RHW75CN2, RHP75CN2
IP Ready Network Housing
IP Ready Network Housing with 24Vac input, wall mount or
pendant mounting, heater & blowers, ready for standard IP
PTZ cameras. Includes 120 to 24Vac, 40Va transformer.
ELECTRICAL SPECIFICATIONS (OUTDOOR ONLY):
!
Power 24Vac, Class 2 Only
Total Power: 52 watts
Accessories (Heater/Blower): 26 watts
Heater: 25 watts
Blower: 1 watt
Camera Power: 26 watts
NOTE: (1) 100Va transformer is provided for
Accessory and Camera Power.
NOTE: This unit is designed for operation in an
upright position. Installing the housing
upside down may cause damage to
the internal equipment, and will void the
warranty.
GENERAL INSTRUCTIONS:
Tools Required: .100" Flat Head Screwdriver
Phillips Head Screwdriver
Be sure the bracket is properly and securely mounted
!
to a supporting structure capable of rigidly holding
the weight of the entire unit.
ASSEMBLING THE UNIT:
1. Remove content from all boxes.
Contents should include:
Main Housing Assembly
Either with wall mount or pendant bracket
Dome Assembly - Clear or Tinted
Do not remove the protective film until the product is
assembled and installed.
4 Packet Assemblies
(2) 40Va Transformers
-  -
