Code
(last 4
Large LCD
digits)
2E3A
Roll1 (Uppr) jammed.
Manually rewind the
roll all the way
and press OK.
2E3B
Roll 2 (Lwr) jammed.
Manually rewind the
roll all the way
and press OK.
2E3C
Paper jam. Lift
the release lever.
2E3D
Roll 1 (upper) jam
Lift the release
lever.
2E3E
Roll 2 (lower) jam
Lift the release
lever.
2E3F
Paper jam. Lift
the release lever.
2E40
Cannot print as
selected. Another
roll is in use.
[Stop]: Stop printing
2E41
Cannot print as
selected. Another
roll is in use.
[Stop]: Stop printing
2E42
MediaType Mismatch
2E45
MediaType Mismatch
2F11
CR error
Call for Service.
Troubleshooting Guide
Panel display
Small
Small
LCD 1
LCD 2
Power
CR
On
Error
Again
Explanation/Detection sequence
During upper roll paper feeding operation,
the paper was fed with the roll feed sensor
detecting the paper, but the LF_PE sensor
could not detect the paper and the operation
timed out.
During lower roll paper feeding operation,
the paper was fed with the roll feed sensor
detecting the paper, but the LF_PE sensor
could not detect the paper and the operation
timed out.
During operations with cut sheet, the state
of the LF_PE sensor has become invalid.
During operations with upper roll paper, the
paper was fed with the roll paper detection
sensor and the roll feeding sensor detecting
the paper, but the state of the LF_PE sensor
became invalid.
During operations with lower roll paper, the
paper was fed with the roll paper detection
sensor and the roll feeding sensor detecting
the paper, but the state of the LF_PE sensor
became invalid.
When either upper or lower roll paper is in
operation, the states of the roll paper
detection sensor, roll feeding sensor, and
LF_PE sensor became invalid.
Print data having lower roll paper
specification has been received while upper
roll printout remains.
Print data having upper roll paper
specification has been received while lower
roll printout remains.
Paper mismatch (type/ restart printing of
suspended job)
It occurs when all of the following conditions
are met:
・[Stop] selected for [Paper Mismatch
Detection] in menu settings.
・[Change Paper] button was pressed for
suspended jobs from host.
・The paper type that has been set in the job
and the type of actually fed paper do not
match.
Paper mismatch (type/ restart printing of
suspended job)
It occurs when all of the following conditions
are met:
・[Stop] selected for [Paper Mismatch
Detection] in menu settings.
・The paper width that has been set with
data and the paper width of actually fed
paper do not match.
An operation order has been issued while
the carriage suffered a hardware error.
2-42
Remedial Action
(★: Reference fault
isolation procedure
or tool)
①Manually rewind
the paper and
reload. Go to ★
2E25.
①Manually rewind
the paper and
reload. Go to ★
2E25.
①Reload the
paper. Go to ★
2E25.
①Reload the
paper. Go to ★
2E25.
①Reload the
paper. Go to ★
2E25.
①Reload the
paper. Go to ★
2E25.
Remove the
printout of upper
roll, and print
again.
Remove the
printout of lower
roll, and print
again.
Continued printing
allowed.
Replace with
appropriate paper.
Continued printing
allowed.
Check the driver
settings.
Replace with
appropriate paper.
Go to ★2F26
(P3-4).
