PCI-DIO24/LP User's Guide

Mechanical

Card dimensions
Form factor

Connector and pin out

I/O connector type
Compatible cables
Compatible accessories
Pin Signal Name
1 Port A0
2 Port A1
3 Port A2
4 Port A3
5 Port A4
6 Port A5
7 Port A6
8 Port A7
9 Port B0
10 Port B1
11 Port B2
12 Port B3
13 Port B4
14 Port B5
15 Port B6
16 Port B7
17 Port C0
18 Port C1
19 Port C2
20 Port C3
21 Port C4
22 Port C5
23 Port C6
24 Port C7
25 n/c
26 IRQ_ENABLE
27 IRQ_INPUT
28 n/c
29 n/c
30 n/c
31 GND
32 n/c
33 GND
34 PC +5V
Table 5. Mechanical specifications
PCI low-profile MD2 length:
131.8 mm (L) x 63.5 mm (W) x 18.4 mm (H)
Universal PCI keying. Compatible with either 3.3 V or 5 V PCI signaling environments.
Table 6. Connector specifications
SCSI type ultra micro DB68 VHDCI female
MCC p/n C68MMS-x. x = 3 or 6 feet.
CIO-MINI68
CIO-MINI68/DST
Table 7. Connector pin out
15
SpecificationsError! No text of specified style in document.
Pin Signal Name
35 GND
36 GND
37 GND
38 GND
39 GND
40 GND
41 GND
42 GND
43 GND
44 GND
45 GND
46 GND
47 GND
48 GND
49 GND
50 GND
51 GND
52 GND
53 GND
54 GND
55 GND
56 GND
57 GND
58 GND
59 GND
60 n/c
61 n/c
62 n/c
63 n/c
64 n/c
65 GND
66 n/c
67 GND
68 PC +5V
