Installation
Note:
It is also possible to mount the unit using any strong epoxy glue.
Apply the glue and then hold the unit's back plate firmly in
place until the glue dries.
8.
Re-attach the unit's front cover.

3.2 Wiring Instructions

The unit is supplied with a 16-inch pigtail, having a 10-conductor cable.
To Connect the Unit to the Controller
1.
Prepare the unit's cable by cutting the cable jacket back 1¼ inches
and strip the wire ½ inch.
2.
Prepare the controller cable by cutting the cable jacket back 1¼
inches and strip the wire ½ inch.
3.
Splice the unit's pigtail wires to the corresponding controller wires and
cover each connection.
Refer to the wire color table below, and to the wiring diagrams
provided on the following pages.
Controller
5~16 VDC
Shield / Ground
C1
C2
LED_CTL
Tamper
Tx
Rx
Ground
N/A
4.
If the tamper output is used, connect the purple wire to the correct
input on the controller when used as reader, or to the zone input of
an intruder alarm system when used as a controller.
5.
Trim and cover all unused conductors.
Page 9
Reader
5~16 VDC
Shield / Ground
Data 1
Data 0
LED_CTL
Tamper
Tx
Rx
Ground
N/A
Color
Functionality
Red
+DC Input
Black
Ground
White
Communication
Green
Communication
Brown
Auxiliary Input
Purple
Tamper
Blue
RS-232 Transmit
Grey
RS-232 Receive
Orange
RS-232 Ground
Yellow
N/A
