Warning word, extended Status word and
Alarm word
Warning word, extended word and Alarm word are
shown on the display in Hex format. If there is more
than one warning or alarm, a sum of all warnings or
alarms will be shown. Warning word, extended word
and Alarm word can also be displayed using the
serial bus in parameter 540, 541 and 538.
VLT 6000
Bit (Hex) Unit
diagnose bit
00000001 80
00000002 81
00000004 82
00000008 83
00000010 84
00000020 85
00000040 86
00000080 87
00000100 72
00000200 73
00000400 74
00000800 75
00001000 76
00002000 77
00004000 78
00008000 79
00010000 64
00020000 65
00040000 66
00080000 67
00100000 68
00200000 69
00400000 70
00800000 71
01000000 56
02000000 57
04000000 58
08000000 59
10000000 60
20000000 61
40000000 62
80000000 63
44
Extended word (P.
532)
Overvoltage control
active
Start delay
Sleep boost active
Sleep mode active
Automatic mode
adaptation
completed
Automatic mode
adaptation running
Reversing and start
Ramp operation
Reversing
Speed = reference
Running
Local ref. = 0
Remote controlled
ref. = 1
OFF mode = 1
Auto mode = 0
Hand mode = 1
Start blocked
Start blocked signal
missing
Freeze output
Freeze output
bloced
Jogging
Jog blocked
Stand by
Stop
DC stop
Drive ready
Relay 123 active
Drive ready
Control ready
Start prevented
Profibus OFF3 active
Profibus OFF2 active
Profibus OFF1 active
Reserved
VLT® 5000/ 5000 FLUX/ 6000 HVAC/
8000 AQUA PROFIBUS
VLT 5000
Bit (Hex) Unit
diagnose bit
00000001 112
00000002 113
00000004 114
00000008 115
00000010 116
00000020 117
00000040 118
00000080 119
00000100 104
00000200 105
00000400 106
00000800 107
00001000 108
00002000 109
00004000 110
00008000 111
00010000 96
00020000 97
00040000 98
00080000 99
00100000 100
00200000 101
00400000 102
00800000 103
01000000 88
02000000 89
04000000 90
08000000 91
10000000 92
20000000 93
40000000 94
80000000 95
MG.90.G1.02 - VLT is a registered Danfoss trademark
Alarm word,
binary (P. 538)
Brake test failed
Trip lock
AMA tuning not OK
AMA tuning OK
Power up fault
ASIC fault
HPFB bus timeout
Standard bus
timeout
Short-circuiting
Switchmode fault
Earth fault
Overcurrent
Torque limit
Motor thermistor
Motor overload
Inverter overload
Undervoltage
Overvoltage
Phase fault
Live zero fault (4-20
mA current signal
low)
Heat sink
temperature too
high
Motor phase W
missing
Motor phase V
missing
Motor phase U
missing
Quick discharge not
OK
Filedbus
communication fault
Mains failure
Inverter fault
Brake power fault
Encoder loss
Safety interlock
Reserved
