Installation - Synesso Espresso Machine Technical Manual

To maintain the 1 year warranty, an authorized or certified espresso service representative
must perform the installation of this espresso machine.
Site Preparation
The machine must be placed on a level horizontal surface that can be easily cleaned and is capable
of sustaining a minimum of 300 lbs. of weight.
The surface depth should allow for a minimum clearance of 1" behind and 3" in front of the machine.
Make a 2 ½" round hole through the counter top, 4" from the back center of the machine. This should
provide ample room for the hoses and electrical lines.
A 3/8" cold water supply line with a shut off valve is needed within 5' of the machine, preferably
located directly underneath the machine.
A proper water filtration or softening system must be installed on the incoming water supply. Water
treatment systems will vary, and it is important to use a system designed to match the needs of your
specific area. Most water filtration systems require periodic maintenance, including cartridge or filter
replacement. This is vital to the proper functioning of the machine and the quality of the espresso
served. Follow the instructions provided by your water treatment system for proper installation.
Note: Improper water filtration can result in water damage inside the machine causing scale and
corrosion. DAMAGE CAUSED BY IMPROPER WATER TREATMENT WILL NOT BE COVERED BY
THE MACHINE WARRANTY.
There must be adequate room under the counter to locate the motor and pump. This should be within
5' of the cold water supply line. The pump should be easily accessible for potential adjustments and
should have proper ventilation and a minimum of 3" clearance on all sides. Dimensions of the pump
and motor are: 6 ½" Height x 5 ½" Width x 9 ½" Depth.
A floor drain or sink should be readily available. The best location is directly under the installation site
of the machine. The drain hose should descend steeply for proper drainage.
An electrical receptacle and matching plug, rated at the proper voltage and amperage is required
within 3' of the location of the machine. Plug ends are not included with the machine. Below are the
recommended cord plug ends for the Synesso™ machines:
• 1 Group, 110 V – UL-listed 20 amp
• 1 Group, 220 V – UL-listed 20 amp
• 2 Group, 220 V – UL-listed 30 amp
• 3 Group, 220 V – UL-listed 50 amp
