How the Switch Reports Problems

Name
Color
Fault
Red
Power
Green
Link OK
Green
(Ethernet)
Activity
Green
(TX/RX)
The switch detects and processes errors as follows:
The LEDs indicate problems with the port and power.
Table 3-1 describes the switch LEDs.
In a TCP/IP environment, if you have configured the software
correctly, the management software triggers an SNMP trap
message. As a result, the software then sends traps to alert the
network manager when a trigger occurs. This type of software
configuring allows the network administrator/manager to
pro-actively monitor their network.
Table 3-1 lists and describes the switch LEDs.
Table 3-1 LEDs
State
ON
Indicates that the management software is
malfunctioning, a problem exists with the serial
interface, diagnostics is running, or a hardware
problem.
OFF
Indicates no problem.
ON
Indicates that power is being applied to the switch
Indicates the voltage has dropped below acceptable
OFF
levels or the power cord is loose.
ON
Indicates that there is a good physical link with a
device.
OFF
Indicates the physical link is broken.
Flashing Indicates the Ethernet port is receiving/transmitting
packets.
AT-3714F and AT-3726 Installation Guide
Description
3-3
