End_time This field is the end time for the virtual circuit. The expected format is
HH:MM:SS. The Seconds field is optional.
Header_ This determines whether you will have no compression on cell headers, or
compression if you will use TCP/IP compression on the cell headers transmitted across
this vc.
idle_timeout Interval to wait before timing out an inactive connection. Default: 300
seconds.
input_filter Designation of the filter file in FLASH memory to be applied to the input
data stream.
ip Sets interface to enable/disable protocol. Default is enable.
ip_routing Sets routing type (RIP packets) accepted on this connection. Options:
LISTEN - detects packets destined for system's nets
SEND - routes packets destined for the remote network
BOTH - both of the above
NONE - ignores all routing packets
ip_source_ When enabled, any packet who's source IP address falls within the LANs
validation IP network will be dropped.
ipx This controls whether to enable or disable IPX for the virtual circuit. The
choices are [ENABLE, DISABLE].
ipx_address This sets the IPX address for the virtual circuit.
ipx_routing This sets the routing type (RIP packets) accepted on this connection.
Options are:
ALL - listens, sends, and responds RIP packets.
LISTEN - detects packets destined for the system's network.
NONE - ignores all routing packets.
RESPOND - responds by sending out packets
SEND - routes packets destined for the remote network.
ipx_wan This determines if IPX is enabled or disabled for the WAN. Options are
[ENABLED, DISABLED].
local_IP_address IP address of the VC making an IP connection over the WAN interface.
There are two special values which may be assigned to the
local_IP_address:
The local_IP_address should be learned via PPP negotiation
(255.255.255.255).
The interface is Unnumbered (0.0.0.0).
mac_routing Determines if MAC-Encapsulated Routing is enabled.
MTU Maximum Transfer Unit - largest data packet size allowed.
NAT_option Enable / disable Network Address Translation.
NAT_default_ Default workstation address that incoming IP traffic will get forwarded to
address if the demuxing of the network address translation is unresolved.
Network_service Type of network service. Default is PPP.
output_filter Name of filter file in FLASH memory to be applied to output data stream.
Password The password is an alphanumeric string of maximum size 15 characters.
remote_IP_address For a client IP connection, address assigned to the client.
Rip Selects either RIPV1 or RIPV2 for IP RIP.
rip_authentication Text string used for RIPv2 authentication.
CLI Commands B-33
