i-on40
is 270mA i.e. the aux current that can be
supplied for 12hrs by a 7 A-h battery under
normal operating conditions.

EN50131-6 ratings:

PSU rated output:
Independent power
outputs (Normal
operating
conditions):
CIE power
requirement:
Keypad power
requirement:
Battery changing
requirement:
Communicator
power requirement:
12V Aux output
voltage range:
14.4V output
voltage range:
Max p-to-p ripple
voltage:
Standby Battery:
Max recharge time
to 80% capacity:
'Low battery' fault
at:
Aux power output
fault at:
Deep discharge
protection at:
Serviceable
components:
Standby time:
Electromagnetic
Compatibility
Immunity Conforms to EN50130-4.
Emissions Conforms to EN61000-6-3.
Outputs
O/P 1 - 2 Voltage free, single pole
relay contacts rated 24VDC
@ 1A.
O/P 3 - 4 Open collector transistor,
+12VDC when inactive, 0V
when active. 500mA max.
O/P 5 - 16 Open collector transistor
+12VDC when inactive, 0V
when active, 50mA max.
LS Min impedance 16 Ohm,
270mA max
Total not to exceed
270mA for 7 Ah
battery
130mA min.
220mA max
30mA (backlight off)
45mA (backlight on)
65mA (backlight on)
270mA
20mA quiescent
50mA max
9±0.5V to 13.8V
9±0.5V to 14.7V
0.5V
12V, 7Ah sealed lead
acid.
Less than 72 hours.
< 12V
< 9V
9±0.5V
Mains fuse: 250mA
(T)
See "Power
Availabillity" on page
4.
(loudspeaker) current consumption from
12VAux = 280mA in alarm.
Fuses
The control unit has a replaceable T250mA
mains fuse.
Electrical Safety
Conforms to EN60950-1.
Other
If you wish to connect the i-on40 control
unit to a PC using either the Ethernet or the
USB port then make sure that the cables
have the following specifications:
Ethernet Cat5e patch cable, RJ45
male plugs at each end,
suitable for 10/100Base-T.
USB Mini-B plug for control unit
end, USB-A for PC end.
Max length 3m.
Compliance Statements
This product is suitable for use in systems
designed to comply with PD 6662: 2004 at
grade 2 and environmental class II.
This product complies with the
requirements of EN50131-3 at grade 2 and
environmental class II.
This product complies with the
requirements of EN50131-6:2008 at grade
2 and environmental class II.
When fitted with an i-sd02 this equipment
is compliant with EN 50136-1. It allows the
alarm transmission system to meet the
performance requirements of EN 50131-
1:2006 ATS 2 provided that:
a) It is installed in accordance with the
installation instructions.
b) The connected PSTN is functioning
normally.
When fitted with an i-sd02 this product
provides options A, B and C at Grade 2 as
noted in Table 10 of EN50131-
1:2006+A1:2009.
If the installer selects a non-
compliant configuration then they must
remove or adjust compliance labelling
Third party approval carried out by
Telefication
Page 23
