Specifying your video output settings (MXO2
and MXO2 Rack only)
MXO2 features simultaneous video outputs that allow you to send your video to
a variety of devices at the same time. MXO2 provides two separate video output
channels to choose from: main channel and SD channel. The video output
settings allow you to set the main channel's video format, assign a video channel
to an MXO2 output, and define the channel's behavior. You can also select other
settings such as the scrub and pause method, and calibrate your HDMI monitor
for video.
For a list of the supported video output formats for the MXO2 main and SD
channels, and the supported video formats for the MXO2 outputs, see
D, "Matrox MXO2 Supported Output
From the Apple menu, click System Preferences , and then click the
1
Matrox MXO2
Click Video Output .
2
From the Set main channel format to menu, you can select the video
3
output format that you want for the MXO2 main channel. For a list of the
supported video output formats for the MXO2 main and SD channels, see
"Main and SD video output formats supported on MXO2 and MXO2 Rack"
on page 108.
$
Chapter 6, Installing Your MXO2 Software and Configuring Your System
icon.
Follow application
project's video output format, or to a compatible format for your project.
For example, if your project's video output is NTSC, the MXO2 main
Formats."
Sets the main channel's video output to match your
Appendix
