Moog Videolarm RM7CF2 Installation And Operation Instructions Manual

Vandal-resistant dome housing

Advertisement

Quick Links

© 2011, Moog Videolarm, Inc. All Rights Reserved
R M 7 C F 2
Vandal-Resistant Dome Housing
Installation and Operation Instructions for the following models:
RM7CF2
Outdoor 24Vac clear vandal-resistant recessed housing for fixed camera
with heater/blower
RM7CF2N
Outdoor 24Vac clear vandal-resistant recessed housing for fixed network
(12Vdc) camera with heater/blower
IRM7CF
Indoor clear vandal-resistant recessed housing for fixed camera
IRM7CF2N
Indoor 24Vac clear vandal-resistant recessed housing for fixed network
(12Vdc) camera with heater/blower
IRM7TF
Indoor tinted vandal-resistant recessed housing for fixed camera
RM7TF2N
Outdoor 24Vac tinted vandal-resistant recessed housing for fixed network
(12Vdc) camera with heater/blower
IRM7CF2
Indoor 24Vac clear vandal-resistant recessed housing for fixed camera
with heater/blower
Before attempting to connect or operate this product, please read these instructions completely.
www.videolarm.com
81-IN5395
01-13-2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM7CF2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Moog Videolarm RM7CF2

  • Page 1 © 2011, Moog Videolarm, Inc. All Rights Reserved R M 7 C F 2 Vandal-Resistant Dome Housing www.videolarm.com Installation and Operation Instructions for the following models: RM7CF2 Outdoor 24Vac clear vandal-resistant recessed housing for fixed camera with heater/blower RM7CF2N Outdoor 24Vac clear vandal-resistant recessed housing for fixed network (12Vdc) camera with heater/blower IRM7CF Indoor clear vandal-resistant recessed housing for fixed camera IRM7CF2N Indoor 24Vac clear vandal-resistant recessed housing for fixed network (12Vdc) camera with heater/blower IRM7TF Indoor tinted vandal-resistant recessed housing for fixed camera RM7TF2N...
  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK).
  • Page 3: Terms And Conditions

    If Purchaser believes that the Product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to Moog Videolarm. All claims for warranty service must be made within the warranty period.
  • Page 4: Electrical Specifications

    Electrical Specifications Contents of Box RM7CF2N Power 24VAC RM7CF2 ( OUTDOOR ONLY ) Class 2 Only 24 VAC 2.25 Amps 54 Watts Total Power: 54 Watts Accessories: Heater: 25 Watts/Blower: 1 Watt English Camera Power: 28 Watts Tools Required: .100” Flat Head Screwdriver...
  • Page 5 10.375” A box cutter or jigsaw can be used for Using the provided template, mark the cutting the circle. ceiling tile for the cutout. • Con la plantilla proporcionada, cortar el azulejo del • Un cortador o un rompecabezas de la caja se techo para el agujero.
  • Page 6 Add the safety wire to the flex conduit or The alternate location to attach the safety continue to the next step. wire is on the housing secure tab. • La localización alterna para unir el alambre de seguridad • Agregue el alambre de seguridad al conducto de la está...
  • Page 7 WIRING INSIDE HOUSING 12VDC Power leads RM7F2N 12VDC+ 12VDC- Black Camera power supply DC power for camera (red & black wires) The beam angle may be adjusted on the The beam angle may be adjusted on the These are recommended maximum distances I nstall the camera on the fixed bracket and bottom of the unit.
  • Page 9: Product Registration/Warranty

    Product Registration/Warranty Thank you for choosing Moog Videolarm. We value your patronage and are solely committed to providing you with the highest quality products available and superior customer service. Should a problem arise, rest assure that Moog Videolarm stands behind its products by offering impressive warranty plans: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on camera systems (SView, QView, Warriors), and InfraRed Illuminators. Register Your Products Online Take a few moments and validate your purchase via the Online Product Registration Form at www.videolarm.com/productregistration.jsp Register your recent Moog Videolarm purchases and benefit from the following: • Simple and Trouble-Free RMA process • Added into customer database to receive product updates / news • Eliminate the need to archive original purchase documents: Receipts, Purchase Orders, etc…...

This manual is also suitable for:

Rm7cf2nIrm7cfIrm7cf2nIrm7tfRm7tf2nIrm7cf2
