10/100BaseTX/
FX Media
Dependent
Adapter
RS232
Connector

Reset Button

AC Power
Connector
The MDA's LEDs, one for Activity and the other for Link status, are
located on the switch's front panel under Port Activity. Table 1-1 lists
the features of the MDAs. For details concerning how to install an
MDA, see Chapter 2, Installing a Media Dependent Adapter.
Table 1-1 Media Dependent Adapter Features
Supported
Adapter
AT-3701 UTP
AT-3701F/SC Fiber SC
The RS232 connector provides out-of-band management via a
VT-100 terminal or MS-Windows' VTERM terminal emulation using a
straight-through cable.
This recessed button can be activated using the tip of a ball point
pen to run power-on self test.
The switch has a single power supply, which has autoswitch AC
inputs. The input voltage range is from 120-240 VAC, 50/60 Hz.
AT-3714F and AT-3726 Installation Guide
Cable
10/100Base-TX RJ45
Ethernet port: auto-negotiated speed
and duplex mode
10/100Base-T max. segment length:
330' (100m), Category 5 UTP
100Base-FX: multimode SC fiber
connector
100Base Ethernet port
100Base-FX: max. segment length
1.25 miles (2 km for full duplex, 412 M for
half duplex)
micron multimode fiber
Description
; 50/125 and 62.5/125
1-5
