VLT 5000
Bit (Hex) Unit
diagnose bit
00000001 48
00000002 49
00000004 50
00000008 51
00000010 52
00000020 53
00000040 54
00000080 55
00000100 40
00000200 41
00000400 42
00000800 43
00001000 44
00002000 45
00004000 46
00008000 47
00010000 32
00020000 33
00040000 34
00080000 35
00100000 36
00200000 37
00400000 38
00800000 39
01000000 24
02000000 25
04000000 26
08000000 27
10000000 28
20000000 29
40000000 30
80000000 31
MG.90.G1.02 - VLT is a registered Danfoss trademark
Warning word 1 (P.
540)
Fault during brake
test
Fault in EEprom on
control card
Fault in EEprom on
power card
HPFB bus timeout
Serial
communication
timeout
Overcurrent
Torque limit
Motor thermistor
Motor overload
Inverter overload
Undervoltage
Overvoltage
Voltage warning low
Voltage warning high
Phase fault
No motor
Live zero fault
Under 10 Volt
(terminal 50)
Not used
Brake resistor power
100%
Brake resistor fault
Brake transistor fault
Out of frequency
range
Fieldbus
communication fault
Not used
Mains failure
Motor too small
Motor too big
Check p. 103 and p.
105
Check p. 104 and p.
106
Encoder loss
Not used
VLT® 5000/ 5000 FLUX/ 6000 HVAC/
8000 AQUA PROFIBUS
VLT 5000
Bit (Hex) Unit
diagnose bit
00000001 80
00000002 81
00000004 82
00000008 83
00000010 84
00000020 85
00000040 86
00000080 87
00000100 72
00000200 73
00000400 74
00000800 75
00001000 76
00002000 77
00004000 78
00008000 79
00010000 64
00020000 65
00040000 66
00080000 67
00100000 68
00200000 69
00400000 70
00800000 71
01000000 56
02000000 57
04000000 58
08000000 59
10000000 60
20000000 61
40000000 62
80000000 63
Extended word (P.
541)
Ramping
Automatic motor
tuning
Start clockwise/anti-
clockwise
Slow down
Catch-up
Feedback high
Feedback low
Output current high
Output current low
Output frequency
high
Output frequency
low
Brake test ok
Braking max.
Braking
Quick discharge OK
Out of frequency
range
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
PB acyclic MC1
communication
PB acyclic MC2
communication
Not used
Not used
