Laser information

Three configurations of cards with fixed optics will be provided for each of the connector types: four
extended long-wave ports, four long-wave ports, and four short-wave ports.

Table 10

Laser specifications
Part Number
300836-B21
Long wave:
35 Km
300835-B21
Long wave:
10 Km
300834-B21
Short wave
2 Gb
–
Transceivers on Wave
UPM Card Length
4 Extended Long 1310 nm
wave
4 Long wave 1310 nm
4 Short wave 850 nm
Media/ Standard
Distance
9/125 µm 100-SM-LL-L
Single-mode:
1 m–35 Km
9/125 µm 100-SM-LL-L
Single-mode:
1 m–10 Km
50/125 µm 100-M5-SN-I
Multimode:
2 m–500 m
62.5/125 µm
Multimode:
1 m–200 m
