and turn screw with a screwdriver.
• Clockwise to INCREASE pressure
• Counterclockwise to DECREASE pressure
9. Please allow at least ½ hour of "warm up" time before using your Synesso™ espresso ma-
chine to brew shots or steam milk. The steam gauge, located on the left side of the first brew
group, should read a minimum of 1.1 Bar.
Unplugging EMC Compliant Machines
(C-Tick for Australia and NZ, CE for Europe)
To comply with EMC (Electromagnetic Compatibility) regulations, Synesso™ is required to install
a capacitor in the electronics box across the main power IN. To avoid an electric shock from the
charge held in the capacitor, unplug the cord, taking care to NOT touch the metal prongs on
the plug end. Turn the electronics ON/OFF red rocker switch to the ON position and wait a few
