3. Power on the maintenance terminal. After the PC powers on, the Windows desktop is displayed.
Refer to operating instructions shipped with the PC.
Procedures for changing network addresses using the HyperTerminal serial
NOTE:
communication software are described in
4. Select Start > Programs > Accessories > Communications > HyperTerminal. The Connection
Description dialog box is displayed,
Figure 7

Connection Description dialog box

5. Enter edge switch 2-24 in the Name field and click OK. The Connect To dialog box is displayed
(Figure 8).
Figure 8

Connect To dialog box

step 4 through
(Figure 7).
Edge Switch 2/24 installation guide
step 13.
35
