AT-3714F, AT-3726 Hardware Description

Physical Description

Hardware Features

1-2
The switches have the following major front panel components:
24 Ethernet 10Base-T RJ45 ports with one 10/100Base-TX port
(Fast ethernet) (AT-3726); 12 10Base-FL ports (SC or ST) with
one 100Base-FX (fiber SC) port (AT-3714F)
Optional Media Dependent Adapter (MDA)--100Base-X port
can be configured either with 10/100Base-TX (RJ45) or
100Base-FX port (fiber SC)
Port Mirroring (Port M) 10Base-T RJ45
RS232 (DB9) connector (out-of-band/Local Omega)
Reset button
System and port status LEDs
The switches have the following major hardware features:
Full duplex capability on all ports eliminates collisions and
provides up to 20 Mbps on the 10Base ports and up to 200
Mbps of bandwidth on the 100Base ports to servers, routers,
and other switches
Auto-negotiation on all 10BaseT and 10/100BaseTX ports in
compliance with IEEE 802.3u
Port mirroring
Non-blocking, clear-channel architecture delivers wire-speed
switching and up to 880 Mbps aggregate bandwidth for
exceptional performance (AT-3726); 640Mbps for AT-3714F
Shared memory architecture with 1M of packet buffers per
ASIC chip (two ASICs for AT-3726; one ASIC for AT-3714F)
Store-and-forward and Cut-through (fragment-free)
switching modes
Stores up to 1954 MAC addresses
