THERMAL ARC 161STL, 201TS
9.03 Replacement Part List - 201TS
Item No
Description
1
Handle
2
Panel, Cover
3
Rectifier 1000V,50A
4
PCB,Control,201TS
5
Thermostat
6
Resistor,6 ohm,60W
7
PCB,Power,201TS
8
Insulation Sheet
9
Points,HF Starter,201TS
10
Output Inductor Magnetic Core
11
Front Control PCB3
12
Front Panel
13
Front Panel Label
14
Rubber Boot
15
Knob, control, Red, 21 ODx6 ID
16
Connector,Gas Outlet,161STL-201TS
17
Output Terminal, 50mm dinse
18
Socket,8 Pin,cable,161STL-201TS
19
Gas Solenoid
20
Current Sensor, 161-201TS
21
Base Panel
22
Fan,24V DC
23
Rear Panel
24
Cable Cord,12AWG,10ft,6-50P
25
Connector,Gas Inlet,161STL-201TS
26
ON/OFF Switch
27
PCB,Remote,161STL-201TS
Replacement Parts
Part No.
W7003040
W7003200
W7003010
W7003222
W7003016
W7003055
W7003216
W7003214
W7003034
W7003210
W7003218
W7003205
W7003219
W7003064
W7003079
W7003212
W7003020
W7003220
W7003033
W7003076
W7003209
W7003090
W7003201
W7003052
W7003215
W7003053
W7003221
9-4
REPLACEMENT PARTS
Reference Designator
PCB2
THC1, THC2
R1
PCB1
PCB3
Current Sensor
SW1
PCB4
Manual 0-5148
